Samsung AI Control Washer-Dryer User Manual

Introduction

This manual provides essential information for the safe and efficient operation of your Samsung AI Control WD11DG6B85BKU3 washer-dryer. Please read it thoroughly before using the appliance and keep it for future reference.

Figure 1: Samsung AI Control WD11DG6B85BKU3 Washer-Dryer. This image shows the front of the appliance, highlighting its white body, black control panel, and large black porthole.

The Samsung AI Control WD11DG6B85BKU3 is an advanced front-load freestanding washer-dryer designed for efficiency and convenience. It features AI Control for personalized washing, an auto-dose system, disinfecting steam, and a Super Speed cycle. With a washing capacity of 11 kg and drying capacity of 6 kg, it is equipped with a durable inverter motor and smart connectivity via the SmartThings app.

Safety Information

Always follow basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, and injury to persons.

• Ensure the appliance is properly grounded.
• Do not operate the appliance if the power cord is damaged.
• Keep children and pets away from the appliance during operation.
• Do not wash or dry articles that have been cleaned in, washed in, soaked in, or spotted with combustible or explosive substances.
• Refer to the installation guide for proper water and electrical connections.

Setup

Unpacking and Placement

• Remove all packaging materials and transit bolts from the rear of the appliance.
• Place the washer-dryer on a firm, level surface. Adjust the leveling feet to ensure stability.
• Ensure adequate space around the appliance for ventilation and maintenance.

Water and Electrical Connection

• Connect the water inlet hose to a cold water tap and the appliance's inlet valve. Ensure connections are tight to prevent leaks.
• Position the drain hose into a standpipe or sink, ensuring it is securely fixed to prevent dislodging during operation.
• Plug the power cord into a grounded electrical outlet. The appliance requires a 230V power supply.

Operating Instructions

Control Panel Overview

The AI Control panel features a full-touch display for intuitive operation. Use the rotary dial to select cycles and the touch buttons for options and settings.

Figure 2: AI Control Panel. This image displays the user interface, including the central rotary dial and the digital touch screen, which provides cycle information and options.

Loading Laundry and Detergent

• Open the door and load laundry, ensuring not to overload the drum. The SpaceMax design allows for 11 kg of washing capacity in a standard 8 kg footprint.
• The AI Wash with Auto-Dose system automatically dispenses the correct amount of detergent and softener based on load weight and soil level. Ensure the auto-dose drawer is filled.

Figure 3: Auto-Dose System. This image illustrates the automatic detergent dispensing mechanism, which ensures optimal detergent usage for each wash.

Figure 4: EcoDoser Mechanism. A detailed view of the auto-dose drawer, showing how detergent is stored and released.

Figure 5: AI Wash Sensing. This diagram illustrates the five intelligent sensors (wash load, water level, fabric, soil level, and detergent level sensing) that optimize washing performance.

Wash Cycles and Options

The appliance offers 6 wash cycles and 7 option cycles. Select the appropriate cycle using the rotary dial.

• AI Control: Learns your washing habits and recommends optimal cycles.
• Super Speed: Washes 5 kg of laundry in just 39 minutes, ideal for daily loads.
• Disinfecting Steam: Eliminates 99.9% of bacteria and inactivates allergens by releasing steam from the bottom of the drum.
• AI Ecobubble: Generates bubbles that penetrate fabrics faster, allowing effective cleaning even at low temperatures.
• Less Microfiber Cycle: Reduces microplastic release by up to 54% during washing.

Figure 6: Disinfecting Steam Wash. This image illustrates the steam wash process, highlighting its effectiveness in eliminating bacteria and allergens for a hygienic clean.

Figure 7: Less Microfiber Cycle. This image demonstrates the environmental benefit of the Less Microfiber cycle, showing a reduction in microplastic dispersion.

SmartThings Connectivity and AI Energy Mode

Connect your washer-dryer to the SmartThings app for enhanced control and monitoring.

• The SmartThings app allows you to choose cycles, schedule washes, and troubleshoot issues remotely.
• AI Energy Mode monitors and reduces energy consumption by up to 70%, providing consumption data and bill estimates through the app.

Figure 8: SmartThings App Integration. This image shows a user interacting with the SmartThings app on a smartphone, demonstrating remote control and monitoring capabilities for the appliance.

Figure 9: AI Energy Mode Monitoring. This image displays the SmartThings app interface showing energy consumption data and estimated costs, illustrating how AI Energy Mode helps manage power usage.

Maintenance

Drum Cleaning

Regularly run the Drum Clean cycle to remove detergent residue and dirt buildup, ensuring optimal hygiene and performance.

Figure 10: Drum Clean Feature. This image depicts the self-cleaning function of the drum, showing water jets cleaning the interior to prevent mold and odor buildup.

Filter Cleaning

Clean the debris filter periodically to prevent blockages and maintain efficient drainage. Refer to the full manual for detailed instructions on accessing and cleaning the filter.

Exterior Cleaning

Wipe the exterior of the appliance with a soft, damp cloth. Do not use abrasive cleaners or solvents.

Troubleshooting

For more complex issues, refer to the comprehensive troubleshooting section in the full user manual or contact customer support.

Specifications

Figure 11: Energy Efficiency Label. This label indicates the appliance's energy ratings for both washing (A) and drying (D).

Figure 12: Digital Inverter Motor. This image highlights the durable Digital Inverter Motor, which comes with a 20-year warranty.

Warranty and Support

Your Samsung AI Control WD11DG6B85BKU3 washer-dryer comes with a comprehensive warranty. The Digital Inverter Motor is specifically guaranteed for 20 years.

• For warranty claims or technical support, please contact Samsung Customer Service.
• Have your model number (WD11DG6B85BKU3) and purchase date ready when contacting support.
• Visit the official Samsung website for the latest support information, FAQs, and to download the full user manual.
