Welcome
Thank you for choosing the Sokany JE-651E Stainless Steel Citrus Juicer. This manual provides essential information for the safe and efficient operation of your appliance. Please read it thoroughly before first use and keep it for future reference.
Important Safety Instructions
- Read all instructions before use.
- Do not immerse the motor base in water or other liquids.
- Keep hands and utensils away from moving parts during operation.
- Ensure the appliance is unplugged before assembling, disassembling, or cleaning.
- This appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
- Children should be supervised to ensure they do not play with the appliance.
- Do not operate the appliance with a damaged cord or plug.
- Use only original accessories.
- For household use only.
Product Components
Familiarize yourself with the parts of your Sokany JE-651E Citrus Juicer.
- Motor Base (Main Unit)
- Juicing Cone (Small and Large)
- Filter/Strainer
- Juice Collector
- Pressure Lever/Handle
- Stainless Steel Housing
- Power Cord
Setup
- Unpack all components and remove any packaging materials.
- Clean all detachable parts (juicing cones, filter, juice collector) with warm soapy water before first use. Rinse thoroughly and dry.
- Place the motor base on a stable, flat, and dry surface.
- Assemble the juicer: Place the juice collector onto the motor base, then the filter, and finally the appropriate juicing cone (small for limes/lemons, large for oranges/grapefruits).
- Ensure the pressure lever is in the upright position.
- Plug the power cord into a suitable electrical outlet.
Operating Instructions
The Sokany JE-651E is designed for efficient citrus juicing.
- Cut the citrus fruit (oranges, lemons, limes, grapefruits) in half.
- Place one half of the fruit onto the juicing cone.
- Gently press down on the fruit with the pressure lever. The motor will activate automatically.
- Apply steady, even pressure to extract the juice.
- Release the pressure to stop the motor.
- Allow the juice to collect in the juice collector.
- Repeat the process for all fruit halves.
- Once juicing is complete, unplug the appliance.
- Pour the fresh juice from the spout into your desired glass or container.
Cleaning and Maintenance
Regular cleaning ensures optimal performance and longevity of your juicer.
- Always unplug the juicer before cleaning.
- Disassemble the removable parts: pressure lever, juicing cone, filter, and juice collector.
- Wash these parts immediately after use with warm, soapy water. Use a brush if necessary to remove pulp residue from the filter.
- Rinse all parts thoroughly under running water.
- Dry all parts completely before reassembling or storing.
- Wipe the motor base with a damp cloth. Never immerse the motor base in water.
- Do not use abrasive cleaning agents or scouring pads, as they may damage the surfaces.
- Store the assembled juicer in a dry place.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Juicer does not turn on. | Not plugged in. | Ensure the power cord is securely plugged into a working outlet. |
| Juicer does not turn on. | No pressure applied. | The motor activates when pressure is applied to the juicing cone. Apply gentle pressure. |
| Low juice yield. | Insufficient pressure or fruit type. | Apply firm, even pressure. Ensure you are using ripe citrus fruits. |
| Motor stops during operation. | Overload protection activated. | Release pressure, unplug, and let the unit cool down for a few minutes before resuming. |
| Excessive pulp in juice. | Filter clogged or damaged. | Clean the filter thoroughly. Ensure it is correctly seated. |
If the problem persists, please contact customer support.
Specifications
| Feature | Detail |
|---|---|
| Model | JE-651E |
| Brand | Sokany |
| Power | 350 Watts |
| Capacity | 400 ml |
| Material | Stainless Steel |
| Color | Silver |
| Special Features | Portable, Detachable Parts |
| Product Dimensions (D x W x H) | 18 x 7 x 28 cm |
| Item Weight | 800 grams |
Specifications are subject to change without notice for product improvement.
Warranty and Support
This product comes with a standard manufacturer's warranty. Please refer to the warranty card included in your product packaging for specific terms and conditions.
For technical support, spare parts, or warranty claims, please contact your retailer or the authorized service center. Keep your purchase receipt as proof of purchase.
