TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger User Manual

1. Introduction

Thank you for choosing the TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger. This compact and efficient wall charger is designed to provide fast and reliable power to your devices. Its ultra-thin profile makes it ideal for use in narrow spaces and for travel. This manual provides essential information for the safe and effective use of your charger.

2. Package Contents

1x TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger (Model: AC-20AC-WH)

3. Setup

Follow these steps to set up your TREBLEET charger:

Unfold the Prongs: Gently pull out the foldable prongs from the charger body. Ensure they are fully extended before plugging into an outlet.
Connect to Power Outlet: Plug the charger into a standard AC wall outlet (110 Volts). The ultra-thin design allows it to sit flush against the wall, making it suitable for outlets behind furniture.
Connect Your Device: Use a compatible charging cable (not included) to connect your device to either the USB-C (PD 3.0) port or the USB-A (QC 3.0) port on the charger.

TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger plugged into a wall outlet.

Figure 1: The TREBLEET charger plugged into a wall outlet, demonstrating its flush fit.

4. Operating Instructions

The TREBLEET charger features dual ports for versatile charging:

Single Port Charging:
When using only the USB-C (PD) port, it supports Power Delivery 3.0 fast charging up to 20W Max. This can charge compatible devices like an iPhone 15 from 0% to 50% in approximately 30 minutes.
When using only the USB-A (QC) port, it supports Quick Charge 3.0 up to 18W Max.
Dual Port Charging:
When both the USB-C and USB-A ports are used simultaneously, the total output is shared at a maximum of 15W (5V/3A). Fast charging is disabled in this mode, and devices will charge at a normal rate.

Diagram illustrating intelligent power allocation for single and dual port charging.

Figure 2: Intelligent Power Allocation. Single port provides up to 20W, while dual ports share 15W.

Diagram showing output specifications for USB-C (PD) and USB-A (QC3.0) ports when used individually and simultaneously.

Figure 3: Detailed output specifications for single and dual port usage.

Device Compatibility

The charger is compatible with most USB-C and USB-A devices, including but not limited to:

iPhone 15/15 Pro/15 Pro Max, 14/14 Pro, 13/13 Pro, 12/12 Pro
Google Pixel 6/7/8
Samsung Galaxy S23/S23 Ultra/Z Fold4/A53 5G/S22/S22+/Z Flip3/Z Fold3/S21 FE
iPad models
Various PC tablets and other USB-powered devices

TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger in use, charging a smartphone on a nightstand.

Figure 4: The ultra-thin design allows for convenient charging in tight spaces, such as behind a nightstand.

TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger charging two smartphones simultaneously.

Figure 5: The dual-port design enables charging of two devices concurrently.

5. Safety Information

The TREBLEET charger is built with safeguards to protect your devices:

Overcurrent Protection: Prevents damage from excessive current flow.
Overheating Protection: Monitors temperature to prevent overheating during operation.
Overcharging Protection: Safeguards your device's battery from being overcharged.

General Safety Precautions:

Do not expose the charger to liquids, moisture, or extreme temperatures.
Avoid dropping or subjecting the charger to strong impacts.
Do not attempt to disassemble, repair, or modify the charger.
Keep out of reach of children.
Ensure the charger is fully inserted into the wall outlet.

6. Maintenance

To ensure the longevity and optimal performance of your charger:

Cleaning: Disconnect the charger from the power outlet before cleaning. Use a soft, dry cloth to wipe the surface. Do not use liquid cleaners or aerosols.
Storage: When not in use, store the charger in a cool, dry place away from direct sunlight and extreme temperatures. The foldable prongs make it easy to store and transport.

7. Troubleshooting

If you encounter issues with your charger, refer to the following:

Device Not Charging:
• Ensure the charger is securely plugged into a working wall outlet.
• Verify that your charging cable is properly connected to both the charger and your device.
• Try using a different charging cable or device to rule out cable or device issues.
• Check if the wall outlet is functional by plugging in another appliance.
Slow Charging:
• If two devices are connected, the total output is limited to 15W, disabling fast charging. For maximum charging speed, use only one port at a time.
• Ensure your device and cable support fast charging protocols (PD 3.0 or QC 3.0) to utilize the charger's full capabilities.
• Overheating can sometimes reduce charging speed. Disconnect the charger and device, allow them to cool, and then try again.

8. Specifications

Brand	TREBLEET
Model Number	AC-20AC-WH
Package Dimensions	3.07 x 1.73 x 0.67 inches
Item Weight	1.44 ounces
Input Voltage	110 Volts
Amperage	3 Amps
Total USB Ports	2 (1x USB Type-C, 1x USB Type-A)
Special Feature	Fast Charging (PD 3.0 & QC 3.0)

Image showing the dimensions of the TREBLEET charger compared to a US quarter coin and a credit card.

Figure 6: Physical dimensions of the charger for reference.

9. Warranty and Support

The TREBLEET Ultra-Thin 20W USB-C PD Fast Portable Charger is designed with built-in safeguards to ensure device protection. For specific warranty details and customer support, please refer to the manufacturer's official website or contact their customer service directly. Keep your purchase receipt for any warranty claims.
