Introduction
Thank you for choosing the BOSMILLER 9341 Big and Tall Executive Office Chair. This manual provides essential information for the safe assembly, operation, and maintenance of your new office chair. Please read these instructions thoroughly before use and retain them for future reference.
Image: The BOSMILLER 9341 Executive Office Chair, showcasing its robust design and integrated massage/heating features.
Safety Information
- This chair has a maximum weight capacity of 650 lbs. Do not exceed this limit.
- Ensure the chair is properly assembled for optimal stability. Regularly check all screws and connections for tightness.
- Lift and move the chair with care, as it weighs approximately 62 lbs. Seek assistance if necessary.
- The quiet rubber wheels are designed to protect your floors. Avoid using the chair on uneven surfaces or over obstacles that could damage the wheels or cause instability.
- Keep hands and clothing clear of moving parts during adjustment.
- Do not stand on the chair.
Package Contents
Before assembly, verify that all components are present and undamaged. If any parts are missing or damaged, please contact customer support.
- Backrest
- Seat Cushion
- Armrests (Left and Right)
- Base (Star Base)
- Gas Lift Cylinder
- Casters (Wheels)
- Mechanism Plate
- Hardware Kit (Screws, Washers, Allen Wrench)
- Massage/Heating Remote Control and Power Adapter
- Instruction Manual
Setup and Assembly
Assembly is required. Please follow the steps below carefully. It is recommended to assemble the chair on a soft, clean surface to prevent damage.
- Attach Casters to Base: Insert the casters into the holes at the end of each leg of the star base. Push firmly until they click into place.
Image: Illustration showing the casters being inserted into the chair's star base.
- Insert Gas Lift: Place the gas lift cylinder into the center hole of the assembled star base.
Image: The gas lift cylinder being placed into the central opening of the chair base.
- Attach Mechanism Plate to Seat: Align the mechanism plate with the screw holes on the underside of the seat cushion. Secure it with the provided screws, ensuring the front of the mechanism faces the front of the seat.
Image: The mechanism plate being screwed onto the bottom of the seat cushion.
- Attach Armrests to Seat: Secure the armrests to the sides of the seat cushion using the designated screws. Pay attention to the 'L' (Left) and 'R' (Right) markings.
Image: Illustration showing the armrests being attached to the sides of the seat.
- Attach Backrest to Seat and Armrests: Align the backrest with the mounting points on the seat and armrests. Secure with screws. Ensure all connections are tight.
Image: The backrest being secured to the seat and armrest assembly.
- Place Assembled Seat onto Gas Lift: Carefully place the assembled seat (with backrest and armrests) onto the gas lift cylinder. The tapered end of the gas lift should fit securely into the mechanism plate.
Image: The final step of placing the chair body onto the gas lift and base.
Operating Instructions
Chair Adjustments
- Seat Height Adjustment: Locate the lever on the right side beneath the seat. To raise the seat, lift the lever while taking your weight off the chair. To lower the seat, lift the lever while seated. Release the lever to lock the height.
- Rocking Function and Recline Lock: The chair features a 125° rocking function. Pull the lever on the left side beneath the seat outwards to enable rocking. Push it inwards to lock the chair in an upright position. The tilt tension knob, located beneath the seat at the front, can be rotated to adjust the resistance of the rocking motion.
Image: Diagram illustrating the 125-degree rocking function, tilt tension knob, and recline lock lever.
- 5D Armrests: The armrests offer multiple adjustment options:
- Height Adjustment: Press the button on the side of the armrest and move it up or down.
- Forward/Backward Slide: Slide the armrest pad forward or backward.
- Pivot: Rotate the armrest pad 360° to find your preferred angle.
- Flip-up: The armrests can be flipped up 90° to allow the chair to be pushed closer to a desk or for easier entry/exit.
Image: Visual representation of the various adjustments available for the 5D armrests, including height, forward/backward, pivot, and flip-up.
- Adjustable Lumbar Support: The chair features adjustable lumbar support to ease back pressure. Adjust the lumbar support to your desired position for optimal comfort.
Massage and Heating Function
The chair is equipped with a 4-point vibrating massage system and a heating function for the lumbar area. Use the provided remote control to operate these features.
- Power On/Off: Connect the chair's power adapter to a wall outlet. Use the 'POWER' button on the remote to turn the massage and heating functions on or off.
- Massage Modes: Select from 2 massage modes using the 'MODE' button.
- Massage Position Selection: Use the remote to select specific massage points.
- Heating Function: Activate the heating function with the 'HEAT' button. The lumbar area can warm up to 130°F.
- Timer: Set a timer for the massage function using the remote control.
Image: The remote control for the vibration massage and heating functions, with an overlay showing the four massage points on the chair's backrest.
Maintenance
- Cleaning: The chair's leather finish requires dry cleaning. For general cleaning, wipe surfaces with a soft, damp cloth. Avoid harsh chemicals or abrasive cleaners.
- Hardware Check: Periodically check all screws and bolts to ensure they are tight. Loose hardware can affect the chair's stability and safety.
- Caster Care: Keep the wheels free of hair and debris to ensure smooth movement and prevent floor scratches.
- Gas Lift: Do not attempt to disassemble or repair the gas lift cylinder. If it malfunctions, contact customer support for replacement.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Chair is wobbly or unstable | Loose screws or improper assembly. | Check all assembly screws and tighten them securely. Ensure the gas lift is fully seated in the base and mechanism. |
| Seat height does not adjust | Gas lift cylinder malfunction or lever issue. | Ensure the height adjustment lever is fully engaged. If the gas lift is faulty, contact customer support for a replacement. |
| Chair does not rock or recline | Recline lock engaged or tilt tension too tight. | Pull the recline lock lever outwards to enable rocking. Loosen the tilt tension knob by rotating it counter-clockwise. |
| Casters (wheels) are not rolling smoothly | Debris caught in casters or worn-out wheels. | Remove any hair or debris from the caster wheels. If wheels are worn, replacements are readily available and can be installed by pulling out the old ones and pushing in new ones. |
| Massage/Heating function not working | Power connection issue or remote control battery. | Ensure the power adapter is securely connected to the chair and a working power outlet. Check the remote control for battery issues. |
Specifications
| Feature | Detail |
|---|---|
| Brand | BOSMILLER |
| Model Name | 9341 |
| Color | Black |
| Product Dimensions | 29.5"D x 24.5"W x 50.5"H |
| Maximum Weight Recommendation | 650 Pounds |
| Item Weight | 62 pounds |
| Back Style | Solid Back |
| Special Features | 5D Armrests, Massage and Heating, Big and Tall, Leather, Adjustable Lumbar Support |
| Product Care Instructions | Dry Clean |
| Material | Memory Foam (Fill Material), Leather (Furniture Finish) |
| Seat Height | 22.8 Inches |
| Seat Depth | 22.3 inches |
| Furniture Base Movement | Swivel |
| Reclining Position Count | 1 (125° rocking function) |
| UPC | 716035310914 |
| Date First Available | July 3, 2023 |
Warranty and Support
BOSMILLER is committed to providing high-quality products. This chair comes with a 1-year guarantee from the date of purchase.
If you encounter any issues or have questions regarding your BOSMILLER 9341 Executive Office Chair, please contact our customer service team. We are here to help ensure your satisfaction.
For support, please refer to the contact information provided at the point of purchase or visit the official BOSMILLER website.
