SPACEREST Portable Shower for Camping with 5-Gallon Water Jug Instruction Manual

Introduction

Thank you for choosing the SPACEREST Portable Shower. This versatile system is designed for outdoor enthusiasts, pet owners, and outdoor workers, providing convenient rinsing in various scenarios such as camping, beaches, boats, gardens, and work sites. This manual provides essential information for the safe and effective use of your portable shower.

What's in the Box

• 1x Shower Head
• 1x 5-Gallon (19L) Water Jug (Food-grade PE material)
• 1x Pump
• 2x 2200mAh Rechargeable Batteries
• 1x Mesh Bag
• 1x Hose
• 1x Multi-use Hook
• 1x Charging Cable

Image: All components of the SPACEREST Portable Shower Kit, including the 5-gallon water jug, shower head, pump, batteries, hose, mesh bag, multi-use hook, and charging cable, displayed on a grassy surface.

Setup Instructions

1. Charge Batteries: Ensure both 2200mAh batteries are fully charged using the provided charging cable.
2. Fill Water Jug: Open the large cap on the 5-gallon water jug and fill it with water. The food-grade PE material is safe for various uses.
3. Insert Pump: Push the soft rubber plug on the pump hose to the red line. Immerse the pump into the water jug.
4. Secure Pump: Press the soft rubber plug into the water outlet of the bucket. Tighten the custom lid on the water outlet of the bucket to ensure a tight seal.
5. Connect Shower Head: Connect the shower head to the hose.
6. Connect Battery: Connect a charged battery to the pump and lock it in place.
7. Power On: Press and hold the power button on the pump for 3 seconds to turn it on.

Image: A visual guide showing six steps for assembling the SPACEREST Portable Shower Kit, from inserting the pump into the jug to connecting the battery and shower head.

Operating Instructions

• Power On/Off: Press and hold the power button on the pump for 3 seconds to turn the unit on or off.
• Adjust Water Flow: The shower head features an adjustable flow control. Use the lever on the shower head to switch between different spray patterns or to temporarily stop the water flow to conserve water.
• Hands-Free Use: Utilize the multi-use hook to hang the shower head from a tree branch, vehicle, or other suitable support for hands-free operation.
• Water Temperature: The product operates within a water temperature range of 50°F to 131°F (10°C to 55°C). Do not use water outside this range.

Image: A man showering outdoors using the SPACEREST Portable Shower, with the water jug and pump system set up in the back of an SUV, demonstrating its use for personal hygiene in remote locations.

Image: A man washing fruit with the portable shower, showcasing the food-grade nature of the 5-gallon water jug and its utility for cleaning produce outdoors.

Maintenance

• Cleaning: After each use, rinse the water jug, pump, and hose with clean water. Ensure all components are dry before storing.
• Battery Care: Store batteries in a cool, dry place. Recharge them periodically if not used for extended periods to maintain battery health.
• Storage: The portable shower can be fixed on the water jug for easy storage. Use the large mesh bag to keep all accessories organized and prevent loss.

Image: The portable shower system demonstrating its easy storage feature, with the hose, shower head, and other accessories neatly packed into a mesh bag that attaches securely to the 5-gallon water jug.

Troubleshooting

• No Water Flow:
  • Check if the pump is fully submerged in water.
  • Ensure the battery is charged and properly connected.
  • Verify the power button on the pump is pressed and held for 3 seconds to activate.
  • Inspect the hose and shower head for any blockages.
• Water Leakage:
  • Ensure the custom lid on the water jug is tightened securely.
  • Check that the soft rubber plug is properly seated in the water outlet.
  • Verify the silicone waterproof ring is correctly positioned.
• Weak Water Pressure:
  • Check the battery charge level; low battery can affect pump performance.
  • Ensure the pump intake is not obstructed by debris.

Specifications

Important Safety Information

• Do not soak the battery in water.
• The product only operates within the water temperature range of 50°F to 131°F (10°C to 55°C).
• Keep out of reach of children.
• Ensure all connections are secure before operation to prevent leaks or electrical hazards.

Warranty and Support

For warranty information, technical support, or any inquiries regarding your SPACEREST Portable Shower, please refer to the manufacturer's official website or contact their customer service directly. Keep your purchase receipt for warranty claims.
