1. Introduction
The Vital Health Wearable Breast Pump Model 9754 is designed for convenient and discreet milk expression. This hands-free device allows for ease of use, operating quietly to minimize disturbance. It is engineered to provide an efficient and comfortable pumping experience for mothers.
Please read this manual thoroughly before first use to ensure proper operation, maintenance, and safety. Keep this manual for future reference.
2. Safety Information
WARNING: Failure to follow these safety instructions could result in injury or damage to the product.
- This device is intended for personal use by lactating mothers to express breast milk. Do not use for any other purpose.
- Always inspect the pump and its components for damage before each use. Discontinue use if any part is damaged.
- Keep the device and all its components out of reach of children. This is not a toy.
- Do not immerse the pump motor unit in water or other liquids.
- Use only the provided USB charging cable. Do not use unauthorized chargers.
- Do not use while bathing or showering.
- Consult a healthcare professional if you experience pain or discomfort during pumping.
- The product materials are BPA Free, Chemical Free, and Phthalate Free.
- Actual product packaging and materials may contain more and different information than what is shown on our website. We recommend that you do not rely solely on the information presented and that you always read labels, warnings, and directions before using or consuming a product.
3. Product Overview and Components
The Vital Health Wearable Breast Pump 9754 comes with the following components:
- Pump Motor Unit
- Milk Collector Cup (180ml capacity)
- 24mm Flange
- Flange Inserts (17mm, 19mm, 21mm)
- Silicone Diaphragm
- Valve
- USB Type-C Charging Cable
- Bra Adjustment Strap
- User Manual
Image 1: All components of the Vital Health Wearable Breast Pump 9754, including the pump unit, milk collector, flanges, inserts, charging cable, and bra strap, shown with its packaging.
Image 2: The assembled Vital Health Wearable Breast Pump 9754 unit, showcasing its compact and ergonomic design.
4. Setup and Assembly
4.1. Charging the Pump
- Connect the USB Type-C charging cable to the charging port on the pump motor unit.
- Plug the other end of the cable into a compatible USB power adapter (not included) or a USB port.
- The LED display will indicate charging status. A full charge takes approximately 2.5 hours and provides about 90 minutes of operational time.
4.2. Assembling the Pump
- Ensure all components are clean and dry before assembly (refer to Section 6 for cleaning instructions).
- Insert the silicone diaphragm securely into the pump motor unit, ensuring a tight seal.
- Attach the valve to the bottom of the milk collector cup.
- Place the 24mm flange onto the milk collector cup. If a smaller size is needed, insert the appropriate flange insert (17mm, 19mm, or 21mm) into the 24mm flange.
- Connect the assembled milk collector cup with the flange to the pump motor unit, ensuring it clicks into place securely.
5. Operating Instructions
5.1. Wearing the Pump
- Position the assembled pump unit over your breast, ensuring your nipple is centered within the flange tunnel.
- Place the pump inside your nursing bra. Adjust your bra or use the included bra adjustment strap to ensure a snug and secure fit. The pump should feel comfortable and stable.
Image 3: A user demonstrating the discreet and hands-free wearability of the Vital Health Wearable Breast Pump 9754 within a bra.
5.2. Powering On and Adjusting Settings
- Press and hold the power button on the pump motor unit to turn it on. The LED display will illuminate.
- The pump features 3 modes and 12 adjustable suction levels. Use the mode button to cycle through the available modes (e.g., massage, expression, mixed).
- Use the '+' and '-' buttons to adjust the suction intensity within your chosen mode. Start with a low suction level and gradually increase it to a comfortable setting that promotes milk flow.
- The LED display will show the current mode and suction level.
5.3. Pumping and Milk Collection
- Pump for a duration that is comfortable and effective for you, typically 15-20 minutes per breast.
- Monitor the milk flow into the collector cup. The pump's backflow prevention design ensures hygiene.
- When finished, press and hold the power button to turn off the pump.
- Carefully remove the pump from your bra and detach the milk collector cup from the motor unit.
- Pour the expressed milk into a sterile storage bottle or bag.
6. Cleaning and Maintenance
IMPORTANT: Clean and sterilize all parts that come into contact with breast milk before first use and after each subsequent use.
6.1. Disassembly for Cleaning
- Turn off the pump and disconnect it from any power source.
- Carefully separate the milk collector cup from the pump motor unit.
- Disassemble all parts that come into contact with milk: flange, flange insert, valve, and milk collector cup.
- The pump motor unit should not be washed or sterilized. Wipe it with a clean, damp cloth if necessary.
6.2. Cleaning and Sterilization
- Washing: Wash all disassembled parts (except the motor unit) in warm, soapy water. Use a soft brush to clean hard-to-reach areas. Rinse thoroughly with clean water.
- Sterilization: Sterilize the cleaned parts by boiling them in water for 5 minutes, using a steam sterilizer, or a cold water sterilization solution according to the manufacturer's instructions.
- Drying: Allow all parts to air dry completely on a clean drying rack or use a clean cloth. Ensure no moisture remains before reassembly.
6.3. Storage
Store the clean and dry pump and its components in a clean, dry place away from direct sunlight and extreme temperatures.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Pump not turning on | Low battery; Power button not pressed correctly | Charge the pump fully; Press and hold the power button firmly. |
| No or low suction | Improper assembly; Damaged silicone parts; Flange not sealed correctly; Suction level too low | Ensure all parts are assembled correctly and securely; Check silicone diaphragm and valve for tears or damage and replace if necessary; Reposition the flange for a tight seal; Increase suction level. |
| Milk leaking | Milk collector cup overfilled; Improper assembly; Damaged valve | Do not exceed the 180ml capacity; Ensure all parts are securely assembled; Check the valve for damage and replace if necessary. |
| Pump making unusual noise | Improper assembly; Foreign object in pump | Disassemble and reassemble all parts carefully; Inspect for any foreign objects. If noise persists, contact customer support. |
8. Specifications
- Model Number: 9754
- Bottle Capacity: 180ml
- Charger Type: USB Type-C
- Charging Time: Approximately 2.5 hours
- Operational Time Per Charge: Approximately 90 minutes
- Battery Type: 1000mAh Lithium Ion
- Lithium Battery Voltage: 3.7V
- Vacuum: 280mmHg
- Modes: 3
- Suction Levels: 12
- Dimensions: 122 x 110 x 68mm (approx. 11L x 6.8W x 12.2H cm)
- Net Weight: 230g
- Flange Size: 24mm (with 17mm, 19mm, 21mm inserts)
- Noise Level: 50 db
- Material: Plastic, Silicone (BPA Free, Chemical Free, Phthalate Free)
9. Warranty and Support
9.1. Manufacturer's Warranty
This Vital Health Blay Scientific Wearable Breast Pump 9754 is covered by a 1-year manufacturer's warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage caused by misuse, accidents, unauthorized modifications, or normal wear and tear.
Please retain your proof of purchase for warranty claims.
9.2. Customer Support
For any questions, concerns, or warranty claims, please contact our customer service team:
Email: customer.service@blayscientific.com
Our team is available to assist you with product inquiries, troubleshooting, and support.
