1. Product Overview
The Antifir 24000 BTU Mini Split Air Conditioner & Heater is a versatile ductless inverter system designed for efficient heating and cooling of your space. This unit offers intelligent functions, quiet operation, and energy efficiency, making it a suitable solution for various residential and commercial applications.
Key features include:
- Full Installation Package: Comes with indoor and outdoor unit components, including all necessary accessories for installation.
- Intelligent Functions: Features powerful cooling & heating (TURBO), sleep settings, energy-conserving mode, iFEEL mode, and Health mode.
- Quiet Operation: Sleep mode reduces noise to a minimal 22 decibels for undisturbed rest.
- Energy Efficiency: Advanced inverter technology optimizes energy consumption and maintains stable room temperature.
- Easy Cleaning: Ability to remove particles and moisture from the evaporator, with an easily removable and washable filter.
Figure 1.1: Antifir 24000 BTU Mini Split Air Conditioner and Heater with included remote and installation kit components.
2. Safety Information
WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause property damage, injury, or death. Read the installation and operating instructions thoroughly before installing or servicing this equipment.
- Always ensure the unit is properly grounded to prevent electrical shock.
- Do not attempt to repair or service the unit yourself. Refer all servicing to qualified personnel.
- Ensure the power supply matches the unit's specifications (208/230V).
- Keep the area around the outdoor unit clear of debris and obstructions.
- Do not insert fingers or objects into the air inlet/outlet.
- Turn off the power supply before cleaning or performing any maintenance.
3. Included Components
Your Antifir Mini Split system comes in two cartons, containing the following components:
Box One (Indoor Unit Components)
- 1 x Wall Mount Indoor Unit
- Communication Wires
- Remote Control
- Drain Hose
- User Guide
Box Two (Outdoor Unit Components)
- 1 x Outdoor Unit
- 8ft Power Line
- 13ft Copper Connection Pipe - Air Pipe
- 13ft Copper Connection Pipe - Liquid Pipe
- 6.5ft Drain Hose
- 15ft Communication Wires
- Tape
- Putty
- Wall Sleeve
Figure 3.1: Components included in the two parcels of your Antifir Mini Split system.
4. Setup and Installation
Installation of the Antifir Mini Split system requires specific tools and knowledge of HVAC systems. It is highly recommended to have the unit installed by a qualified and certified HVAC technician to ensure proper function, safety, and warranty compliance.
4.1 Pre-Installation Checklist
- Verify all components listed in Section 3 are present.
- Ensure the installation area meets the required space and electrical specifications.
- Confirm proper drainage for the indoor unit.
- Prepare necessary tools, including a vacuum pump for refrigerant lines.
4.2 Installation Steps (Overview)
- Mount the indoor unit securely on the wall, ensuring proper clearance for airflow.
- Install the outdoor unit on a stable, level surface, away from obstructions.
- Connect the copper refrigerant lines between the indoor and outdoor units. Ensure connections are tight to prevent leaks.
- Connect the electrical power line and communication wires according to the wiring diagram in the detailed installation guide.
- Perform vacuuming of the refrigerant lines to remove air and moisture.
- Open the service valves to release refrigerant into the system.
- Check for any refrigerant leaks using appropriate detection methods.
- Connect the drain hose from the indoor unit to an appropriate drainage point.
Figure 4.1: Properly installed Antifir indoor unit in a living space.
5. Operating Instructions
Your Antifir Mini Split system can be operated using the included remote control. Some models may also support smart control via an app or voice assistants like Alexa (refer to the QR codes in the manual for specific app instructions).
5.1 Remote Control Functions
The remote control provides full control over your unit's functions. Ensure batteries are installed correctly.
Figure 5.1: Antifir remote control for comprehensive unit management.
- ON/OFF: Powers the unit on or off.
- MODE: Cycles through operating modes:
- Cool: Provides cooling to lower room temperature.
- Heat: Provides heating to raise room temperature.
- Dry: Dehumidifies the air, removing excess moisture.
- Fan: Circulates air without heating or cooling.
- SET (Temperature Adjustment): Use the UP/DOWN arrows to set the desired temperature.
- SPEED (Fan Speed): Adjusts the fan speed (Low, Mid, High, Auto).
- SWING / SWING2: Controls the vertical and horizontal airflow direction.
- SLEEP: Activates sleep mode for quiet operation and turns off the display for a dark environment.
- iFEEL: Senses the temperature around the remote control and adjusts the unit to maintain the set temperature, providing localized comfort.
- CLEAN: Initiates a self-cleaning cycle to remove dust and dry moisture from the evaporator.
- HEALTH: Activates health-related functions (specific features may vary by model).
- TURBO: Provides rapid cooling or heating for quick temperature changes.
- ECO: Engages energy-saving mode for reduced power consumption.
Figure 5.2: The Antifir Mini Split offers multiple modes to meet various climate control needs.
6. Maintenance
Regular maintenance ensures optimal performance and longevity of your Antifir Mini Split system.
6.1 Filter Cleaning
The air filter should be cleaned regularly, typically every two weeks, or more frequently depending on usage and air quality. A clean filter ensures efficient operation and better air quality.
- Turn off the unit and disconnect power before cleaning.
- Open the front panel of the indoor unit.
- Gently remove the air filters.
- Clean the filters using a vacuum cleaner or wash them with lukewarm water (below 40°C / 104°F) and a neutral detergent.
- Rinse thoroughly and allow the filters to dry completely in a shaded area before re-installing. Do not expose to direct sunlight.
- Re-install the dry filters and close the front panel.
Figure 6.1: The removable and washable filter ensures fresh airflow and easy maintenance.
6.2 Auto Clean Function
The unit features an auto-clean function (accessible via the 'CLEAN' button on the remote) that helps to remove small particles and eliminate moisture from the evaporator, preventing mildew and maintaining internal cleanliness.
6.3 Fungus-Proof Mode
This mode helps to prevent the growth of mold and mildew within the unit by drying out any residual moisture after operation. Activate this mode periodically to maintain a healthy indoor environment.
7. Troubleshooting
Before contacting customer support, please refer to the following common issues and their potential solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Unit does not turn on. | No power supply; Remote control batteries low/dead. | Check power connection and circuit breaker; Replace remote control batteries. |
| Insufficient cooling/heating. | Dirty air filter; Obstruction of air inlet/outlet; Room too large for unit capacity; Windows/doors open. | Clean air filter; Remove obstructions; Ensure room size is within unit capacity (24000 BTU for up to 1500 sq.ft.); Close windows/doors. |
| Water leakage from indoor unit. | Drain hose clogged or improperly installed; Unit not level. | Check and clear drain hose; Ensure unit is installed level. |
| Unusual noise during operation. | Loose parts; Fan obstruction; Normal operating sounds (e.g., refrigerant flow). | Check for loose components; Ensure no obstructions in fan; Some sounds are normal. |
| Remote displays Celsius instead of Fahrenheit. | Incorrect remote model or setting. | Some remote models may require a specific version (e.g., YKR-H/101E) for Fahrenheit display. Check manual or contact support for remote settings. |
| Temperature on AC remote differs from home thermometer. | Remote displays AC's output temperature, not actual room temperature. | This is normal. Use iFEEL mode for localized temperature sensing. |
If the problem persists after attempting these solutions, please contact Antifir customer support for further assistance.
8. Specifications
Detailed technical specifications for the Antifir 24000 BTU Mini Split Air Conditioner & Heater, Model YH07-002-9K-24K:
- Brand: Antifir
- Model Info: YH07-002-9K-24K
- Cooling Power: 24000 British Thermal Units (BTU)
- Capacity: 2 Tons
- Seasonal Energy Efficiency Ratio (SEER2): 18.5
- Heating Seasonal Performance Factor (HSPF2): 8.3
- Voltage: 208/230 Volts
- Wattage: 6740 watts
- Annual Energy Consumption: 2800 Watts
- Noise Level: 40 dB (as low as 22 dB in Sleep mode)
- Product Dimensions (Indoor Unit): 9.13"D x 44.57"W x 12.99"H
- Product Dimensions (Outdoor Unit): 12.2"D x 32.48"W x 25.79"H
- Item Weight (Indoor Unit): 18.7 pounds
- Material Type: Iron, Copper, Plastic
- Refrigerant Charged: 1300g (R32)
- Installation Type: Split System
- Special Features: Inverter Compressor, Energy Efficient, ECO mode, iFEEL, Heating And Cooling Function, Dust Filter, 4 Way Swing, Auto Clean, Dehumidifier, Fast Cooling, Turbo function.
Figure 8.1: Dimensional and technical specifications of the Antifir Mini Split system.
9. Warranty and Support
Antifir stands behind the quality of its products. For specific warranty details, including coverage period and terms, please refer to the warranty card included with your product or visit the official Antifir website.
For technical support, troubleshooting assistance beyond this manual, or to inquire about replacement parts, please contact Antifir customer service. Have your model number (YH07-002-9K-24K) and purchase date ready when contacting support.
Thank you for choosing Antifir.
