FFanhia ST-822-FS
20in Wood Folding Shower Seat Instruction Manual
Brand: FFanhia | Model: ST-822-FS
Introduction
Thank you for choosing the FFanhia 20in Wood Folding Shower Seat. This wall-mounted shower bench is designed to provide a safe, comfortable, and space-saving seating solution for your bathroom. Crafted from high-quality oak wood and durable hardware, it features a unique 90° folding mechanism, making it ideal for small spaces while ensuring stability and ease of use. This manual will guide you through the installation, operation, and maintenance of your new shower seat.
Safety Information
- Maximum Load Capacity: The shower seat is designed to support a maximum load of 440.92 lbs (200 kg). Do not exceed this weight limit.
- Proper Installation: Ensure the seat is securely mounted to a solid wall or bathroom tile wall. It is NOT suitable for hollow walls. Improper installation can lead to serious injury.
- Regular Inspection: Periodically check all mounting screws and hardware to ensure they remain tight and secure.
- Children and Elderly: Supervise children and assist elderly or infirm individuals when using the shower seat.
- Avoid Standing: Do not stand on the shower seat. It is designed for sitting only.
Package Contents
Please verify that all components are present before beginning installation:
- 1x Foldable Shower Seat
- 2x Decorative Covers
- 2x Bases
- 1x English Installation Diagram
- All necessary accessories for use (screws, anchors, etc.)
Image: All components included in the package, laid out for inspection.
Setup and Installation
Before You Begin
Tools Required (not included):
- Drill
- Drill bits appropriate for your wall type and anchor size
- Measuring tape
- Pencil or marker
- Level
- Screwdriver
Important Note: This shower seat is designed for installation on solid walls and bathroom tile walls. It is not suitable for hollow walls. Ensure the drilling depth is greater than 70 mm (2.76 inches) for secure installation.
Installation Steps
- Determine Installation Height: Choose a comfortable height for the shower seat. The installation height can be freely selected to accommodate different users (children, adults, elderly). Mark the desired position on the wall.
- Mark Drilling Points: Use the bases as a template to mark the drilling points on the wall. Ensure the marks are level.
- Drill Holes: Using an appropriate drill bit for your wall material, drill holes at the marked points. The minimum drilling depth should be 70 mm (2.76 inches).
- Insert Wall Anchors: Insert the provided wall anchors into the drilled holes. Tap them gently with a hammer if necessary until they are flush with the wall surface.
- Attach Bases: Align the bases with the anchors and secure them to the wall using the provided screws. Ensure they are firmly tightened.
- Mount Shower Seat: Attach the foldable shower seat to the installed bases. Follow the specific instructions on the included English Installation Diagram for proper alignment and attachment.
- Install Decorative Covers: Place the circular decorative covers over the bases to conceal the mounting hardware. These covers also help dampen vibration and provide a silent folding effect.
- Test Stability: Before use, gently apply pressure to the seat to ensure it is securely mounted and stable.
Image: Components and installation diagram for the shower seat.
Operating Instructions
The FFanhia folding shower seat is designed for simple and convenient use:
- To Deploy: Gently pull the seat downwards until it locks into the horizontal position. Ensure it is fully extended and stable before sitting.
- To Fold Up: When not in use, lift the seat upwards. The unique folding mechanism allows it to fold flat against the wall at a 90° angle, saving significant space in your bathroom. The reserved distance between the seat plate and the wall prevents pinching.
Image: The shower seat in its deployed, ready-to-use position within a shower.
Image: An individual comfortably seated on the shower bench.
Maintenance
To ensure the longevity and appearance of your FFanhia shower seat, follow these maintenance guidelines:
- Cleaning: Wipe the seat regularly with a soft, damp cloth. For stubborn dirt, use a mild, non-abrasive cleaner. Avoid harsh chemicals or abrasive scrubbers, as they can damage the oak wood and its protective coating.
- Drying: After cleaning or use in the shower, ensure the seat is thoroughly dried to prevent water damage to the wood.
- Wood Care: The oak wood is treated with environmentally friendly baking painting and an environmentally friendly coating (wood wax oil process) for water resistance. While durable, prolonged exposure to standing water should be avoided.
- Hardware: Periodically check the hardware for any signs of rust or wear. If necessary, clean and dry the metal components.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Seat feels wobbly or unstable after installation. | Loose mounting screws; improper wall type; anchors not fully seated. | Ensure all screws are tightened. Verify the wall is solid and not hollow. Re-seat anchors if necessary. If the wall is hollow, the seat cannot be safely installed. |
| Difficulty folding or unfolding the seat. | Mechanism obstruction; dirt buildup; misaligned installation. | Check for any obstructions around the hinge mechanism. Clean any dirt or debris. Ensure the seat was installed level and correctly. |
| Wood appears discolored or damaged. | Prolonged water exposure; harsh cleaning agents. | Ensure the seat is dried after each use. Use only mild cleaners. For minor discoloration, consult a wood care specialist. |
Specifications
| Feature | Detail |
|---|---|
| Material | Oak, Hardware |
| Color | Wood |
| Feature | Foldable |
| Folding Angle | 90° (upward) |
| Process | Environmentally Friendly Baking Painting and Environmentally Friendly Coating |
| Mount Type | Wall Mounted |
| Assembly Required | Yes |
| Overall Load-capacity | 200 kg / 440.92 lbs |
| Board Thickness | 30 mm / 1.18 in |
| Single Strip Width | 70 mm / 2.76 in |
| Minimum Drilling Depth | 70 mm / 2.76 in |
| (Each) Decorative Cover Diameter | 10.8 cm / 4.25 in |
| Product Size (L x W) | 51 cm x 23 cm / 20.08 in x 9.06 in |
| Net Weight | 4.5 kg / 9.92 lbs |
| Gross Weight | 4.82 kg / 10.63 lbs |
Image: Product dimensions diagram.
Warranty and Support
For any questions, concerns, or support needs regarding your FFanhia 20in Wood Folding Shower Seat, please refer to the contact information provided with your purchase or visit the manufacturer's official website. While specific warranty details are not provided in this manual, please retain your proof of purchase for any warranty claims.
