eeTao 42V 1.5A AC/DC Charger Instruction Manual

1. Introduction

This manual provides essential instructions for the safe and effective use of your eeTao 42V 1.5A AC/DC Charger. This charger is specifically designed for use with the Swagtron T882 Swagboard and its compatible 62.4Wh rechargeable battery (Model FY0634201500). Please read this manual thoroughly before use and retain it for future reference.

2. Product Overview

The eeTao 42V 1.5A AC/DC Charger is a reliable power supply designed to recharge your Swagtron T882 Swagboard battery. It features a 2-prong connector and operates with a wide input voltage range of 100-240VAC, 50/60Hz, making it suitable for global use. The charger incorporates multiple safety protections, including Over Voltage Protection (OVP), Over Current Protection (OCP), and Short Circuit Protection (SCP), to ensure safe charging.

Image of the eeTao 42V AC/DC charger, showing its main unit with specifications printed on it and the attached 2-prong connector cable.

3. Setup Instructions

Follow these steps to properly connect your charger:

1. Identify the Charging Port: Locate the charging port on your Swagtron T882 Swagboard. It is typically a circular port designed for a 2-pin connector.
2. Connect the Charger: Insert the 2-prong connector of the eeTao charger firmly into the Swagboard's charging port. Ensure a secure connection.
3. Plug into Power Outlet: Plug the charger's AC power cord into a standard 100-240VAC wall outlet.

Image illustrating the charging port on a Swagtron T882 Swagboard, highlighted for charger connection. Also shows the battery label with model number T882 and input 42VDC 0.5A.

4. Operating Instructions

Once connected, the charger will begin to supply power to the Swagboard's battery. The charging process is automatic. There are no user-adjustable settings on the charger itself.

• Charging Time: Charging time will vary depending on the battery's current charge level and capacity. Refer to your Swagtron T882 Swagboard manual for specific charging duration guidelines.
• Disconnection: Once charging is complete, first unplug the charger from the wall outlet, then disconnect the 2-prong connector from the Swagboard's charging port.

5. Safety Information

To prevent injury or damage, observe the following safety precautions:

• Use this charger only with compatible devices as specified in this manual.
• Do not expose the charger to water, moisture, or extreme temperatures.
• Avoid dropping or subjecting the charger to severe impact.
• Do not attempt to open, modify, or repair the charger. Refer servicing to qualified personnel.
• Ensure proper ventilation around the charger during use to prevent overheating.
• Keep out of reach of children.

6. Maintenance

Proper care will extend the life of your charger:

• Cleaning: Disconnect the charger from all power sources before cleaning. Use a soft, dry cloth to wipe the exterior. Do not use liquid cleaners or solvents.
• Storage: Store the charger in a cool, dry place away from direct sunlight and moisture when not in use.
• Cable Care: Avoid bending or crimping the power cord excessively. Do not place heavy objects on the cord.

7. Troubleshooting

If you encounter issues with your charger, consider the following:

• Charger Not Working: Ensure the charger is securely plugged into both the wall outlet and the Swagboard. Try a different outlet to rule out a power source issue.
• Battery Not Charging: Rechargeable batteries have a limited lifespan, typically 1 to 3 years. An old or dead battery may not accept a charge, which is not an indication of a faulty charger. If you suspect the battery is the issue, a voltmeter can be used to test if the charger is outputting the correct voltage (42VDC).
• Overheating: If the charger feels excessively hot, disconnect it immediately. Ensure it is used in a well-ventilated area and not covered.

8. Specifications

9. Warranty and Support

eeTao provides the following coverage for this product:

• Refund Policy: 30 days from the date of purchase.
• Exchange Policy: 24 months from the date of purchase.

For support or warranty claims, please contact eeTao customer service through your purchase platform.
