QFP Split King Adjustable Bed Frame - Instruction Manual

1. Product Overview

The QFP Split King Adjustable Bed Frame is an ergonomic electric smart bed base designed for enhanced comfort and support. It features independent head and foot incline adjustments, quiet dual motors, and multiple preset positions including Anti-Snore and Zero-Gravity. This bed frame is compatible with most mattress types, such as memory foam, latex, gel, and hybrid mattresses.

Image 1.1: Adjustable head and foot incline with dimensions and 1000 lbs weight capacity.

2. Safety Information

• Do not exceed the maximum weight capacity of 1000 lbs.
• Be cautious of sharp edges during assembly and use.
• Always follow the assembly instructions to prevent instability or collapse.
• Keep children and pets away from moving parts during operation.
• Ensure all electrical connections are secure and away from moisture.

3. Package Contents

Before beginning assembly, ensure all parts are present and accounted for. Refer to the detailed parts list in your physical manual. Key components include:

• Bed Frame Sections (A1-A4, C1-C5, D1-D4)
• Dual Motors (x2)
• Control Box
• Wireless Remote Control
• Power Cord and Transformer
• Retainer Bars (x2)
• Adjustable Legs (Short and Long options)
• Hardware Package (bolts, washers, nuts, Allen wrenches)

Image 3.1: Detailed view of the hardware package, including various bolts, washers, and tools.

4. Setup and Assembly

The QFP Adjustable Bed Frame is designed for straightforward assembly. Follow these steps carefully. An assembly video is provided for visual guidance.

Assembly Steps:

1. Unpack Components: Carefully remove all components from the packaging. Lay them out on a clean, flat surface. Verify all parts against the parts list in your manual.
2. Attach Rollers (Step 2 in video): Secure the rollers (G4) to the designated points on the frame sections (A3).
3. Connect Frame Sections (Step 3-4 in video): Use bolts (G3, G7) and washers to connect the main frame sections. Ensure all connections are tight and secure.
4. Assemble Slat Supports (Step 5-6 in video): Attach the slat support bars (C1-C5) using the provided hardware (G1, G2). Ensure they are correctly oriented for left and right sides.
5. Install Bed Base Panels (Step 7-8 in video): Place the bed base panels (D1-D4) onto the frame. Secure them using bolts (G8).
6. Attach Crossbars (Step 9 in video): Connect the crossbars to the frame, ensuring they align with the pre-drilled holes.
7. Secure Side Brackets (Step 10 in video): Attach the side brackets (A4) to the frame using bolts (G2).
8. Install Motors (Step 11 in video): Carefully attach the two linear actuator motors (Carton F) to the designated points on the bed frame using the provided pins. Ensure the motor cables are routed neatly.
9. Connect Control Box (Step 12 in video): Mount the control box (Carton G) to the underside of the bed frame. Connect the motor cables to the appropriate ports (Back and Foot) on the control box. Connect the extension cord and power cord to the transformer, then plug the transformer into the control box.
10. Attach Legs (Step 13 in video): Screw the desired height legs (short or long) into the corner and center support points of the bed frame. Ensure they are tightened securely.
11. Install Retainer Bars (Step 14 in video): Insert the retainer bars into the designated holes at the foot of the bed to prevent the mattress from sliding.

5. Operating Instructions

Your QFP Adjustable Bed Frame is operated using a wireless remote control. Familiarize yourself with the remote's functions to customize your comfort.

Image 5.1: Wireless remote control with buttons for Anti-Snore, Yoga, Flat, TV, Zero Gravity, and memory presets.

Remote Control Functions:

• Head Up/Down: Adjusts the head section incline.
• Foot Up/Down: Adjusts the foot section incline.
• Anti-Snore: Elevates the head slightly to help reduce snoring.
• Zero-Gravity (ZG): Positions the body to relieve pressure on the back and improve circulation.
• TV/Yoga: Pre-set positions for watching television or engaging in light yoga/stretching.
• Flat: Returns the bed to a completely flat position.
• Memory Presets (M): Allows you to save your favorite custom positions for quick access. To set a memory position, adjust the bed to your desired position, then press and hold the 'M' button until the bed beeps or the light flashes.

6. Key Features

• Powerful Dual Motors: Equipped with two reliable and quiet 6000N dual motors, providing reinforced thrust and structural stability. Supports up to 1000 lbs.
• Ultimate Comfort & Adjustability: Independent head incline (0-65 degrees) and foot incline (0-65 degrees) for personalized comfort. Features memory function to save preferred positions.
• Versatile & Health Benefits: Helps alleviate issues such as snoring, sleep apnea, asthma, discomfort during pregnancy, back pain, and acid reflux. Offers a zero-gravity experience.
• Split King Design: Can be combined from two Twin XL bases to create a Split King setup, allowing independent control for each side.
• Under-Bed Clearance: Provides 12 inches of clearance for convenient storage.

Image 6.1: Illustration of the electric bed frame highlighting the powerful motor and reinforced metal support.

Image 6.2: Visual representation of the health benefits and comfort provided by the adjustable bed frame, including 12-inch under-bed clearance.

Image 6.3: Mattress compatibility with memory foam, latex, gel, and hybrid types.

7. Maintenance

To ensure the longevity and optimal performance of your QFP Adjustable Bed Frame, follow these simple maintenance guidelines:

• Cleaning: Wipe the frame with a damp cloth to remove dust and debris. Avoid using harsh chemicals or abrasive cleaners that could damage the finish.
• Inspections: Periodically check all bolts and connections to ensure they remain tight. Re-tighten if necessary.
• Motor Care: Keep the motor areas free from obstructions. Do not attempt to lubricate the motors or internal components.
• Cable Management: Ensure all power cords and motor cables are securely fastened and not pinched or tangled.

8. Troubleshooting

If you encounter any issues with your adjustable bed frame, refer to the following common troubleshooting steps:

• No Power/No Movement:
  • Check if the power cord is securely plugged into a working electrical outlet.
  • Ensure the power cord is properly connected to the transformer and the transformer to the control box.
  • Verify that the motor cables are correctly plugged into the control box.
  • Check for any tripped circuit breakers in your home.
• Remote Not Responding:
  • Replace the batteries in the remote control.
  • Ensure there are no obstructions between the remote and the control box.
  • If the remote is paired, try re-pairing it according to the instructions in your physical manual.
• Unusual Noises:
  • Check for any loose bolts or connections and tighten them.
  • Ensure no objects are caught in the moving parts of the bed frame.
• Uneven Movement:
  • Verify that the bed frame is on a level surface.
  • Check that the motors are correctly installed and aligned.

If the issue persists after attempting these steps, please contact QFP customer support for further assistance.

9. Specifications

10. Warranty and Support

For warranty information or technical support, please refer to the contact details provided in your product packaging or visit the official QFP website. Keep your purchase receipt as proof of purchase for any warranty claims.
