VOYZ 15" Portable Bluetooth Speaker System Instruction Manual

1. Introduction

Thank you for choosing the VOYZ 15" Portable Bluetooth Speaker System. This powerful and versatile audio system is designed for various applications, including parties, events, karaoke, DJing, and presentations. It features a 15-inch subwoofer, 1000W output, Bluetooth connectivity, USB/SD MP3 player, and comes with a tripod stand and two wireless microphones. Please read this manual thoroughly before operating the unit to ensure proper use and to maximize its performance.

2. Safety Information

• Power Source: Use only the specified power adapter. Ensure the voltage matches the requirements of your region.
• Ventilation: Do not block any ventilation openings. Maintain adequate space around the unit for proper airflow.
• Water and Moisture: Do not expose the unit to rain, moisture, or excessive humidity. Keep liquids away from the speaker.
• Heat Sources: Keep the unit away from heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
• Cleaning: Unplug the unit from the power outlet before cleaning. Use a dry, soft cloth only.
• Servicing: Do not attempt to service this product yourself. Refer all servicing to qualified service personnel.
• Battery Safety: The speaker contains a rechargeable battery. Do not expose the battery to extreme temperatures or dispose of it in fire.

3. Package Contents

Verify that all items listed below are included in your package:

• 1 x VOYZ 15" Portable Bluetooth Speaker System
• 2 x Wireless Microphones
• 1 x Remote Control
• 1 x Heavy Duty Tripod Stand
• 1 x Power Adapter
• 1 x User Manual (this document)

Image 3.1: Contents of the VOYZ 15" Portable Bluetooth Speaker System package.

4. Product Overview

4.1 Front Panel

Image 4.1: Front view of the speaker, showcasing its main features.

4.2 Rear Panel and Controls

The rear panel houses all the input/output connections and control knobs for the speaker system.

Image 4.2: Rear panel with detailed control layout.

• USB/TF/FM/Bluetooth Module: For media playback and mode selection.
• Digital Display: Shows current mode and track information.
• Master Volume: Adjusts overall speaker volume.
• Graphic Equalizer: For fine-tuning audio frequencies.
• Mic Input (XLR/1/4"): Connect wired microphones.
• Line Input (RCA/XLR): Connect external audio sources.
• Speaker Out: Connect a passive speaker.
• DC Power Supply: For charging and external power.
• Battery Level Indicator: Shows current battery charge.
• Power Switch: Turns the unit on/off.

5. Setup

5.1 Initial Charging

Before first use, fully charge the speaker's internal battery. Connect the power adapter to the DC Power Supply input on the rear panel and plug it into a wall outlet. The battery indicator will show charging status.

5.2 Assembling the Tripod Stand

1. Unfold the legs of the tripod stand until they are fully extended and stable.
2. Adjust the height of the stand using the locking pin and knob. Ensure the pin is securely engaged.
3. Carefully lift the speaker and place its bottom pole mount onto the top pole of the tripod stand. Ensure it is seated firmly.

Image 5.1: Speaker mounted on the tripod stand.

6. Operating Instructions

6.1 Powering On/Off

Locate the Power Switch on the rear panel and toggle it to the 'ON' position to power on the speaker. Toggle to 'OFF' to power down.

6.2 Bluetooth Connection

1. Turn on the speaker. The digital display will show the current mode.
2. Press the 'MODE' button on the speaker or remote control until 'BLUE' or 'BLUETOOTH' appears on the display.
3. On your Bluetooth-enabled device (smartphone, tablet, etc.), search for available Bluetooth devices.
4. Select 'VOYZ SPEAKER' (or similar name) from the list.
5. Once connected, you will hear a confirmation tone, and you can now play audio wirelessly through the speaker.

6.3 USB/SD Card Playback

1. Insert a USB flash drive or SD card (with MP3/WMA audio files) into the corresponding slot on the rear panel.
2. The speaker should automatically switch to USB/SD mode and begin playing. If not, press the 'MODE' button to select USB or SD.
3. Use the playback controls (Play/Pause, Next, Previous) on the speaker or remote to navigate your music.

6.4 Microphone Usage

The system includes two wireless microphones for karaoke or public speaking.

1. Ensure the wireless microphones have fresh batteries installed.
2. Turn on the microphones using their power switches.
3. Adjust the 'MIC VOL' knob on the speaker's rear panel to control the microphone volume.
4. Use the 'ECHO' and 'DELAY' controls to add effects to the microphone sound.

Image 6.1: Wireless microphones and remote control.

6.5 True Wireless Stereo (TWS) Function

The TWS function allows you to connect two VOYZ AB515-PL speakers wirelessly for a true stereo sound experience.

Image 6.2: Explanation of True Wireless Stereo (TWS).

1. Ensure both VOYZ AB515-PL speakers are powered on and in Bluetooth mode.
2. On one of the speakers (this will be the master speaker), press and hold the 'TWS' button (or a dedicated TWS button if available, otherwise the Play/Pause button for a few seconds) until you hear a pairing tone.
3. The two speakers will automatically connect to each other. Once connected, you will hear a confirmation sound.
4. Now, connect your Bluetooth device to the master speaker as described in Section 6.2. Audio will play through both speakers in stereo.

7. Maintenance

7.1 Cleaning

To clean the speaker, unplug it from the power source. Use a soft, dry cloth to wipe down the exterior surfaces. Do not use abrasive cleaners, waxes, or solvents as they may damage the finish.

7.2 Storage

When not in use for extended periods, store the speaker in a cool, dry place, away from direct sunlight and extreme temperatures. It is recommended to fully charge the battery every 3-6 months to maintain its lifespan.

8. Troubleshooting

9. Specifications

10. Warranty and Support

VOYZ products are designed for reliability and performance. For warranty information, technical support, or service inquiries, please refer to the warranty card included with your product or visit the official VOYZ website. Keep your purchase receipt as proof of purchase for any warranty claims.

For further assistance, you may contact VOYZ customer support through their official channels.
