1. Introduction
Thank you for choosing the besrey Baby Bassinet Bedside Sleeper. This manual provides essential information for the safe assembly, operation, maintenance, and troubleshooting of your new bassinet. Please read these instructions carefully before assembly and keep them for future reference. This bassinet is designed to provide a safe and comfortable sleeping environment for infants from 1 to 5 months, with a maximum weight capacity of 19.8 lbs (9 kg).
2. Safety Information
WARNING: Failure to follow these warnings and instructions could result in serious injury or death.
- Always ensure the bassinet is placed on a firm, horizontal level floor.
- Do not use the bassinet if any parts are broken, torn, or missing. Contact besrey customer service for replacement parts. Do not substitute parts.
- The bassinet is designed for infants aged 1-5 months and weighing up to 19.8 lbs (9 kg). Discontinue use when the infant begins to push up on hands and knees, or has reached the maximum weight, whichever comes first.
- To prevent falls, do not use this product when the infant is able to roll over, pull up, or push up on hands and knees.
- Always ensure the bassinet is securely attached to the adult bed when used in bedside sleeper mode.
- Only use the mattress provided by the manufacturer. Do not add a second mattress, pillow, comforter, or padding.
- Keep all cords, strings, and electrical wires away from the bassinet to avoid strangulation hazards.
- This bassinet meets ASTM/CPSIA/CCPSA safety standards.
For detailed safety regulations, refer to the Canadian Cribs, Cradles, and Bassinets Regulations. The bassinet features two sewn sides to minimize safety risks, ensuring the mattress support is always at a safe height relative to the side walls.
Image: Illustration of safety standards compliance and the bassinet's design with fixed side walls for enhanced safety, showing relevant certification documents.
3. Components List
Please check that all components are present before assembly:
- Bassinet Frame (Pre-assembled main structure)
- Mattress (3D breathable cotton with memory foam layer)
- Support Legs with Swivel Wheels (2 units)
- Connecting Bar
- Storage Pockets (Integrated into bassinet fabric)
- Safety Straps for Bedside Use
- Instruction Manual (This document)
4. Setup and Assembly
Follow these steps to assemble your besrey Baby Bassinet:
- Unpack Components: Carefully remove all parts from the packaging.
- Attach Support Legs: Insert the support legs into the designated slots on the bassinet frame until they click securely into place. Ensure the wheels are facing outwards.
- Connect Stabilizer Bar: Attach the connecting bar between the two support legs at the bottom. This provides additional stability.
- Insert Mattress: Place the provided mattress firmly into the bassinet sleeping area. Ensure it lies flat and fits snugly.
- Adjust Height: Use the height adjustment buttons on the side of the bassinet legs to set the desired height. There are 7 height positions to match various adult bed heights (27.5" to 32.2" from floor to top of adult mattress).
- Bedside Sleeper Setup (Optional): If using as a bedside sleeper, position the bassinet next to your bed. Lower the side panel by releasing the locking mechanism (if applicable to your model, note: some models may not have a drop-down side). Secure the bassinet to your bed frame using the provided safety straps to prevent any gap between the bassinet and your bed.
Image: The besrey Baby Bassinet fully assembled and positioned next to an adult bed, demonstrating its bedside sleeper functionality.
Image: Close-up of the bassinet's leg showing the 7 height adjustment levels and measurements, indicating compatibility with different bed heights.
5. Operating Instructions
5.1 Adjusting Height
To adjust the bassinet's height, locate the adjustment buttons on each leg. Press the buttons and slide the bassinet frame up or down to one of the 7 available positions. Ensure both sides are adjusted to the same height for stability. The bassinet is compatible with adult beds ranging from 27.5 inches to 32.2 inches in height (from floor to top of adult mattress).
5.2 Moving the Bassinet
The bassinet is equipped with 360° silent swivel wheels for easy mobility. To move the bassinet, simply unlock the wheel brakes by pressing down on the brake levers. Once moved to the desired location, press the brake levers again to lock the wheels and ensure the bassinet remains stationary.
Image: The bassinet showing its 360-degree swivel casters with integrated brakes, highlighting the ease of movement and locking mechanism.
5.3 Using Mesh Pockets
The bassinet features convenient mesh storage pockets on the side. These pockets are ideal for keeping small essentials such as feeding bottles, pacifiers, burp cloths, or small toys within easy reach.
Image: Close-up view of the bassinet's side, showcasing the integrated mesh pockets filled with baby essentials like a bottle and diapers.
6. Maintenance and Care
- Cleaning: Wipe the bassinet frame with a dry cloth. For fabric parts, spot clean with mild soap and water. Do not use abrasive cleaners or bleach.
- Mattress Care: The mattress cover can be removed for cleaning. Follow the care label instructions on the mattress.
- Inspection: Regularly inspect the bassinet for any signs of wear, damage, or loose parts. Ensure all screws and fasteners are tight.
- Storage: When not in use, the bassinet can be folded for compact storage. Store in a cool, dry place away from direct sunlight.
7. Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Bassinet is unstable. | Legs not fully engaged; height not even; connecting bar loose. | Ensure legs are clicked into place. Adjust both sides to the same height. Tighten connecting bar. |
| Wheels not locking. | Brake levers not fully pressed down. | Press down firmly on the brake levers until they click into the locked position. |
| Mattress does not lie flat. | Incorrect placement or foreign object underneath. | Remove mattress, check for obstructions, and reinsert ensuring it is flat and snug. |
| Difficulty adjusting height. | Buttons not fully pressed; mechanism jammed. | Ensure buttons are fully depressed. Check for any obstructions in the adjustment mechanism. |
8. Specifications
- Model: BR-BDC07
- Brand: besrey
- Color: Warm Gray
- Product Dimensions (Assembled): 91 cm (L) x 57 cm (W) x 84 cm (H) / 35.8 in (L) x 22.4 in (W) x 33.1 in (H)
- Sleeping Area Dimensions: 35.5 in (L) x 20.5 in (W) x 15 in (H)
- Mattress Dimensions: 34.65 in (L) x 20.1 in (W) x 1 in (H)
- Material: Aviation-grade Aluminum, Steel-alloy, Breathable Mesh Fabric, Cotton Mattress
- Item Weight: 7.67 kg (16.9 lbs)
- Maximum Weight Recommendation: 9 kg (19.8 lbs)
- Recommended Age: 1-5 months
- Height Adjustment: 7 positions, compatible with adult beds 27.5" - 32.2" tall.
- Special Features: Adjustable Height, Foldable, 360° Swivel Wheels with Brakes, Mesh Pockets, Breathable Fabric.
- Safety Standards: ASTM/CPSIA/CCPSA compliant.
Image: Technical drawing showing the detailed dimensions of the bassinet, including overall size, sleeping area, and mattress size.
9. Warranty and Support
For warranty information, product support, or to order replacement parts, please contact besrey customer service. Refer to the contact information provided with your product packaging or visit the official besrey website.
Manufacturer: FUJIAN BESREY BABY PRODUCTS CO.,LTD.
Place of Business: Stiger Industry Zone, Rongqian High-Tech, Fuqing City, Fujian Province, China
For further assistance, you may also visit the besrey Store on Amazon.
