Caso Coffee Taste & Style Duo Thermo Coffee Machine Instruction Manual

1. Introduction

Thank you for choosing the Caso Coffee Taste & Style Duo Thermo coffee machine. This appliance is designed to provide a convenient and enjoyable coffee brewing experience with its dual thermal carafes and advanced features. Please read this manual thoroughly before initial use to ensure proper operation, maintenance, and safety.

2. Important Safety Instructions

• Read all instructions before operating the appliance.
• Do not immerse the appliance, power cord, or plug in water or other liquids.
• Close supervision is necessary when the appliance is used by or near children.
• Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts, and before cleaning the appliance.
• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner.
• The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock, or injury to persons.
• Do not use outdoors.
• Do not let the cord hang over the edge of a table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Always attach plug to appliance first, then plug cord into the wall outlet. To disconnect, turn any control to 'off', then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Exercise extreme caution when disposing of hot steam.
• The thermal carafes are designed for use with this appliance only. They must never be used on a range top.

3. Package Contents

Please check that all items are present and in good condition:

• Caso Coffee Taste & Style Duo Thermo Coffee Machine
• Two Thermal Carafes
• Removable Filter Basket
• Permanent Filter
• Coffee Measuring Spoon
• Instruction Manual

4. Product Overview

Familiarize yourself with the components of your coffee machine.

A front-angled view of the Caso Coffee Taste & Style Duo Thermo coffee machine, showcasing its black and stainless steel finish with two thermal carafes.

4.1 Components

• Water Tank: 1.2L capacity with practical water level indicator.
• Lid: For the water tank.
• Control Panel: Touch-sensitive panel with LED display for settings and functions.
• Brewing Head: Features a 17-hole design for optimal coffee powder humidification.
• Filter Basket: Removable for easy cleaning.
• Permanent Filter: For aroma-friendly brewing.
• Thermal Carafes (x2): Designed to keep coffee warm for extended periods, each holding up to 10 cups.
• Drip Stop: Prevents dripping when the carafe is removed.

A detailed diagram showing the removable filter basket with its dimensions: 26.5cm width, 17cm depth, and 32.5cm height, including the handle.

A close-up view of the digital display and touch controls on the Caso coffee machine, showing temperature and various function icons for brewing.

5. Setup

Before first use, follow these steps:

1. Unpack: Carefully remove all packaging materials and check for any damage.
2. Clean: Wash the thermal carafes, filter basket, and permanent filter in warm, soapy water. Rinse thoroughly and dry. Wipe the exterior of the coffee machine with a damp cloth.
3. First Brew Cycle (Cleaning):
   • Fill the water tank with fresh, cold water up to the MAX level.
   • Place the empty filter basket with the permanent filter (or a paper filter) into its holder.
   • Place an empty thermal carafe on the warming plate.
   • Run a full brewing cycle without coffee powder. Discard the hot water.
   • Repeat this process once or twice to ensure the system is clean.
4. Position: Place the coffee machine on a stable, flat, heat-resistant surface, away from the edge of the counter.

6. Operating Instructions

6.1 Basic Coffee Brewing

1. Fill Water Tank: Open the water tank lid and fill with fresh, cold water to the desired level, indicated by the water level indicator. Do not exceed the MAX line.
2. Add Coffee: Place the permanent filter (or a paper filter) into the removable filter basket. Add the desired amount of ground coffee using the provided measuring spoon. A general guideline is one level spoon per cup.
3. Insert Filter Basket: Ensure the filter basket is securely placed in its holder.
4. Place Carafe: Position one or both thermal carafes under the drip outlet. Ensure the carafe lid is properly closed to maintain temperature.
5. Start Brewing: Plug the appliance into a power outlet. Press the ON/OFF button on the touch control panel. The brewing process will begin.
6. Serve: Once brewing is complete, the machine will automatically switch off. The thermal carafes will keep your coffee warm.

6.2 Using the Timer Function

The integrated timer allows you to program the machine to start brewing at a specific time.

1. Prepare Coffee: Follow steps 1-4 of "Basic Coffee Brewing".
2. Set Current Time: Refer to the control panel instructions to set the current time on the LED display.
3. Set Program Time: Press the TIMER button. Use the hour and minute buttons to set the desired start time for brewing.
4. Activate Timer: Press the TIMER button again to confirm and activate the timer. A timer indicator light will illuminate.
5. The machine will automatically start brewing at the programmed time.

6.3 Aroma Function

The aroma function allows you to adjust the brewing strength from mild to strong.

1. Prepare Coffee: Follow steps 1-4 of "Basic Coffee Brewing".
2. Select Aroma: Before starting the brew cycle, press the AROMA button on the control panel. Cycle through the options (e.g., mild, medium, strong) until your desired strength is displayed.
3. Start Brewing: Press the ON/OFF button to begin brewing with the selected aroma setting.

7. Maintenance and Cleaning

Regular cleaning ensures optimal performance and extends the life of your coffee machine.

7.1 Daily Cleaning

1. Unplug: Always unplug the appliance and allow it to cool completely before cleaning.
2. Discard Grounds: Remove the filter basket and discard used coffee grounds and paper filter (if used).
3. Wash Parts: Wash the filter basket, permanent filter, and thermal carafes in warm, soapy water. Rinse thoroughly and dry. These parts are generally not dishwasher safe unless specified.
4. Wipe Exterior: Wipe the exterior of the coffee machine with a soft, damp cloth. Do not use abrasive cleaners or scouring pads.

7.2 Descaling

Depending on water hardness, descaling should be performed every 2-4 months to prevent mineral buildup.

1. Prepare Descaling Solution: Mix a descaling solution according to the manufacturer's instructions (e.g., white vinegar and water, or a commercial descaling agent).
2. Fill Water Tank: Pour the descaling solution into the water tank up to the MAX level.
3. Run Cycle: Place an empty carafe on the warming plate. Run a brewing cycle without coffee.
4. Rinse: After the cycle, discard the solution. Fill the water tank with fresh, cold water and run 2-3 full brewing cycles to rinse the machine thoroughly.

8. Troubleshooting

Refer to this table for common issues and their solutions.

9. Specifications

10. Warranty and Support

Your Caso Coffee Taste & Style Duo Thermo coffee machine comes with a standard manufacturer's warranty. Please refer to the warranty card included in your original packaging for specific terms and conditions, including the warranty period and coverage details.

For technical support, service, or to inquire about spare parts, please contact Caso customer service. Contact information can typically be found on the Caso official website or on the product packaging.
