Oasesenergy 24V 200Ah LiFePO4 Lithium Battery User Manual

1. Introduction

This manual provides essential information for the safe and efficient use of your Oasesenergy 24V 200Ah LiFePO4 Lithium Battery. Please read this manual thoroughly before installation and operation. Keep it for future reference.

2. Safety Instructions

Observe the following safety precautions to prevent injury or damage to the battery and connected equipment:

• Do not short-circuit the battery terminals.
• Do not immerse the battery in water or expose it to excessive moisture.
• Do not expose the battery to fire or extreme heat.
• Use only compatible chargers designed for LiFePO4 batteries.
• Ensure proper ventilation during charging and discharging.
• Do not disassemble, puncture, or modify the battery.
• Keep the battery out of reach of children.
• Wear appropriate personal protective equipment (PPE) when handling the battery.
• Operating temperature range: -20°C to 60°C (-4°F to 140°F). Charging temperature range: 0°C to 45°C (32°F to 113°F).

3. Product Overview

The Oasesenergy 24V 200Ah LiFePO4 Lithium Battery is a high-performance, rechargeable power solution featuring Grade-A prismatic cells and an advanced 200A Battery Management System (BMS). It offers superior energy density, stability, and safety compared to traditional lead-acid batteries.

Figure 3.1: Oasesenergy 25.6V 200Ah LiFePO4 Battery. Dimensions: 523mm x 269mm x 222mm. Weight: 40kg. Terminal Specifications: M8. Max Energy: 5248Wh. BMS: 200A. Max Load Power: 5120Wh.

Figure 3.2: Grade A Cells and Smart 200A BMS. The BMS provides comprehensive protection including overcharge, overdischarge, overcurrent, short circuit, and high temperature protection. Expected lifespan is 4000-15000 cycles, or approximately 10 years.

Figure 3.3: Low Temperature Cut-off Protection. The battery features automatic cut-off for charging at 0°C (32°F) and discharging at -20°C (-4°F) to prevent damage in cold conditions.

Figure 3.4: Comparison with SLA Battery. The Oasesenergy 24V 200Ah LiFePO4 battery offers significantly longer lifespan (10+ years vs. 3 years), more cycles (4000-15000 vs. 300-500), and is approximately 1/3 the weight of a comparable lead-acid battery, while including a smart BMS for enhanced safety.

4. Setup

4.1 Initial Charging

Before first use, fully charge the battery using a compatible LiFePO4 charger. Ensure the charger's voltage and current settings match the battery's requirements.

4.2 Connection Instructions

Connect the battery to your system using appropriate cables and connectors. Ensure all connections are secure and correctly polarized (positive to positive, negative to negative) to prevent damage.

4.3 Parallel and Series Connection

This LiFePO4 battery supports both parallel and series connections for increased capacity or voltage:

• Parallel Connection: Connect batteries in parallel to increase total capacity while maintaining the same voltage. Ensure all batteries are at a similar state of charge before connecting.
• Series Connection: Connect batteries in series to increase total voltage. For example, two 24V batteries in series will create a 48V system. The battery supports up to 4 parallel and 2 series connections (4P2S) to achieve a 48V (51.2V) 820Ah battery bank with a maximum energy of 41.98 kWh.

Always consult a qualified electrician or refer to detailed wiring diagrams for complex configurations.

5. Operating Instructions

5.1 Bluetooth App Monitoring

The Oasesenergy LiFePO4 battery includes a built-in Bluetooth module, allowing real-time monitoring of battery data via a dedicated smartphone application. Download the Oasesenergy app from your device's app store.

1. Ensure Bluetooth is enabled on your smartphone.
2. Open the Oasesenergy app.
3. The app will automatically detect nearby Oasesenergy batteries. Select your battery from the list.
4. Monitor parameters such as State of Charge (SOC), voltage, current, and temperature. The Bluetooth range is typically 5-10 meters.

Figure 5.1: Bluetooth App Monitoring. The app provides real-time data including SOC, voltage, current, and temperature for convenient battery management.

5.2 Typical Applications

This battery is suitable for a wide range of deep cycle applications:

• RV and Camper: Provides reliable power for recreational vehicles.
• Marine: Ideal for trolling motors and other marine applications.
• Solar Systems: Excellent for off-grid or grid-tied solar energy storage.
• Emergency Power: Can serve as a backup power supply.
• Home Use: Powers various household appliances.

Figure 5.2: Wide Application Scenarios. The Oasesenergy battery is versatile for camping, RV travel, solar energy storage, and powering trolling motors.

Figure 5.3: Home and Outdoor Use. The battery can power appliances such as a coffee maker (800W for 6.4H), refrigerator (200W for 25.6H), heater (3000W for 1.7H), and air conditioner (1500W for 3.4H), based on its 5120Wh max energy output.

6. Maintenance

The Oasesenergy LiFePO4 battery requires minimal maintenance. Follow these guidelines for optimal performance and longevity:

• Regular Inspection: Periodically check battery terminals for corrosion or loose connections. Clean terminals if necessary.
• Storage: If storing the battery for an extended period, ensure it is charged to approximately 50-70% State of Charge (SOC) and stored in a cool, dry place away from direct sunlight and extreme temperatures. Recharge every 3-6 months to prevent deep discharge.
• Cleaning: Keep the battery casing clean and free from dust and debris. Use a dry cloth for cleaning.
• Avoid Deep Discharge: While the BMS protects against over-discharge, it is best practice to avoid consistently discharging the battery to its absolute minimum to maximize cycle life.

7. Troubleshooting

If you encounter issues with your Oasesenergy LiFePO4 battery, refer to the following common problems and solutions:

• Battery Not Charging:
  • Check all cable connections between the charger and the battery.
  • Ensure the charger is powered on and functioning correctly.
  • Verify that the charger is compatible with LiFePO4 batteries and its voltage settings are correct.
  • Check the battery temperature; charging is disabled below 0°C (32°F).
• Battery Not Discharging/No Power Output:
  • Check all cable connections to the load.
  • Verify the battery's State of Charge (SOC) using the Bluetooth app. The BMS will cut off discharge if the voltage is too low.
  • Ensure the load does not exceed the battery's maximum continuous discharge current (200A) or peak current.
  • Check the battery temperature; discharging is disabled below -20°C (-4°F) or above 60°C (140°F).
• Bluetooth App Not Connecting:
  • Ensure Bluetooth is enabled on your smartphone and the app has location permissions.
  • Make sure you are within the Bluetooth range (5-10 meters) of the battery.
  • Restart the app or your smartphone.
  • Ensure the battery is powered on.

If these steps do not resolve the issue, please contact Oasesenergy customer support.

8. Specifications

9. Warranty and Support

Oasesenergy provides a limited warranty for this product. Please refer to the warranty card included with your purchase or visit the official Oasesenergy website for detailed warranty terms and conditions.

For technical support, troubleshooting assistance, or warranty claims, please contact Oasesenergy customer service through the following channels:

• Website: Oasesenergy Official Store
• Email: [Insert Customer Support Email Here, if available]
• Phone: [Insert Customer Support Phone Number Here, if available]

When contacting support, please have your product model number (24-200) and purchase date available.
