1. Introduction
Thank you for choosing the Lorus Classic Man Quartz Watch, model RU411AX9. This manual provides essential information for the proper setup, operation, and maintenance of your watch. Please read these instructions carefully to ensure optimal performance and longevity of your timepiece.
2. Safety Information
- Avoid exposing the watch to extreme temperatures (above 60°C / 140°F or below 0°C / 32°F) or sudden temperature changes.
- Keep the watch away from strong magnetic fields, as these can affect the accuracy of the quartz movement.
- Do not expose the watch to strong chemicals, solvents, or detergents, as they may damage the case, strap, or seals.
- Avoid strong impacts or drops, which can damage the internal mechanism or external components.
- Ensure the crown is always pushed in completely to maintain water resistance.
3. Product Overview
The Lorus Classic Man Quartz Watch RU411AX9 features a classic analog display with a durable stainless steel case and bracelet. Familiarize yourself with the main components:
- Dial: The watch face displaying the time.
- Hour Hand: Indicates the hour.
- Minute Hand: Indicates the minute.
- Second Hand: Indicates the second.
- Crown: The knob on the side of the watch used for setting the time.
- Case: The main body of the watch, made of stainless steel.
- Bracelet: The stainless steel band that secures the watch to your wrist.
Image 3.1: Front view of the Lorus Classic Man Quartz Watch RU411AX9, showing the black dial, hands, and stainless steel bracelet.
4. Setup
4.1 Setting the Time
- Pull out the crown: Gently pull the crown located on the side of the watch outwards to the first click position. The second hand will stop.
- Set the time: Rotate the crown in either direction to move the hour and minute hands to the desired time.
- Push in the crown: Once the time is set, push the crown back in completely to its normal position. The second hand will resume movement. Ensure the crown is fully pushed in to maintain water resistance.
5. Operating
5.1 Water Resistance
Your Lorus RU411AX9 watch is water resistant up to 100 meters (10 ATM). This means it is suitable for swimming, snorkeling, and showering. However, it is not suitable for scuba diving or high-impact water sports.
- Important: Do not operate the crown or push buttons (if any) while the watch is wet or submerged in water.
- After exposure to saltwater, rinse the watch with fresh water and dry it thoroughly with a soft cloth.
6. Maintenance
6.1 Cleaning
To maintain the appearance of your watch:
- Wipe the case and bracelet regularly with a soft, dry cloth.
- For stubborn dirt, use a slightly damp cloth and then dry thoroughly. Do not use harsh chemicals.
6.2 Battery Replacement
The watch is powered by a quartz movement, which requires a battery. The typical battery life is approximately 2-3 years. When the battery runs low, the second hand may start to move in two-second intervals (End-of-Life indicator). It is recommended to have the battery replaced by a qualified watch technician to ensure proper sealing and maintain water resistance.
6.3 Storage
When not wearing your watch, store it in a cool, dry place, away from direct sunlight, extreme temperatures, and strong magnetic fields.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Watch has stopped | Depleted battery | Replace the battery (recommended by a professional). |
| Watch is losing or gaining time significantly | Crown not fully pushed in; exposure to strong magnetic fields; internal movement issue. | Ensure crown is fully pushed in. Keep away from magnetic sources. If problem persists, consult a professional watch repair service. |
| Condensation visible under the crystal | Temperature change; water resistance compromised. | Immediately take the watch to a professional watch repair service to prevent further damage. |
8. Specifications
| Brand | Lorus |
| Model Number | RU411AX9 |
| Movement Type | Quartz |
| Display Type | Analog |
| Case Material | Stainless Steel |
| Case Diameter | 43 Millimeters |
| Case Thickness | 11 Millimeters |
| Band Material | Stainless Steel |
| Band Width | 18 Millimeters |
| Dial Color | Black |
| Dial Window Material | Mineral Glass |
| Water Resistance Depth | 100 Meters (10 ATM) |
| Clasp Type | Pin Buckle |
| Special Features | Second Hand |
| Power Source | Battery Powered |
9. Warranty and Support
For warranty information and customer support, please refer to the warranty card included with your purchase or contact the retailer where the watch was purchased. Keep your proof of purchase for any warranty claims. For service or repairs, it is recommended to contact an authorized Lorus service center or a qualified watch technician.
