Syrinx YG607 Dual Head LED Floor Lamp Instruction Manual

Introduction

Thank you for choosing the Syrinx YG607 Dual Head LED Floor Lamp. This lamp is designed to provide versatile and eye-caring illumination for various activities and environments, including living rooms, bedrooms, and offices. It features adjustable brightness and color temperature, flexible gooseneck arms, and convenient control methods including a gesture switch and remote control. Please read this manual thoroughly before use to ensure proper setup and operation.

What's in the Box

• 1 × Double-Head Floor Lamp
• 4 × Lamp Poles
• 1 × Lamp Base
• 1 × Power Adapter
• 1 × User Manual

Setup

Assembly of the Syrinx YG607 Dual Head LED Floor Lamp is required. Follow these steps to set up your lamp:

1. Carefully unpack all components from the box.
2. Connect the four lamp poles by screwing them together clockwise. Ensure each connection is secure.
3. Attach the assembled lamp pole to the lamp base by screwing it clockwise until firmly in place. The sturdy iron base provides stability.
4. Connect the double-head lamp unit to the top of the assembled pole.
5. Plug the power adapter into the lamp's power input, then plug the adapter into a standard electrical outlet.

Figure 1: Lamp assembly diagram, highlighting the sturdy iron base and overall dimensions.

Operating Instructions

The Syrinx YG607 lamp offers multiple ways to control its lighting features.

1. Power On/Off

• Gesture Switch: Wave your hand within 3 inches above the sensor on the lamp head to turn the lamp on or off.
• Remote Control: Press the 'ON/OFF' button on the remote control to power the lamp on or off.

2. Brightness Adjustment

The lamp offers 10 levels of brightness adjustment.

• Remote Control: Use the 'Brightness+' button to increase brightness and 'Brightness-' button to decrease brightness.

Figure 2: Illustration of 10-level brightness adjustment.

3. Color Temperature Adjustment

Choose from 5 color temperatures (3000K-6000K) to suit your preference.

• Remote Control: Press the 'Color Temperature' button to cycle through the 5 available color temperatures.

Figure 3: Visual representation of 5 color temperature modes.

4. Reading Mode

Activate a pre-set lighting mode optimized for reading.

• Remote Control: Short press the 'Natural Light' button (depicted as a book icon) to enter reading mode.

5. Timer Function

Set the lamp to automatically turn off after a specified duration.

• Remote Control: Short press the 'Timing' button to activate the 45-minute timer. The lamp will turn off automatically after 45 minutes.

Figure 4: The 45-minute timer function in use.

6. Memory Function

The lamp remembers your last brightness and color temperature settings when turned off and on again.

Figure 5: Memory function ensures previous settings are retained.

7. Remote Control

The remote control allows convenient adjustment of all lighting features. It features a magnetic design for easy attachment to the lamp pole, keeping it accessible.

Figure 6: Remote control with magnetic design and gesture sensor location.

Features

1. Dual Head & Flexible Gooseneck

The lamp features two independent light heads with a 360° rotatable gooseneck and 180° foldable swing arms. This allows for precise light direction, providing focused or wide coverage as needed.

Figure 7: Dual-angle lighting with flexible gooseneck and foldable arms.

2. Eye-Caring Technology

Equipped with 96 high-quality LED lamp beads, this lamp provides uniform brightness, wide lighting range, no strobe, no blue light hazard, and no glare. The soft light protects your eyes from fatigue, making it ideal for extended use. It boasts a Color Rendering Index (CRI) greater than 90, accurately restoring colors.

Figure 8: Eye-caring and flicker-free lighting benefits.

Figure 9: High CRI (>90) for accurate color rendering.

3. Energy Efficiency

The LED technology consumes 80% less energy than traditional bulbs, providing 14W/2000lm of bright illumination while being environmentally friendly.

4. Versatile Applications

With its 23.7-inch ultra-wide lamp bar and 59-inch max height, this lamp is suitable for a wide array of activities such as reading, crafting, sewing, playing the piano, and can be an excellent addition to living rooms, bedrooms, and offices.

Figure 10: Examples of versatile applications for the lamp.

Specifications

Maintenance

To ensure the longevity and optimal performance of your Syrinx LED Floor Lamp, follow these maintenance guidelines:

• Cleaning: Disconnect the power before cleaning. Use a soft, dry cloth to wipe the lamp. Do not use abrasive cleaners, solvents, or polishing agents as they may damage the finish or electrical components.
• Bulb Replacement: The LED light source is integrated and not user-replaceable. Do not attempt to disassemble the lamp head.
• Storage: If storing the lamp for an extended period, ensure it is clean and dry. Store it in a cool, dry place away from direct sunlight and extreme temperatures.

Troubleshooting

If you encounter any issues with your lamp, please refer to the following common problems and solutions:

Warranty and Support

Syrinx is committed to providing high-quality products and customer satisfaction. Your Syrinx LED Floor Lamp undergoes rigorous quality inspections.

• Return Policy: Enjoy a worry-free 3-month return policy.
• Technical Support: Benefit from 24 months of technical support.
• Contact: If you have any questions or require assistance, please feel free to contact our US local team. We are dedicated to providing prompt solutions.
