Introduction
Thank you for choosing the Mastela Multi-Motion Baby Bassinet and Bouncer. This product is designed to provide a comfortable and secure environment for your infant, featuring automatic motion, soothing music, and convenient app control. Please read this manual thoroughly before assembly and use to ensure safe and proper operation.
Important Safety Information
WARNING: Failure to follow these warnings and instructions could result in serious injury or death.
- Always use the restraint system. Adjust to fit snugly.
- Never leave child unattended.
- Do not use this product once your child can sit up unaided, push up on hands and knees, or weighs more than 15 kg (33 lbs), whichever comes first.
- This product is not intended for prolonged periods of sleep.
- Always place the product on a firm, flat, level surface.
- Do not use near stairs, steps, or uneven surfaces.
- Keep away from open flames, heaters, or other sources of strong heat.
- Regularly inspect the product for loose fasteners, damaged joints, or broken parts. Do not use if any part is broken or missing.
- Only use replacement parts supplied or approved by the manufacturer.
- Ensure all assembly steps are completed correctly before placing a child in the product.
- This product is certified according to NM 300-1, NM 300-2, NM 300-3, and NM 16040. Certificate Number: 7990/2022-BRI-1.
Package Contents
Please check that all components are present before assembly. If any parts are missing or damaged, do not use the product and contact customer support.
- Bassinet/Bouncer Unit
- Base Stand
- Canopy with Mobile Toys
- Headrest Cushion
- Power Adapter and Cable
- Instruction Manual
Setup and Assembly
Follow these steps to assemble your Mastela Multi-Motion Baby Bassinet and Bouncer.
1. Attach the Base Stand
- Place the base stand on a flat, stable surface.
- Align the bassinet unit with the connection points on the base stand.
- Press firmly until you hear a click, indicating it is securely locked. Ensure there is no wobble.
Image 1: Fully assembled Mastela Multi-Motion Baby Bassinet and Bouncer in gray, showing the bassinet unit attached to the base stand with the canopy extended.
2. Install the Canopy and Mobile
- Attach the canopy to the designated slots on the bassinet unit.
- Ensure the mobile with toys is securely hanging from the canopy.
Image 2: Side view of the Mastela Multi-Motion Baby Bassinet and Bouncer with the canopy fully extended, providing shade and a cozy environment.
3. Secure the Headrest and Cushion
- Place the headrest cushion inside the bassinet for infant comfort.
- Ensure the main cushion is properly seated.
Image 3: An infant sleeping comfortably in the Mastela Multi-Motion Bassinet, showcasing the headrest and secure five-point harness.
4. Power Connection
Connect the power adapter to the designated port on the base unit and plug it into a standard electrical outlet. The unit is designed for energy efficiency via cable power.
Operating Instructions
Powering On/Off
Press the power button on the control panel located on the base unit to turn the device on or off.
Adjusting Recline Positions
The recline can be adjusted using the straps located on the sides of the bassinet unit. This allows for multiple positions, from a flat bassinet mode for sleeping to a more upright bouncer mode for playing or feeding. Ensure the child is not in the unit when adjusting the recline.
Image 4: Side view of the bassinet in a slightly reclined position, suitable for infants who are awake and observing their surroundings.
Image 5: Side view of the bassinet in a more upright bouncer position, ideal for playtime or feeding, demonstrating its versatility.
Automatic Swing and Motion
The unit features 7 motion options: 3 vertical (up and down) and 3 horizontal (side to side), plus a combination motion. Use the control panel or the Mastela Baby app to select your desired motion and intensity.
Timer Function
Set the automatic shut-off timer for 15, 30, 45, or 60 minutes using the control panel or the app. This feature helps conserve energy and provides a consistent soothing period.
Music Playback
Choose from 12 soothing melodies. Adjust the volume using the control panel or the Mastela Baby app to create a calming auditory environment for your child.
Mobile App Control (Mastela Baby App)
For full control, download the Mastela Baby app on your smartphone. The app allows you to:
- Adjust motion settings and intensity.
- Select and manage music playlists.
- Control volume levels.
- Set and modify the timer.
Image 6: A hand holding a smartphone displaying the Mastela Baby app interface, demonstrating remote control capabilities for the bassinet's functions.
Using the Canopy and Mobile
The adjustable canopy provides a cozy, shaded environment for rest. The attached mobile with two toys offers visual stimulation and entertainment for your child.
Safety Harness
Always secure your child with the five-point safety harness. Adjust the straps to ensure a snug and safe fit. The protective screen also adds an extra layer of safety.
Maintenance and Cleaning
Regular cleaning and maintenance will prolong the life of your Mastela Multi-Motion Baby Bassinet and Bouncer.
- Fabric Components: The headrest and dense cushion are removable and machine washable. Use a gentle cycle with cold water and mild detergent. Air dry or tumble dry on low heat.
- Frame and Plastic Parts: Wipe clean with a damp cloth and mild soap. Do not use abrasive cleaners or solvents.
- Storage: When not in use, store the product in a clean, dry place away from direct sunlight.
Troubleshooting
If you encounter any issues, please refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not power on. | Not plugged in; power outlet issue; damaged cable. | Ensure power adapter is securely plugged into both the unit and a working outlet. Check cable for damage. |
| Motion/Swing not working. | Weight limit exceeded; obstruction; incorrect setting. | Ensure child's weight is within 15 kg limit. Check for any obstructions. Verify motion settings on control panel or app. |
| App cannot connect to the unit. | Bluetooth/Wi-Fi issue; app not updated; unit not powered on. | Ensure unit is powered on. Check your phone's Bluetooth/Wi-Fi settings. Restart the app and the unit. Ensure app is updated to the latest version. |
| Music not playing or volume too low. | Volume setting too low; mute activated. | Adjust volume using control panel or app. Ensure mute function is not active. |
If the problem persists, please contact Mastela customer support for further assistance.
Product Specifications
- Brand: Mastela
- Model: Multi-Motion Baby Bassinet and Bouncer
- Color: Gray (Chumbo)
- Dimensions (L x W x H): 80 cm x 45.5 cm x 78 cm (approximately 31.5 in x 17.9 in x 30.7 in)
- Weight Capacity: Up to 15 kg (33 lbs)
- Materials: Thermoplastic Rubber, Metal, Polyvinyl Chloride (PVC), Polypropylene (PP), Polyester. Frame in Metal. Fabric in Polyester.
- Power Source: Cable with included power adapter
- Motion Options: 7 (3 vertical, 3 horizontal, 1 combination)
- Timer Settings: 15, 30, 45, 60 minutes
- Melodies: 12 soothing tunes
- Control: On-board control panel and Mastela Baby mobile application
- Certifications: NM 300-1, NM 300-2, NM 300-3, NM 16040. Certificate Number: 7990/2022-BRI-1.
Warranty and Support
For warranty information and customer support, please refer to the documentation provided at the time of purchase or contact your retailer. You may also visit the official Mastela website for further assistance.
Manufacturer: Mastela
