QiMH RGB Floor Lamp Instruction Manual

1. Introduction

This manual provides detailed instructions for the assembly, operation, and maintenance of your QiMH RGB Floor Lamp. This 36W LED standing lamp features three independent, rotatable light heads, offering versatile lighting options including RGB colors, multiple color temperatures, and stepless dimming. It can be controlled via both a remote and touch interface, making it suitable for various environments such as living rooms and bedrooms.

Image: The QiMH RGB Floor Lamp in a room setting, with a hand holding the remote control, demonstrating its smart features.

2. Package Contents

Please ensure all components are present before proceeding with assembly:

• QiMH RGB Floor Lamp (main body with 3 light heads)
• Lamp Base
• Remote Control
• Power Cable
• User Manual (this document)

3. Setup and Assembly

Follow these steps to assemble your QiMH RGB Floor Lamp:

1. Unpack Components: Carefully remove all parts from the packaging and lay them out on a clean, flat surface.
2. Attach Base: Screw the lamp pole securely into the lamp base. Ensure it is tightened to prevent wobbling.
3. Connect Power Cable: Insert the power cable into the designated port at the base of the lamp.
4. Position Lamp: Place the assembled lamp in your desired location, ensuring it is on a stable and level surface.
5. Plug In: Connect the power cable to a standard electrical outlet (AC 100-240V).

Image: A visual representation of the lamp's dimensions, showing a height of 68 inches and a base diameter of 9.8 inches.

4. Operating Instructions

4.1 Remote Control Operation

The included remote control provides comprehensive control over the lamp's functions. Ensure the remote has working batteries.

Image: A detailed diagram illustrating the buttons and functions of the remote control for the QiMH RGB Floor Lamp.

• ON/OFF Button: Short press to turn all 3 lights ON/OFF. Long press for stepless dimming.
• Brightness +/- (BRT+/-): Adjust the brightness level from 10% to 100%.
• Color Temperature Switching (CCT): Cycle through 2700K (Warm White), 4000K (Natural Light), 5000K (Bright White), and 6500K (Refreshing White).
• RGB Switching (RGB): Switch between various RGB colors and 10 fixed color options.
• Mode Switch (M): Short press to cycle through 8 dynamic modes (e.g., gradient, jumping, breathing).
• Night Light Mode: Activates a soft 2700K light setting.
• Reading Mode: Activates a 4000K light setting suitable for reading.
• 1H (One-hour Timing Function): Sets a 1-hour auto-off timer.
• L1, L2, L3 Buttons: Individually control (turn ON/OFF and dim) each of the three lamp heads.

4.2 Touch Control Operation

The lamp also features touch controls located on the main pole:

• Power Button (Top): Short press to turn ON/OFF. Long press for stepless dimming.
• Color Switching Button (Middle): Short press to cycle through color temperatures (2700K, 4000K, 5000K, 6500K) and RGB colors.
• Mode Switching Button (Bottom): Short press to cycle through dynamic lighting modes.

4.3 Adjustable Lamp Heads

Each of the three lamp heads can be adjusted independently to direct light as needed:

• Rotation: Each head can rotate up to 350 degrees horizontally.
• Vertical Adjustment: Each head can be adjusted 180 degrees vertically (up and down).

Image: A close-up view of the lamp heads demonstrating their 350-degree rotation and 180-degree vertical adjustment capabilities.

4.4 Timer and Memory Function

• 1-Hour Timer: Press the "1H" button on the remote to activate a 60-minute auto-off timer.
• Memory Function: The lamp will remember your last brightness and color settings when turned off and on again, ensuring consistent lighting.

Image: The lamp in a bedroom setting, illustrating the 1-hour timer for auto-off and the memory function for retaining last settings, ideal for bedtime.

5. Maintenance

To ensure the longevity and optimal performance of your QiMH RGB Floor Lamp, follow these maintenance guidelines:

• Cleaning: Disconnect the lamp from the power source before cleaning. Use a soft, dry cloth to wipe down the lamp pole and light heads. Do not use abrasive cleaners or solvents, as they may damage the finish.
• Dust Removal: Regularly dust the lamp to prevent accumulation, which can affect light output and appearance.
• Integrated LED Source: The light fixtures on this lamp belong to an integrated LED source and cannot be individually replaced. If a light fixture malfunctions, the entire lamp may require servicing or replacement.
• Remote Control Battery: If the remote control's responsiveness decreases, replace its batteries. Refer to the remote control's battery compartment for the correct battery type.

6. Troubleshooting

If you encounter issues with your QiMH RGB Floor Lamp, refer to the following common problems and solutions:

7. Specifications

8. Important Notes
