User Manual: 19x15W Moving Head LED Light

1. Introduction

This manual provides detailed instructions for the safe operation, installation, and maintenance of your Osusuent 19x15W Moving Head LED Light. Please read this manual thoroughly before use to ensure proper functionality and to prevent damage.

Figure 1: Osusuent 19x15W Moving Head LED Light, front view.

2. Safety Information

Always observe the following safety precautions to reduce the risk of electric shock, fire, or injury:

• Ensure the power supply matches the specified voltage (1E+2 Volts AC).
• Do not expose the device to rain or moisture.
• Always disconnect from power before cleaning or servicing.
• Ensure proper ventilation to prevent overheating. The unit features an advanced heat dissipation design and high-power fan.
• Avoid direct eye exposure to the light source.
• Install the fixture securely using appropriate mounting hardware. The double handle configuration facilitates ceiling or wall installation.

3. Product Overview

The Osusuent 19x15W Moving Head LED Light is a versatile stage lighting fixture designed for various events. It features 19 RGBW 4-in-1 LED lamp beads, offering a wide range of color mixing capabilities and Beam/Wash/Zoom 3-in-1 functions.

Key Components:

• LED Array: 19 RGBW 4-in-1 LEDs for vibrant color output.
• Optical Lens: Designed for wider and more beautiful light emission.
• Moving Head: Allows for 270° Y-axis and 540° X-axis rotation.
• Control Panel: LCD display and navigation buttons for mode selection and settings.
• DMX Ports: DMX-IN and DMX-OUT for external control.
• Power Ports: Power-IN and Power-OUT for daisy-chaining units.

Figure 2: Internal components including optical lenses and LED beads.

Figure 3: Key features including optical lens, cooling fan, rotary arm, and control system.

4. Setup and Installation

4.1 Unboxing and Initial Inspection

Carefully remove the light fixture and all accessories from the packaging. Inspect for any signs of damage during transit. Ensure all included components are present (light kit included).

4.2 Mounting

The fixture can be installed on a ceiling, wall, or placed on a flat surface. Use the integrated double handle configuration for secure mounting. Ensure the mounting surface can support the weight of the fixture and any additional equipment.

Figure 4: Product dimensions and different views for installation planning.

4.3 Connections

Connect the power cable to the Power-IN port. For DMX control, connect a DMX cable from your controller to the DMX-IN port. Multiple units can be daisy-chained using the Power-OUT and DMX-OUT ports.

Figure 5: DMX-IN and DMX-OUT ports.

Figure 6: Power-IN and Power-OUT ports.

5. Operating Modes

The Osusuent Moving Head LED Light offers multiple working modes, selectable via the control panel or DMX. The control panel features an LCD display and navigation buttons (UP, DOWN, MENU, ENTER).

Figure 7: Control panel buttons.

Figure 8: LCD display showing Main Menu.

Available Modes:

• Static Color Mode: Displays a single, fixed color.
• Strobe Mode: Produces rapid flashes of light.
• Automatic Mode: Cycles through pre-programmed light sequences.
• Voice Control (Sound Activated) Mode: Lights react to sound and music.
• Master-Slave Mode: Multiple units synchronize, with one acting as master and others as slaves.
• DMX Mode: Allows for professional control via a DMX512 controller.
• Gradient Mode: Smooth transitions between colors.

Figure 9: Visual representation of available control modes.

6. Lighting Effects

The 19x15W Moving Head LED Light is capable of producing a wide array of dynamic lighting effects, enhancing any event or performance.

6.1 Beam/Wash/Zoom Functionality

This fixture combines Beam, Wash, and Zoom functions into one unit. The unique focusing function allows for precise control, enabling you to either color a large area with a wide wash or highlight a local area with a narrow beam.

Figure 10: Zoom angle capabilities (5°-60°) and light intensity.

6.2 Color Mixing

With 19 RGBW 4-in-1 LEDs, the light can mix to produce virtually any desired color, offering extensive creative possibilities.

Figure 11: Examples of various color outputs.

6.3 Demonstration Video

Watch the official product video to see the various lighting effects, zoom capabilities, and individual light bead control in action.

7. Maintenance

Regular maintenance ensures the longevity and optimal performance of your lighting fixture.

7.1 Cleaning

Clean the exterior of the fixture and lenses periodically with a soft, lint-free cloth. Do not use abrasive cleaners or solvents.

7.2 Heat Dissipation

The fixture is designed with advanced heat dissipation and a high-power fan. Ensure that ventilation openings are not blocked to maintain proper airflow and prevent overheating.

7.3 Light Bulb Recycling and Disposal

For information on recycling and proper disposal of light bulbs and damaged lamps, please refer to local regulations and guidelines. Do not dispose of electronic waste in general household waste.

8. Troubleshooting

If you encounter issues with your Osusuent Moving Head LED Light, refer to the following common problems and solutions:

• No Power: Check the power cable connection and ensure the power switch is in the 'ON' position. Verify the power source is active.
• No Light Output: Confirm the selected operating mode is active and not in a 'blackout' state. Check DMX connections if in DMX mode.
• Fixture Not Responding to DMX: Verify DMX cable connections, DMX address settings on the fixture, and DMX controller output. Ensure proper termination if daisy-chaining multiple units.
• Abnormal Movement/Noise: Disconnect power, check for any obstructions around the moving head. Reconnect power and observe. If the issue persists, contact support.
• Overheating: Ensure adequate ventilation around the unit. Clear any dust or debris from the fan and vents.

For issues not covered here, please contact customer support.

9. Technical Specifications

10. Warranty and Support

For warranty information and customer support, please refer to the product packaging or contact your retailer. Keep your purchase receipt as proof of purchase.

For technical assistance or service inquiries, please contact Osusuent customer service through their official website or the contact details provided with your purchase.
