1. Introduction
This manual provides essential information for the safe operation, assembly, maintenance, and troubleshooting of your Gyroor Electric Scooter with Seat or URBANMAX C1 Electric Scooter with Seat. Please read this manual thoroughly before first use to ensure proper function and safety.
Both scooter models feature a 450W powerful motor, capable of reaching a maximum speed of 15.5 mph. The Gyroor model offers a range of up to 20 miles, while the URBANMAX C1 model extends to 22 miles on a single charge. Both are equipped with an adjustable seat for comfortable riding, suitable for users from 5'1" to 6'1" tall, and support a maximum weight of 265 pounds. The foldable handlebar design allows for easy storage and portability.
Image: Overview of both Gyroor and URBANMAX C1 electric scooters, highlighting their design and features.
2. Safety Information
Your safety is paramount. Always adhere to the following guidelines:
- Wear a Helmet: Always wear a certified helmet and other protective gear (knee pads, elbow pads) when riding.
- Local Laws: Familiarize yourself with and obey all local traffic laws and regulations regarding electric scooter use.
- Weight Limit: Do not exceed the maximum weight capacity of 265 pounds.
- Weather Conditions: Avoid riding in wet conditions, heavy rain, snow, or on icy surfaces.
- Pre-Ride Check: Before each ride, inspect the brakes, tires, and all fasteners to ensure they are secure and in good working order.
- Braking: Use both front and rear brakes for effective and controlled stopping. The Gyroor model features dual disc brakes, while the URBANMAX C1 has a front disc brake and rear drum brake.
- Awareness: Be aware of your surroundings, pedestrians, and other vehicles. Ride defensively.
- Age Recommendation: Suitable for users 12 years old and above.
3. Package Contents
Upon opening the package, verify that all components are present and undamaged:
- Electric Scooter (Gyroor or URBANMAX C1 model)
- Adjustable Seat
- Rear Basket
- Charger
- User Manual
- Assembly Tools (if required)
4. Setup and Assembly
Follow these steps to assemble your electric scooter:
- Unfold the Scooter: Carefully unfold the main frame and secure the handlebar stem in the upright position. Ensure the exclusive bar lock is engaged to prevent accidental dislodging.
- Attach the Handlebar: Insert the handlebar into the stem and secure it firmly using the provided fasteners. Ensure all cables are clear and not pinched.
- Install the Seat: Attach the adjustable seat post into the designated slot on the scooter frame. Adjust the seat height to a comfortable riding position and tighten the quick-release lever or bolt.
- Mount the Rear Basket: Secure the rear basket to the designated mounting points on the scooter's rear frame using the provided hardware.
- Initial Charge: Before first use, fully charge the scooter's battery. Refer to the 'Charging the Battery' section under Maintenance.
Image: Gyroor Electric Scooter with its digital display, illustrating the operational interface.
Image: URBANMAX C1 Electric Scooter with its digital display, illustrating the operational interface.
5. Operating Instructions
Learn how to safely operate your electric scooter:
- Power On/Off: Press and hold the power button on the display unit to turn the scooter on or off. The display will show speed, battery level, and mileage.
- Acceleration: Use the throttle lever or button (depending on model) to accelerate. Start slowly and gradually increase speed.
- Braking: Apply the brake levers on the handlebars to slow down or stop. The scooter features effective dual disc brakes (Gyroor) or front disc and rear drum brakes (URBANMAX C1) for reliable stopping power.
- Riding Position: Utilize the comfortable, breathable seat for extended rides. The 12-inch thick tires and 9.5-inch wide deck contribute to a stable and comfortable experience.
- Folding: To fold the scooter for storage or transport, disengage the bar lock and carefully fold the handlebar stem down towards the deck. Ensure it latches securely.
Image: Multiple scenarios of individuals using the Gyroor electric scooter, highlighting its adaptability for commuting and leisure.
Image: Multiple scenarios of individuals using the URBANMAX C1 electric scooter, highlighting its adaptability for commuting and leisure, with SGS certification.
6. Maintenance
Regular maintenance ensures the longevity and safe operation of your scooter:
- Charging the Battery: Connect the charger to the scooter's charging port and then to a power outlet. The indicator light on the charger will change color when fully charged. Do not overcharge.
- Tire Pressure: Regularly check the tire pressure of the 12-inch tires. Maintain the recommended PSI (refer to the tire sidewall or scooter specifications) for optimal performance and range.
- Cleaning: Wipe the scooter with a damp cloth. Do not use high-pressure water jets or immerse the scooter in water.
- Brake Inspection: Periodically check the brake pads and cables for wear and proper adjustment. Ensure brakes respond effectively.
- Fasteners: Check all screws, bolts, and quick-release mechanisms regularly to ensure they are tight and secure.
- Storage: Store the scooter in a cool, dry place away from direct sunlight and extreme temperatures. If storing for an extended period, charge the battery to about 50-70% and recharge every 30-60 days.
7. Troubleshooting
Common issues and their potential solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Scooter does not turn on | Low battery; Loose connection; Faulty power button | Charge the battery; Check all cable connections; Contact support if button is faulty |
| Reduced range/speed | Low tire pressure; Overload; Battery degradation; Riding uphill frequently | Inflate tires to recommended PSI; Reduce load; Battery replacement may be needed over time; Adjust riding habits |
| Brakes not effective | Worn brake pads; Loose brake cable; Misaligned calipers | Inspect and replace brake pads; Adjust brake cable tension; Realign calipers or seek professional help |
| Unusual noises | Loose components; Debris in wheels/motor; Worn bearings | Check all fasteners; Clean wheels and motor area; Contact support for bearing issues |
If you encounter issues not listed here or if solutions do not resolve the problem, please contact Gyroor customer support.
8. Specifications
Key technical specifications for the Gyroor Electric Scooter with Seat and URBANMAX C1 Electric Scooter with Seat:
| Feature | Specification |
|---|---|
| Brand | Gyroor |
| Color | Black |
| Motor Power | 450W |
| Max Speed | 15.5 mph |
| Max Range (Gyroor) | Up to 20 Miles |
| Max Range (URBANMAX C1) | Up to 22 Miles |
| Weight Limit | 265 Pounds |
| Wheel Size | 12 Inches |
| Wheel Material | Polyurethane |
| Frame Material | Metal |
| Handlebar Type | Adjustable |
| Brake Style (Gyroor) | Dual Disc Brake |
| Brake Style (URBANMAX C1) | Front Disc Brake, Rear Drum Brake |
| Special Features | Foldable, Lightweight, Seat, Rear Basket |
| Recommended Uses | Transportation for teens and adults |
Image: Detailed view of the Gyroor scooter's 450W motor and rear wheel.
Image: Detailed view of the URBANMAX C1 scooter's 450W motor and rear wheel, noting UL2272 certification.
9. Warranty and Support
Your Gyroor Electric Scooter with Seat and URBANMAX C1 Electric Scooter with Seat come with a Limited Warranty. Please retain your proof of purchase for warranty claims.
For technical support, warranty inquiries, or replacement parts, please visit the official Gyroor website or contact their customer service department. Refer to the contact information provided with your product packaging.
For more information, you can visit the Gyroor Store on Amazon.
