Introduction
This manual provides essential information for the assembly, operation, maintenance, and safety of your CRADIAC Alpha PRO GEN 2 mountain bike. Please read this manual thoroughly before assembling or riding your bicycle to ensure proper function and safety. Retain this manual for future reference.
Product Features
The CRADIAC Alpha PRO GEN 2 is a high-performance mountain bike designed for versatility and durability. Key features include:
- Frame: 6061 Lightweight Aluminium Alloy Frame (18 Inch) with internal cabling for a clean aesthetic and protection.
- Fork: Alloy Zoom Masera Suspension Fork with Lockout feature to absorb shocks on varied terrains.
- Brakes: JAK Dual Disc Brakes for reliable stopping power in all conditions.
- Shifters: Shimano EF 500 21-speed shifters for precise gear transitions.
- Front Derailleur: Shimano Altus M310 for efficient front gear changes.
- Rear Derailleur: Shimano Acera M3020 for crisp and accurate rear gear shifts.
- Chain Wheel: Shimano 42/34/24T chain wheel for a wide range of gearing options.
- Freewheel: Shimano 7-speed freewheel for smooth gear changes.
- Wheels: 29-inch wheels with quick-release mechanism for easy removal and installation.
- Pedals: Sturdy Alloy Platform Pedals for superior grip.
- Seat: Memory Foam seat with quick-release for easy height adjustment.
Figure 1: Overview of CRADIAC Alpha PRO GEN 2 components, including Shimano shifters, Zoom Masera alloy lockout suspension, alloy frame with inner cabling, Shimano Acera M3020 rear derailleur, Shimano Altus M310 front derailleur, Shimano chainwheel, JAK dual disc brakes, and quick release wheel.
Safety Information
Always prioritize safety when riding your bicycle. Failure to follow safety guidelines can result in serious injury or death.
- Helmet Use: Always wear a properly fitted helmet that meets safety standards.
- Pre-Ride Check: Before each ride, check tire pressure, brake function, gear shifting, and ensure all quick releases are securely fastened.
- Visibility: Use front and rear lights, especially when riding in low light conditions. Wear bright clothing.
- Traffic Laws: Obey all local traffic laws, signs, and signals.
- Riding Conditions: Adjust your riding style to suit road conditions, weather, and your skill level. Avoid riding in adverse weather if possible.
- Braking: Practice using both front and rear brakes smoothly and effectively. Avoid sudden braking, especially with the front brake, which can cause loss of control.
- Maintenance: Regular maintenance is crucial for safe operation. Refer to the Maintenance section.
Setup and Assembly
Your CRADIAC Alpha PRO GEN 2 bicycle requires assembly. Assembly tools and instructions are included. It is recommended that assembly be performed by a qualified bicycle mechanic if you are unfamiliar with bicycle assembly.
Included Components:
- Bicycle Frame and partially assembled components
- Assembly instructions
- Assembly tools
General Assembly Steps:
- Unpacking: Carefully remove all components from the packaging. Inspect for any shipping damage.
- Handlebar Installation: Attach the handlebar to the stem, ensuring it is centered and tightened securely.
- Front Wheel Installation: Install the front wheel into the fork dropouts. Ensure the quick-release skewer is properly installed and tightened. Verify disc brake alignment.
- Seat Post and Saddle: Insert the seat post into the frame and adjust the saddle height. Secure with the quick-release lever.
- Pedal Installation: Identify left (L) and right (R) pedals. Thread the pedals into the crank arms. Note that the left pedal has a reverse thread. Tighten firmly.
- Brake Adjustment: Ensure both front and rear disc brakes are properly aligned and functioning. Adjust cable tension if necessary.
- Gear Adjustment: Check and adjust front and rear derailleurs for smooth and accurate shifting across all 21 speeds.
- Tire Inflation: Inflate tires to the recommended pressure indicated on the tire sidewall.
- Final Check: Double-check all bolts, quick releases, and components for tightness and proper function before the first ride.
Figure 2: Shimano shifters and quick release front wheel. Ensure shifters are correctly positioned and the quick release is securely fastened.
Figure 3: Quick release mechanism for seat height adjustment. Ensure the seat is at a comfortable and safe height for riding.
Operating Instructions
Gear Shifting (Shimano EF 500, Altus M310, Acera M3020):
Your bicycle is equipped with a 21-speed (3x7) Shimano gear system. Use the shifters on the handlebars to change gears.
- Right Shifter: Controls the rear derailleur (7 speeds). Use for fine-tuning speed and cadence. Shift to a lower gear (larger cog) for easier pedaling on inclines, and a higher gear (smaller cog) for faster speeds on flat or downhill terrain.
- Left Shifter: Controls the front derailleur (3 speeds). Use for larger changes in gearing, adapting to significant changes in terrain. Shift to a smaller chainring for climbing and a larger chainring for speed.
- Smooth Shifting: Always pedal lightly when shifting gears to avoid strain on the drivetrain components. Avoid shifting multiple gears at once, especially under heavy load.
Figure 4: Shimano Acera M3020 Rear Derailleur (top) and Shimano Altus M310 Front Derailleur (bottom). These components manage gear changes.
Figure 5: Shimano 42/34/24T Chainwheel (top) and the lightweight alloy frame with internal cable routing (bottom).
Braking (JAK Dual Disc Brakes):
Your bike is equipped with powerful JAK dual disc brakes. The right lever controls the rear brake, and the left lever controls the front brake.
- Balanced Braking: Apply both brakes simultaneously for optimal stopping power and control.
- Front Brake: Provides significant stopping power but can cause the front wheel to lock up or lift the rear wheel if applied too aggressively.
- Rear Brake: Helps control speed and stability. Less powerful than the front brake.
- Wet Conditions: Disc brakes perform well in wet conditions, but stopping distances may increase. Apply brakes earlier and more gently.
Suspension Lockout (Alloy Zoom Masera Fork):
The front suspension fork features a lockout mechanism, allowing you to switch between a rigid and active suspension setup.
- Active Mode: For off-road trails and rough terrain, the suspension absorbs bumps for a smoother ride and improved traction.
- Locked Out Mode: For smooth roads or climbing, locking out the suspension prevents energy loss from fork compression, making pedaling more efficient.
- Operation: Refer to the specific lockout lever on your fork for engagement and disengagement. Do not force the lever.
Maintenance
Regular maintenance ensures the longevity and safe operation of your CRADIAC Alpha PRO GEN 2 bicycle.
Daily Checks:
- Tire Pressure: Check and maintain recommended tire pressure.
- Brakes: Ensure brakes engage firmly and release completely.
- Quick Releases: Verify all quick releases (wheels, seat post) are securely tightened.
Weekly/Bi-Weekly Checks:
- Chain Lubrication: Clean and lubricate the chain regularly, especially after riding in wet or dusty conditions.
- Cleaning: Wash your bike with mild soap and water. Avoid high-pressure washers directly on bearings.
- Bolt Tightness: Check and tighten all accessible bolts (stem, handlebars, crank arms, seat post clamp).
Monthly/Quarterly Checks:
- Brake Pads: Inspect brake pads for wear and replace if necessary.
- Gear Adjustment: Fine-tune gear shifting if it becomes imprecise.
- Wheel Trueness: Check wheels for wobbles or damage.
- Professional Service: Consider a professional tune-up at least once a year, or more frequently with heavy use.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Gears not shifting smoothly | Cable tension incorrect, dirty/dry chain, bent derailleur hanger | Adjust shifter cable tension, clean and lubricate chain, inspect derailleur hanger for damage. |
| Brakes feel spongy or weak | Cable stretch, worn brake pads, contaminated rotors | Adjust brake cable tension, replace worn brake pads, clean rotors with disc brake cleaner. |
| Tires lose air quickly | Puncture, faulty valve, improperly seated tire bead | Inspect tire for punctures and repair/replace tube, check valve stem, ensure tire is seated correctly on the rim. |
| Creaking noises while pedaling | Loose pedals, bottom bracket issues, loose crank arms | Tighten pedals, check crank arm bolts. If noise persists, professional inspection of bottom bracket may be needed. |
Specifications
| Feature | Detail |
|---|---|
| Model | Alpha PRO Gen 2 |
| Bike Type | Mountain Bike |
| Frame Material | 6061 Aluminium Alloy |
| Frame Size | 18 Inches |
| Wheel Size | 29 Inches |
| Number of Speeds | 21 (3x7) |
| Fork | Alloy Zoom Masera Suspension with Lockout |
| Brakes | JAK Dual Disc Brakes |
| Shifters | Shimano EF 500 Trigger Shifters |
| Front Derailleur | Shimano Altus M310 |
| Rear Derailleur | Shimano Acera M3020 |
| Chain Wheel | Shimano 42/34/24T |
| Freewheel | Shimano 7-speed |
| Pedals | Alloy Platform |
| Seat | Memory Foam with Quick Release |
| Item Weight | 15.18 Kilograms |
| Maximum Weight Recommendation | 110 Kilograms |
| Minimum User Height | 5.8 Feet |
| Manufacturer | Tungsten Consumer Goods Pvt Ltd |
| Country of Origin | India |
Figure 6: Bike Size Chart for CRADIAC Alpha PRO GEN 2. Recommended for age 15+, unisex, with an 18-inch frame, suitable for riders 5.8 ft and above.
Warranty and Support
Warranty Information:
Your CRADIAC Alpha PRO GEN 2 bicycle comes with the following manufacturer's warranty:
- Frame: Lifetime warranty against manufacturing defects.
- Other Parts: 6-month warranty against manufacturing defects.
What is not covered: Damage resulting from improper assembly, accidents, misuse, neglect, or lack of proper maintenance is not covered under warranty.
Customer Support:
For warranty claims, technical assistance, or any product-related inquiries, please contact the manufacturer:
Manufacturer: Tungsten Consumer Goods Pvt Ltd
Please refer to your purchase documentation for specific contact details or visit the official CRADIAC website.
