ERGOSEAT Armless Home Office Desk Chair (Model 5130013) Instruction Manual

Introduction

This manual provides detailed instructions for the assembly, operation, maintenance, and troubleshooting of your ERGOSEAT Armless Home Office Desk Chair. Please read this manual thoroughly before assembly and use to ensure proper function and safety.

Safety Information

Always follow the assembly instructions provided to ensure the chair is assembled correctly and safely. Failure to do so may result in instability or malfunction. Do not exceed the maximum weight capacity of 250 pounds. Ensure all screws and bolts are tightened securely before use and periodically check for looseness.

Package Contents

Before beginning assembly, verify that all components are present:

Office Chair components (Seat, Backrest, Base, Gas Lift, Wheels)
Hardware Pack (Screws, Washers, Allen Wrench)
Instruction Manual (this document)

Setup and Assembly

Follow these steps to assemble your ERGOSEAT office chair. It is recommended to assemble the chair on a soft, clean surface to prevent damage.

Attach Wheels to Base: Insert each wheel caster into the holes on the chair base until they click securely into place.
Insert Gas Lift: Place the gas lift cylinder into the center hole of the chair base.
Attach Seat Plate: Secure the seat plate to the underside of the seat cushion using the provided screws. Ensure the lever is facing the front of the seat.
Connect Backrest to Seat: Align the backrest support frame with the pre-drilled holes on the back of the seat cushion and attach using the specified screws.
Assemble Seat onto Gas Lift: Carefully place the assembled seat and backrest onto the gas lift cylinder, ensuring it is centered and stable.
Final Check: Verify all screws are tightened and the chair is stable before use.

Diagram showing the dimensions of the ERGOSEAT office chair and its weight capacity. — **Figure 1: Product Dimensions and Weight Capacity.** This image illustrates the chair's measurements, including seat width (16.93"), seat depth (15.35"), backrest width (15.75"), and adjustable height range (29.92"-33.86"). It also indicates a maximum weight capacity of 250 lbs.

Close-up views of the chair's stable components including the base, wheels, and height adjustment lever. — **Figure 2: Excellent Stability Features.** This image highlights the robust metal base, smooth-rolling casters, and the gas lift mechanism with its adjustment lever, demonstrating the chair's stable construction.

Operating Instructions

Your ERGOSEAT chair is designed for ease of use and ergonomic support.

Height Adjustment: To adjust the seat height, pull the lever located under the seat upwards. While seated, pull the lever up to lower the seat. To raise the seat, stand up and pull the lever up. Release the lever at the desired height.
360° Swivel: The chair features a 360° swivel function, allowing for easy rotation without moving the base.
Rolling Casters: The silent swivel casters allow for smooth movement across various surfaces, including hard floors, carpet, and tile.

A person sitting comfortably in the light grey ERGOSEAT office chair at a desk, demonstrating proper posture. — **Figure 3: Ergonomic Use.** This image shows an individual using the chair at a desk, highlighting its ergonomic design for comfortable and supported seating during work.

Two chairs, one pushed under a desk and one pulled out, illustrating the space-saving armless design. — **Figure 4: Space-Saving Design.** This image demonstrates how the armless design allows the chair to be easily pushed under a desk, optimizing space in smaller environments.

Close-up images showing the bounce-back resilience cushion and the easy-to-clean PU leather material of the chair. — **Figure 5: High-Level Seating Comfort.** This image details the chair's high-density, thickened sponge cushion for resilience and the double-needle PU leather upholstery, emphasizing its comfort and ease of cleaning.

Maintenance

Proper maintenance will extend the life and appearance of your ERGOSEAT chair.

Cleaning: Wipe clean with a damp cloth. For tougher stains on the PU leather, use a mild soap solution and wipe dry immediately. Avoid harsh chemicals or abrasive cleaners.
Hardware Check: Periodically check all screws and bolts to ensure they remain tight. Re-tighten as necessary to maintain stability.
Caster Care: Keep the wheels free of debris (hair, dust) to ensure smooth rolling.

Troubleshooting

If you encounter issues with your chair, refer to the following common problems and solutions:

Problem	Possible Cause	Solution
Chair is unstable or wobbly.	Loose screws or incorrect assembly.	Check all assembly points and tighten screws. Ensure the gas lift is fully seated in the base.
Height adjustment not working.	Gas lift malfunction or lever not engaged.	Ensure the lever is pulled completely. If the issue persists, the gas lift may need replacement.
Wheels do not roll smoothly or make noise.	Debris in casters or damaged wheels.	Clean any hair or debris from the wheel casters. If wheels are damaged, consider replacement.
Squeaking noises during use.	Loose connections or friction between parts.	Tighten all screws. Apply a small amount of silicone lubricant to moving parts if necessary, avoiding contact with upholstery.

Specifications

Feature	Detail
Brand	ERGOSEAT
Model Number	5130013
Color	Light Grey
Product Dimensions (D x W x H)	15.35"D x 16.93"W x 29.92"-33.86"H (Adjustable)
Seat Depth	15.35 inches
Chair Backrest Width	15.75 inches
Item Weight	16.66 pounds
Maximum Weight Capacity	250 pounds
Material	PU Leather, High-Density Foam, Sponge, Metal Base
Special Features	Adjustable Height, Ergonomic, Rolling, Scratch Resistant, Space Saving, 360° Swivel
Surface Recommendation	Hard Floor
UPC	840198431886

Warranty Information

For specific warranty details regarding your ERGOSEAT Armless Home Office Desk Chair, please refer to the warranty card included with your purchase or contact ERGOSEAT customer support directly. Standard return policies may apply as per the retailer's terms of sale.

Customer Support

If you have any questions, require assistance with assembly, or need to report a missing or damaged part, please contact ERGOSEAT customer support. Contact information can typically be found on the product packaging or the official ERGOSEAT website.
