1. Introduction
Thank you for choosing the Könighaus Smart Dual Infrared Heater 450W. This manual provides essential information for the safe and efficient use of your new heating device. Please read these instructions carefully before installation and operation, and retain them for future reference.
This infrared heater, Model KJM-19, offers versatile heating solutions with its 450W power output. It features intelligent control options, including a remote control and Wi-Fi connectivity for smartphone app management. The design allows for both freestanding and wall-mounted installation, and it includes an integrated towel rail for added functionality.
The image displays the Könighaus 450W infrared heater, showcasing its smart control options: a physical remote control and a smartphone application for Wi-Fi connectivity.
2. Safety Instructions
To ensure safe operation and prevent damage, please observe the following safety guidelines:
- Always connect the heater to a properly grounded electrical outlet.
- Do not cover the heater. Covering can lead to overheating and fire hazards.
- Maintain a safe distance from flammable materials such as curtains, furniture, and bedding.
- This appliance is equipped with double overheating protection. If the heater overheats, it will automatically shut off. Disconnect from power and allow it to cool before restarting.
- The heater has an IP44 rating, providing protection against splashing water. It is suitable for use in bathrooms but must not be directly exposed to water jets or submerged.
- Ensure children are supervised when near the heater.
- Do not insert objects into the heater's openings.
- If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or similarly qualified persons to avoid a hazard.
This image illustrates the safety features of the Könighaus infrared heater, including IP44 splash protection and double overheating protection, making it suitable for family environments.
3. Package Contents
Please check that all items are present and undamaged:
- Könighaus Smart Dual Infrared Heater (450W, White)
- Remote Control
- Freestanding Feet (2x)
- Wall Mounting Kit (screws, wall plugs)
- Integrated Towel Rail
- Instruction Manual (this document)
4. Setup and Installation
4.1 Freestanding Installation
- Carefully unpack the heater and all accessories.
- Attach the two freestanding feet to the designated slots on the bottom of the heater using the provided screws. Ensure they are securely fastened.
- Place the heater on a flat, stable, and level surface, ensuring it is not near any flammable materials.
The heater is shown in a freestanding configuration, equipped with its integrated towel rail, providing both warmth and a convenient drying solution.
4.2 Wall Mounting Installation
- Choose a suitable wall location. Ensure there is adequate clearance around the heater (minimum 10 cm from sides, top, and bottom) and that the wall material can support the heater's weight.
- Use the provided mounting template (if included) or measure and mark the drilling points on the wall.
- Drill holes at the marked positions and insert the wall plugs.
- Secure the mounting brackets to the wall using the provided screws.
- Carefully lift the heater and hang it onto the secured wall brackets. Ensure it is firmly seated and level.
- Double-check that the heater is securely fastened to prevent accidental detachment.
The image shows the Könighaus infrared heater securely mounted on a wall, highlighting its sleek design and space-efficient installation.
4.3 Towel Rail Installation
- Locate the designated attachment points for the towel rail on the heater.
- Align the towel rail with these points and secure it using the provided hardware.
- Ensure the towel rail is stable and can support the weight of towels.
5. Operating Instructions
5.1 Power Connection
Plug the heater's power cord into a standard 230V electrical outlet. The heater will enter standby mode.
5.2 Using the Remote Control
The included remote control allows for convenient adjustment of the heater's settings:
- Power Button: Press to turn the heater ON or OFF.
- Temperature Adjustment: Use the '+' and '-' buttons to increase or decrease the desired room temperature.
- Timer Function: Activate the timer to set a specific operating duration for the heater. Refer to the remote's specific icons for timer settings.
- Mode Selection: If available, use the mode button to switch between different heating modes (e.g., comfort, eco).
5.3 Wi-Fi App Control
For advanced control and scheduling, connect your heater to the Könighaus smartphone app:
- Download the 'Könighaus' app from your smartphone's app store (available for iOS and Android).
- Register for a new account or log in if you already have one.
- Follow the in-app instructions to add a new device. This typically involves putting the heater into pairing mode (refer to the heater's display or manual for specific steps) and connecting it to your home 2.4 GHz Wi-Fi network.
- Once connected, you can use the app to:
- Turn the heater ON/OFF.
- Adjust the target temperature.
- Set daily or weekly heating schedules.
- Monitor the heater's status.
- Access additional smart features.
This image demonstrates the ease of controlling the heater, with a user operating it via both the included remote control and the dedicated Wi-Fi smartphone application.
6. Maintenance
Regular maintenance ensures optimal performance and longevity of your heater:
- Cleaning: Before cleaning, always disconnect the heater from the power supply and allow it to cool completely. Wipe the surface with a soft, damp cloth. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the surface.
- Storage: If the heater will not be used for an extended period, disconnect it from the power supply, clean it, and store it in a dry, dust-free environment.
- Inspection: Periodically check the power cord and plug for any signs of damage. If damage is found, do not use the heater and contact customer support.
7. Troubleshooting
If you encounter issues with your heater, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Heater does not turn on. | No power supply; Remote control battery low; Heater in standby mode. | Check power cord connection and wall outlet. Replace remote control batteries. Press the power button on the remote or app. |
| No heat output. | Temperature setting too low; Overheating protection activated. | Increase the target temperature. Disconnect power, allow to cool for 30 minutes, then restart. Check for obstructions. |
| Wi-Fi connection fails. | Incorrect Wi-Fi password; Heater out of range; Router issues. | Ensure correct Wi-Fi password. Move heater closer to router. Restart router. Ensure 2.4 GHz network is used. |
| Heater emits unusual smell. | New product smell (normal); Dust accumulation. | Initial odor is normal and will dissipate. Clean the heater as per maintenance instructions. If smell persists or is strong, disconnect and contact support. |
If the problem persists after attempting these solutions, please contact Könighaus customer support.
8. Specifications
Detailed technical specifications for the Könighaus Smart Dual Infrared Heater 450W, Model KJM-19:
| Feature | Specification |
|---|---|
| Brand | KÖNIGHAUS |
| Model | KJM-19 |
| Color | White |
| Product Dimensions (L x W x H) | 70 x 40 x 1.3 cm |
| Weight | 5 kg |
| Wattage | 450 W |
| Voltage | 230 V |
| Protection Class | IP44 (Splash water protected) |
| Special Features | Wi-Fi App Control, Remote Control, Integrated Towel Rail, Double Overheating Protection, Wall Mountable, Freestanding |
| Form Factor | Pedestal / Wall-mounted |
| Indoor/Outdoor Use | Indoor |
A detailed table outlining various technical specifications for Könighaus infrared heaters, such as surface temperature, weight, protection class, power calculation, dimensions, and TÜV certification numbers for different models.
9. Warranty and Support
Könighaus products are manufactured with high-quality standards. For warranty information, claims, or technical support, please refer to the documentation included with your purchase or visit the official Könighaus website. Please have your model number (KJM-19) and purchase details ready when contacting support.
