Moclever Manual Pole Saw 8.2-15.1FT Extendable Tree Pruner

Introduction

Thank you for choosing the Moclever Manual Pole Saw. This versatile 2-in-1 tool is designed for efficient and safe tree trimming, combining a saw and a pruner to reach high branches without the need for ladders. Constructed from durable fiberglass and SK5 alloy steel, it offers reliable performance for maintaining your garden and trees. Please read this manual thoroughly before assembly and operation to ensure safe and effective use.

Image: User operating the extendable pole saw for tree pruning.

Safety Information

WARNING: Always prioritize safety when operating this tool. Failure to follow safety instructions can result in serious injury.

• Always wear appropriate personal protective equipment (PPE), including the provided safety goggles and gloves, to protect your eyes and hands from debris and sharp blades.
• Ensure the pole saw is properly assembled and all connections are secure before use.
• Inspect the tool for any damage or loose parts before each use. Do not use if damaged.
• Maintain a stable footing and clear working area. Be aware of falling branches.
• Do not use the pole saw near power lines or electrical equipment.
• Keep bystanders, especially children and pets, away from the work area.
• Do not overreach. Always maintain proper balance.
• Use caution when handling sharp blades. Store the saw blade in its protective sleeve when not in use.
• Avoid using the tool in wet conditions or during strong winds.

Package Contents

Verify that all items listed below are included in your package:

• 1 x Top Pole
• 1 x Bottom Pole
• 2 x Middle Poles (for extension)
• 1 x High Branch Pruner with 13ft Nylon Rope
• 1 x Double-hooked Saw Blade with Handle Sleeve
• 1 x Double-hooked Saw Blade Replacement
• 1 Pair x Safety Goggles
• 1 Pair x Gloves
• Installation Tools (4 Screws + 4 Nuts)
• 1 x Oxford Fabric Storage Bag
• 1 x User Manual (this document)

Image: All components of the pole saw kit laid out, including poles, pruner, saw blades, and safety accessories.

Setup and Assembly

Follow these steps to assemble your Moclever Manual Pole Saw. Refer to the video below for visual guidance.

1. Pole Installation

1. Connect the pole sections by screwing them together. The threaded connections ensure a secure fit.
2. Add or remove middle poles to achieve the desired length, from 8.2ft to 15.1ft.

Image: Detail of the secure threaded connection for extending the pole.

2. Pruner Installation

1. Insert the pruner mechanism into the top pole.
2. Align the holes and secure the pruner to the pole using the provided 37mm screw and 7mm nut.
3. Further secure the pruner with two 23mm screws and 6mm nuts.

Image: Detailed view of the pruner's lever and pulley system.

3. Double-hooked Saw Blade Attachment

1. If attaching the saw blade to the pruner, align the saw blade with the designated holes on the pruner.
2. Secure the saw blade using the provided 13mm screw and 8mm nut.
3. For handheld use, remove the screw and nut from the handle, insert the saw blade, align one of the two holes on the top handle, and fix it with the screw and nut.

Image: The double-hooked saw blade with its ergonomic handle.

Operating Instructions

The Moclever Manual Pole Saw offers two primary functions: pruning and sawing.

Using the Pruner:

• Extend the pole to the desired length, ensuring all sections are securely locked.
• Position the pruner around the branch you wish to cut. The M-shaped scissors are suitable for branches up to 1.2 inches in diameter.
• Pull the 13ft thickened nylon rope to activate the lever mechanism, closing the pruner blades and cutting the branch.
• Ensure the branch falls in a safe direction, away from yourself and others.

Using the Saw Blade:

• For thicker branches, use the double-hooked saw blade. It can be attached to the pole or used handheld.
• When using with the pole, position the saw blade on top of the branch.
• Use a steady, back-and-forth motion to saw through the branch. The sharpened hook and sickle blade assist in gripping the branch and preventing slippage.
• Allow the saw's teeth to do the work; avoid excessive force.
• When using handheld, grip the ergonomic handle firmly and saw with controlled strokes.

Image: Demonstrating the sawing, trimming, and cutting capabilities of the tool.

Maintenance

• Cleaning: After each use, clean the blades and pruner mechanism to remove sap, dirt, and debris. A damp cloth is usually sufficient. For stubborn sap, use a specialized blade cleaner.
• Lubrication: Periodically apply a light oil to the moving parts of the pruner mechanism to ensure smooth operation.
• Sharpening: The saw blades are made from SK5 alloy steel and designed for durability. If the blades become dull over time, they can be sharpened by a professional or replaced with the provided spare blade.
• Storage: Disassemble the pole saw and store all components in the provided Oxford fabric storage bag. Store in a dry, safe place, out of reach of children.

Image: Pole saw components stored in the carrying bag for easy transport and organization.

Troubleshooting

• Difficulty extending/retracting poles: Ensure the threaded connections are clean and free of debris. Apply a small amount of lubricant if necessary.
• Pruner not cutting cleanly: Check for sap buildup on the blades and clean thoroughly. Ensure the rope is not frayed and the pulley system is operating smoothly.
• Saw blade dull: Replace with the spare blade or have the existing blade professionally sharpened.
• Loose connections: Periodically check and tighten all screws and nuts on the pruner and saw blade attachments.

Specifications

Warranty and Support

This product comes with a standard manufacturer's warranty against defects in materials and workmanship. For specific warranty details, claims, or technical support, please contact Moclever customer service through the retailer where the product was purchased or visit the official Moclever website. Keep your purchase receipt as proof of purchase.
