User Manual for JOYRACER 24V 2 Seater Kids Quad ATV

Introduction

Thank you for choosing the JOYRACER 24V 2 Seater Kids Quad ATV. This manual provides important information for the safe assembly, operation, and maintenance of your new electric ride-on toy. Please read it thoroughly before use and keep it for future reference.

Important Safety Warnings

• Adult Supervision Required: This product must be assembled and operated under direct adult supervision.
• Age and Weight Limits: Suitable for children aged 3-8 years (1 child) or under 4 years (2 children). Maximum load capacity is 110 lbs (50 kg). Do not exceed these limits.
• Protective Gear: Always wear a helmet and appropriate safety gear (e.g., knee pads, elbow pads) when operating the ATV.
• Safe Operating Environment: Use on flat, dry surfaces away from roads, cars, steep inclines, swimming pools, or other water bodies. Avoid operating in wet conditions.
• Battery Safety: Only use the provided charger and battery. Do not short-circuit the battery terminals. Keep the battery away from heat sources and open flames.
• No Modifications: Do not modify the electrical system or any part of the ATV. Unauthorized modifications can cause damage and void the warranty.
• Braking: The vehicle stops when the foot pedal is released. Ensure children understand this mechanism.

Package Contents

Please check that all parts are present before assembly:

• JOYRACER 24V 2 Seater Kids Quad ATV Body
• Wheels (4x)
• Steering Wheel
• Seat
• 24V 9AH Battery
• Charger
• Assembly Hardware (screws, washers, nuts)
• Instruction Manual (this document)

Image: The JOYRACER 24V 2 Seater Kids Quad ATV in pink and black, with two children riding it, showcasing its design and capacity.

Assembly Instructions

Assembly should be performed by an adult. Refer to the included hardware for specific steps.

1. Attach Wheels: Securely attach all four wheels to the axles using the provided washers and nuts. Ensure they spin freely but are firmly attached.
2. Install Steering Wheel: Connect the steering column to the vehicle body and then attach the steering wheel. Ensure all connections are tight.
3. Connect Battery: Locate the battery compartment, usually under the seat. Connect the battery terminals (red to red, black to black). Ensure a secure connection.
4. Install Seat: Place the seat onto the vehicle body and secure it with the designated screws or clips.
5. Final Checks: Before first use, double-check all connections, screws, and moving parts to ensure they are secure and functioning correctly.

Charging the Battery

The ATV is powered by a 24V 9AH rechargeable battery. Proper charging extends battery life.

• First Charge: Charge the battery for 8-12 hours before the first use. Do not charge for more than 18 hours.
• Regular Charging: Recharge the battery after each use for 8-12 hours.
• Charging Port: Locate the charging port on the vehicle (refer to diagrams if available). Plug the charger into the port, then into a standard wall outlet.
• Charger Indicator: The charger typically has an indicator light that changes color when charging is complete.
• Storage Charging: If storing the ATV for an extended period, charge the battery fully every 30 days to prevent damage.

Image: A comparison graphic highlighting the benefits of the JOYRACER's single 24V battery versus multiple 12V batteries, emphasizing long life, easy replacement, stable voltage, and safety.

Operating Instructions

Familiarize yourself with the controls before allowing a child to operate the ATV.

• Power On/Off: Press the power button to turn the ATV on or off.
• Start: Use the one-button start feature to initiate operation.
• Forward/Reverse: Use the gear shift lever or switch to select forward, stop, or reverse.
• Acceleration: Press the foot pedal to accelerate. Release the pedal to brake.
• Speed Control: The ATV may have a speed switch to select between high and low speeds.
• Steering: Turn the steering wheel to change direction.
• Multimedia Functions:
  • Bluetooth: Connect a Bluetooth device to play music.
  • USB/TF Card: Insert a USB drive or TF card for MP3 playback.
  • Story & Radio: Utilize built-in story and radio functions.
• LED Lights: Activate the LED lights using the light switch for enhanced visibility and aesthetics.

Image: The JOYRACER ATV showcasing its multimedia features including Bluetooth music, USB port, TF card slot, story & radio functions, one-button start, and cool LED lights.

Key Features

Powerful 4x4 Drive

Equipped with four 200W powerful engines, providing excellent traction and gradability up to 25 degrees for various terrains.

Spacious 2-Seater Design

Designed to comfortably accommodate two children, offering a shared riding experience.

All-Terrain Anti-Skid Tires & Spring Suspension

Durable anti-skid tires and spring suspension system ensure a smooth and stable ride on various surfaces like grass, sand, gravel, and asphalt.

Integrated Multimedia System

Features Bluetooth connectivity, USB and TF card slots for MP3 playback, and built-in story and radio functions for entertainment during rides.

Maintenance

• Cleaning: Wipe the ATV with a soft, damp cloth. Do not use abrasive cleaners or spray water directly onto electrical components.
• Battery Care: Always fully charge the battery after each use. Do not allow the battery to completely drain. If storing for long periods, charge monthly.
• Lubrication: Periodically check and lubricate moving parts like axles and steering components if necessary.
• Tire Pressure: Ensure tires are in good condition. While these are solid tires, inspect for wear and tear.
• Storage: Store the ATV in a dry, cool place away from direct sunlight and moisture.

Troubleshooting

Specifications

• Brand: JOYRACER
• Model: 4x4 Kids Quad ATV (B0CNGP64KV)
• Battery: 24V 9AH
• Motors: 4 x 200W
• Product Dimensions: 40.5 x 25.6 x 28.7 inches
• Load Capacity: Max 110 lbs (50 kg)
• Recommended Age: 1 Kid: 3-8 years; 2 Kids: Under 4 years
• Speed Range: 1.8 - 4.9 mph
• Playtime: Up to 2 hours (depending on usage)
• Features: 4WD, 2 Seater, LED Lights, Bluetooth, MP3, USB, Spring Suspension

Image: A diagram illustrating the dimensions of the JOYRACER ATV and its recommended age/load capacities for one or two children.

Warranty and Support

For warranty information or technical support, please contact JOYRACER customer service. Keep your purchase receipt as proof of purchase.

Contact information can typically be found on the product packaging or the official JOYRACER website.
