Tuklye T565 Stairlift Battery Instruction Manual

1. Introduction

This manual provides essential information for the safe and effective use of your Tuklye T565 stairlift battery. The Tuklye T565 is a Li-ion 5600mAh 14.8V battery designed specifically for Acorn 180 li stairlifts. Please read this manual thoroughly before installation and operation to ensure proper function and longevity of the battery.

2. Safety Information

WARNING: Failure to follow these safety instructions could result in fire, electric shock, injury, or damage to the battery or stairlift.

• Always disconnect power to the stairlift before attempting any battery installation or removal.
• Do not disassemble, crush, puncture, or short-circuit the battery.
• Keep the battery away from water, fire, and high temperatures.
• Do not use the battery if it is damaged, swollen, or leaking.
• Dispose of batteries according to local regulations. Do not dispose of in household waste.
• Only use the specified charger for this battery.
• Keep out of reach of children.
• Professional installation is recommended.

3. Product Overview

The Tuklye T565 battery is a high-capacity lithium-ion power source designed for reliable performance in compatible stairlift models. Each package contains two battery units.

Figure 3.1: Two Tuklye T565 Stairlift Batteries. These batteries are designed to provide long-lasting power for your stairlift system.

Key Features:

• Specifically designed for stairlift applications.
• High capacity: 5600mAh for extended use.
• Nominal Voltage: 14.8V.
• Lithium-ion chemistry for reliable power delivery.
• Compatible with Acorn 180 li stairlifts.

4. Installation

Installing the Tuklye T565 battery requires careful attention to safety and proper connection. It is highly recommended that installation be performed by a qualified technician.

Figure 4.1: Tuklye T565 Battery in context with a stairlift. This image shows the battery's typical placement area within a stairlift system.

Installation Steps (General Guidance):

1. Power Off: Ensure the stairlift's main power supply is completely disconnected and turned off at the circuit breaker.
2. Locate Battery Compartment: Refer to your stairlift's specific manual to locate the battery compartment, which is typically at the base or under the seat.
3. Remove Old Batteries: Carefully disconnect the old batteries, noting the polarity (+ and -) of the connections. Remove them from the compartment.
4. Insert New Batteries: Place the new Tuklye T565 batteries into the compartment. Ensure they fit securely.
5. Connect New Batteries: Connect the new batteries, ensuring correct polarity. Typically, red wires connect to positive (+) terminals and black wires to negative (-) terminals. Double-check all connections for tightness.
6. Secure Compartment: Close and secure the battery compartment cover.
7. Restore Power: Reconnect the stairlift's main power supply.
8. Test Functionality: Perform a test run of the stairlift to ensure it operates correctly and the batteries are charging.

Note: Specific installation procedures may vary by stairlift model. Always consult your stairlift's original instruction manual for detailed steps.

5. Operating Instructions

Once installed, the Tuklye T565 batteries will power your stairlift. Stairlifts typically have an automatic charging system that keeps the batteries topped up when the lift is parked at a charging point (usually at the top or bottom of the stairs).

Normal Operation:

• Ensure the stairlift is parked at its designated charging station when not in use to allow the batteries to recharge.
• Avoid completely draining the batteries, as this can reduce their lifespan.
• If the stairlift is not used for an extended period, ensure it remains connected to power to maintain battery charge.

6. Maintenance

Proper maintenance can extend the life of your Tuklye T565 batteries.

• Regular Charging: Always allow the stairlift to return to its charging point after use.
• Cleanliness: Keep the battery compartment clean and free of dust and debris. Do not use liquid cleaners directly on the batteries.
• Temperature: Store and operate the batteries within recommended temperature ranges (typically room temperature) to prevent degradation. Avoid extreme heat or cold.
• Inspection: Periodically inspect the battery terminals and connections for any signs of corrosion or looseness.
• Long-Term Storage: If the stairlift will be unused for several months, ensure the batteries are fully charged before storage and periodically recharged (e.g., every 3-6 months) to prevent deep discharge.

7. Troubleshooting

If you encounter issues with your stairlift's power, consider the following common troubleshooting steps related to the battery:

8. Specifications

Detailed technical specifications for the Tuklye T565 stairlift battery:

Figure 8.1: Tuklye T565 Battery Product Label. This label provides key identification and specification details for the battery.

9. Warranty and Support

Tuklye is committed to providing high-quality products. For specific warranty details, please refer to the product packaging or contact the manufacturer directly. General support for the Tuklye T565 battery can be obtained through the following channels:

• Manufacturer: QUANZHOU HUBATS TECHNOLOGY CO.,LTD
• Email: hubatsbattery@gmail.com
• Address: 902 Haoting Building, No. 7, Xinfeng North Road, Fengze District, Quanzhou, Fujian Province, China
• EU Representative (REPLAB SARL): 39 AVENUE ACHILLE PEREETTI 92200 NEUILLY SUR SEINE, France
• EU REP Email: EUREP@REPLAB.CC
• EU REP Phone: +33 767189223

When contacting support, please have your product model (T565) and ASIN (B0CMZVF8RW) ready.
