ZSHINE Motorized Blackout Roller Blinds Instruction Manual

1. Introduction

This manual provides comprehensive instructions for the installation, operation, and maintenance of your ZSHINE Motorized Blackout Roller Blinds. These blinds are designed to offer 100% blackout, water-proof properties, and easy washability, making them suitable for various applications including bedrooms, offices, and commercial spaces.

Key Features:

• Material: 100% full blackout polyester, water-proof and easily washable.
• Motorized Operation: Available with various motor options (TQL25, ZM25-EAZ, AM25-Matter, ZM27-E) compatible with different smart home systems.
• Customizable: Made to order to fit specific window dimensions.
• Easy Installation: Includes all mounting accessories and instructions.
• Rechargeable: Features a rechargeable motor, with an optional solar panel for sustainable charging.
• Smart Home Integration: Depending on the motor, compatible with Alexa, Google Home, and HomeKit.

2. Package Contents

Before beginning installation, please ensure all components are present:

• Motorized Blackout Roller Blind Unit
• Remote Control (pre-set)
• Mounting Hardware (brackets, screws, wall anchors)
• User Manual (this document)
• Type C Cable + Charging Adapter (for charging)
• Optional: Solar Panel

Image: Included accessories, showing mounting brackets, screws, and wall anchors.

3. Installation

3.1. Measuring Your Window

Accurate measurement is crucial for proper fit and function. There are two main installation types: Internal and External.

Image: Detailed diagrams illustrating how to measure window width and height for both internal and external mounting, including considerations for clearance and extension.

Internal Installation:

• Width: Measure at least 3 points (top, mid, bottom) of the window net width. Use the minimum measurement (A, B, C) as the Order Width (End-to-end width). Attention: Do not remove any size in width. The installation clearance will be considered by the manufacturer.
• Height: Measure the net height of the window. Ensure a minimum depth (D) of 2 1/2 inches.

External Installation:

• Width: Measure the window net width and consider an extra 6 inches extension totally in width. Net width + 6" = Order Width (End-to-end width). Attention: The width extension needs to be considered by the customer.
• Height: Measure the net height of the window and consider an extra 8 inches extension totally in height.

3.2. Mounting Options and Valances

The blinds offer various valance and bottom rod options to suit your aesthetic and functional needs.

Image: Visual representations of various valance types (Square V2 Minimalist, Curve white S2, Simple rolling, Beam simple rolling) and bottom rod types (Type A Streamlined water-drop, Type B, Type C, Type D) with dimensions.

Ensure you select the appropriate mounting type (Inside Mount is standard) and valance/bottom rod options as per your order.

Image: Comparison of standard roll and reverse roll configurations, illustrating how the fabric rolls off the tube and their respective dimensions.

Consider the roll type (Standard or Reverse) based on your window frame and desired aesthetic. The measurement for multiple shades side by side is the same as the measurement of one, and you do not need additional reduction in width generally.

Image: Visual comparison between a blind installed with no shading slot and one with a shading slot (between 0.1 to 1.2 inches), demonstrating the light gap.

Note the presence or absence of a shading slot, which affects the light gap at the sides of the blind.

4. Operation

4.1. Remote Control

Your ZSHINE Motorized Blackout Roller Blind comes with a pre-set remote control for immediate use. The remote allows you to raise, lower, and stop the blinds at any desired position.

Image: A white remote control resting on a ZSHINE motorized roller blind, demonstrating its primary function.

Image: A split image showing a hand holding the remote control, with the left side depicting the blind in a blackout state and the right side showing the blind raised to reveal the window view.

4.2. Motor Types and Smart Home Compatibility

ZSHINE offers various motor options, each with different features and smart home compatibility. Please refer to the motor type you selected for specific integration details.

Image: A table comparing four motor codes (TQL25, ZM25-EAZ, AM25-Matter, ZM27-E) based on smart control requirements (bridge hub, direct compatibility), rolling speed, noise level, battery capacity, manual handling when powered off, and auto stop with resistance.

TQL25 Motor:

Image: Diagram showing the TQL25 motor, which is rechargeable and has 3 stopping positions. It requires an optional Smart Hub to link to devices and is compatible with all versions of Alexa & Google Home (not included) via app control for professional timing, voice control, and scene control.

ZM25-EAZ Motor (More Smarter):

Image: Diagram showing the ZM25-EAZ motor, which is rechargeable and COM Smart. It can work directly with 5 Alexa models (Echo 4th Gen, Echo Plus (2nd Gen.), Echo Studio, Echo Show 10 (3rd Gen.), Echo Show 8 (2nd Gen.)) without a separate hub. For other Alexa versions, a Smart Bridge (Zigbee Hub, optional) is required.

AM25-Matter Motor:

Image: Diagram showing the AM25-Matter motor, which is rechargeable. It requires a Matter Hub (any smart device with Thread Border Router capability) to add the shades to HomeKit/Alexa/Google App directly. It uses the Matter over Thread protocol for seamless integration with HomeKit, Alexa, Google Assistant, and more.

ZM27-E Motor (Strong Practicability):

Image: Diagram showing the ZM27-E motor, which has a noise level of 20-30dB, battery capacity of 1200+ runs, and rolling speed of 120-180RPM. It supports manual handling when powered off and auto stop with resistance. It requires an optional Smart Hub to link to devices and is compatible with all versions of Alexa & Google Home (not included) via app control for professional timing, voice control, and scene control.

For voice control, ensure your motor is properly linked to your smart home system (e.g., Alexa, Google Home). You can then use commands like "Alexa, open the Curtains" or "Alexa, open the roller shades."

Image: A person and a dog on a couch, with an Amazon Echo device nearby, illustrating voice control of the blinds via Alexa. A text bubble shows "Alexa, open the Curtains".

5. Charging and Power

Your motorized blinds are rechargeable. You can charge them using the provided Type C cable and charging adapter, or a power bank. An optional solar panel is also available for continuous charging.

Image: Diagrams illustrating three charging methods: Type C Cable + Charging Adapter (4 hours for full charge), Type C Cable + Power Bank (running 300 cycles, about half a year), and Optional Solar Panel (perfect for high windows, works indoors against window glass or outdoors on the wall).

Charging Details:

• Charging Adapter: Approximately 4 hours for a full charge.
• Power Bank: Provides approximately 300 cycles of operation, lasting about half a year.
• Solar Panel (Optional): Ideal for high windows or locations without easy power access. The solar panel can work indoors against the window glass or outdoors on the wall.

The charging adapter and Type C cable are shared for orders with multiple blinds.

6. Maintenance

To maintain the appearance and functionality of your ZSHINE Motorized Blackout Roller Blinds, follow these care instructions:

• Cleaning: Spot clean only. Use a soft, damp cloth with mild soap if necessary. Do not immerse the fabric or motor components in water.
• General Care: Regularly dust the blinds with a soft brush or vacuum with a brush attachment to prevent dirt buildup.

7. Troubleshooting

This section addresses common issues you might encounter with your ZSHINE Motorized Blackout Roller Blinds. If you experience problems not listed here, please contact customer support.

Common Issues and Solutions:

• Blind not responding to remote:
  • Check if the remote control battery needs replacement.
  • Ensure the remote is within range and pointed towards the blind.
  • Verify the motor is charged. Connect the charging adapter and allow it to charge for a few hours.
• Blind not moving smoothly or stopping unexpectedly:
  • Check for any obstructions in the blind's path.
  • Ensure the blind is properly installed and aligned within the window frame.
  • Recharge the motor. Low battery can affect performance.
• Smart home integration issues (Alexa, Google Home, HomeKit):
  • Verify your smart hub (if required for your motor type) is properly connected to your network and the blinds.
  • Ensure your smart home app is updated and the blinds are correctly added and configured.
  • Check your Wi-Fi connection and router settings.

8. Specifications

9. Customer Support

ZSHINE is committed to providing excellent customer service. Should you have any questions, doubts, or require support regarding your product before or after your order, please do not hesitate to reach out to us.

Our professional customer service team is dedicated to assisting you and is more than happy to support your needs.

For assistance, please visit the ZSHINE Store on Amazon or contact us through the Amazon platform.
