1. Introduction
This manual provides detailed instructions for the installation, operation, and maintenance of your LUTHXAY 84-Inch Double Sink Floating Bathroom Vanity with LED Smart Mirror Cabinet. Please read this manual thoroughly before beginning installation or use to ensure proper function and safety. Keep this manual for future reference.
The LUTHXAY vanity system is designed for modern bathrooms, featuring a wall-mounted floating design, dual ceramic sinks, a smart LED defogging mirror cabinet, and soft-close drawers for enhanced functionality and aesthetic appeal.
Figure 1: LUTHXAY 84-Inch Double Sink Floating Bathroom Vanity with LED Smart Mirror Cabinet.
2. Safety Information
WARNING: Failure to follow these safety instructions may result in injury, property damage, or product malfunction.
- Always disconnect power before performing any electrical work.
- This product is heavy. Two or more people are recommended for lifting and installation.
- Ensure the wall structure is capable of supporting the weight of the vanity and mirror cabinet. Consult a professional if unsure.
- All plumbing and electrical connections must comply with local building codes and regulations. Professional installation is highly recommended.
- Avoid using abrasive cleaners or tools that could damage surfaces.
- Keep small parts and hardware away from children.
3. Package Contents
Verify that all components are present and undamaged before beginning installation. If any parts are missing or damaged, contact customer support immediately.
- Vanity Cabinet (84-inch)
- Ceramic Sinks (2 units)
- LED Smart Defog Mirror Cabinet
- Mounting Hardware Kit
- Installation Manual
4. Setup and Installation
Professional installation is recommended for optimal results and safety.
4.1 Pre-Installation Checklist
- Tools Required: Measuring tape, level, drill, stud finder, screwdriver set, caulk gun, safety glasses, gloves.
- Location: Ensure adequate space and access to plumbing and electrical connections.
- Wall Preparation: Identify wall studs for secure mounting. Reinforce wall if necessary.
4.2 Vanity Cabinet Installation
- Determine Height: The recommended height for the sink top is 31-33 inches above the ground. Adjust according to user preference.
- Mark Mounting Points: Measure and mark the desired position for the vanity cabinet on the wall. Use a level to ensure accuracy.
- Drill Holes: Drill pilot holes at the marked locations. Insert expansion screws or appropriate wall anchors suitable for your wall type.
- Mount Cabinet: Carefully lift the vanity cabinet and align it with the drilled holes. Secure the cabinet to the wall using the provided mounting hardware. Ensure it is level and firmly attached.
- Install Sinks: Place the ceramic sinks onto the vanity cabinet. Apply waterproof sealant (e.g., silicone caulk) around the edges to secure and seal the sinks. Connect the faucet and drain assemblies (not included).
4.3 LED Smart Mirror Cabinet Installation
- Determine Height: The recommended height for the mirror is 71-75 inches above the ground, with the bottom edge ideally higher than the faucet height.
- Mark Mounting Points: Measure and mark the position for the mirror cabinet. Ensure it is centered above the vanity.
- Drill Holes and Mount: Drill pilot holes and secure the mirror cabinet to the wall using appropriate hardware.
- Electrical Connection: Connect the mirror cabinet's power cord to the reserved light cord or a nearby power socket. Refer to the wiring diagram below.
Figure 2: Visual guide for vanity and mirror cabinet installation steps.
Figure 3: Wiring options for the LED mirror cabinet. Solution A: Connect to reserved light cord. Solution B: Use a power cord with a plug to a nearby socket.
4.4 Plumbing Connections
- Connect hot and cold water supply lines to the faucet.
- Connect the sink drain to the P-trap and then to the wall drain pipe.
- Check all connections for leaks after turning on the water supply.
5. Operating Instructions
5.1 LED Smart Defog Mirror Cabinet
- LED Lighting: Touch the designated sensor button on the mirror surface to turn the LED lighting on or off.
- Defogging Function: Touch the defogger sensor button on the mirror surface to activate the defogging function. This will quickly clear any water mist from the mirror. Touch again to deactivate.
Figure 4: LED smart mirror cabinet demonstrating soft LED lighting and one-click smart defogging functionality.
5.2 Soft-Close Drawers
The vanity is equipped with soft-close hinges on its drawers. This feature allows the drawers to close gently and silently, preventing slamming and reducing wear and tear. Simply push the drawer gently to close, and the mechanism will engage.
Figure 5: Example of a stainless steel soft-close hinge, ensuring quiet and smooth drawer operation.
6. Maintenance
6.1 Ceramic Sinks
- Clean regularly with a soft cloth and mild, non-abrasive cleaner.
- Rinse thoroughly after cleaning to remove any residue.
- Avoid harsh chemicals, abrasive pads, or steel wool, which can scratch the surface.
Figure 6: The ceramic sink is manufactured through a 1380°C high-temperature calcining process, ensuring durability and ease of cleaning.
6.2 Vanity Cabinet and Mirror Cabinet
- Wipe surfaces with a soft, damp cloth. For stubborn spots, use a mild, non-abrasive cleaner.
- Dry surfaces immediately after cleaning to prevent water spots or damage.
- Do not use ammonia-based cleaners on the mirror, as they can damage the silvering.
- Ensure the cabinet remains dry to maintain its waterproof and moisture-proof properties.
Figure 7: The vanity cabinet is constructed from multilayer solid wood, designed to be waterproof and moisture-proof for bathroom environments.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| LED mirror light not working | No power supply; loose connection; faulty sensor. | Check power connection; ensure switch is on; verify wiring; contact support if sensor is faulty. |
| Defogger not activating | No power; faulty sensor. | Check power; contact support if sensor is faulty. |
| Drawers not closing softly | Obstruction in drawer slide; damaged soft-close mechanism. | Remove any obstructions; inspect hinges for damage; contact support for replacement parts. |
| Water leak from sink/faucet | Loose plumbing connection; improper sealant application. | Tighten connections; reapply waterproof sealant as needed. |
If you encounter issues not listed here or if the suggested solutions do not resolve the problem, please contact LUTHXAY customer support.
8. Specifications
Figure 8: Detailed dimensions for the 84-inch vanity and mirror cabinet components.
| Feature | Detail |
|---|---|
| Brand | LUTHXAY |
| Model | 84 Inch Double Sink Bathroom Vanity |
| ASIN | B0DPKRY7MV |
| Material | Multilayer Solid Wood (Cabinet), Ceramic (Sinks) |
| Number of Sinks | 2 |
| Number of Drawers | 2 |
| Product Dimensions (Vanity) | 84" L x 22" W x 20" H (approximate) |
| Mirror Cabinet Dimensions | 82" L x 28" H (approximate) |
| Color | Brown |
| Special Features | Wall Mounted, Floating Design, LED Smart Defog Mirror, Soft-Close Drawers, Ample Storage |
9. Warranty Information
For specific warranty details regarding your LUTHXAY 84-Inch Double Sink Floating Bathroom Vanity, please refer to the warranty card included with your purchase or contact the seller directly. Warranty terms typically cover manufacturing defects and material flaws under normal use.
10. Customer Support
If you have any questions, require assistance with installation, or need to report a missing or damaged part, please contact LUTHXAY customer support through the platform where you purchased the product. Please have your model number (B0DPKRY7MV) and purchase date available when contacting support.
