1. Introduction
Thank you for choosing the EXTRASTAR 6-Outlet Extender. This manual provides essential information for the safe and efficient use of your new product. Please read these instructions carefully before installation and operation, and retain them for future reference.
Image 1.1: Two EXTRASTAR 6-Outlet Extenders.
2. Safety Information
To reduce the risk of electric shock, fire, or injury, always follow basic safety precautions when using electrical products. This device is ETL-listed, ensuring it meets recognized safety standards.
- Electrical Rating: Do not exceed the electrical rating of 15A/125VAC/1875W. Overloading the extender can cause overheating and potential fire hazards.
- Indoor Use Only: This product is designed for indoor use in dry locations. Do not use it in wet or damp conditions.
- Proper Installation: Ensure the extender is securely plugged into a standard duplex or decorator wall receptacle. Loose connections can cause overheating.
- Grounding: This product features 3-prong grounded outlets for safety. Always use with properly grounded receptacles.
- Children and Pets: Keep out of reach of children and pets.
- Damage: Do not use if the product or its prongs are damaged.
3. Product Features
The EXTRASTAR 6-Outlet Extender is designed to expand your power options efficiently and safely.
- Multiple Outlets: Converts two standard wall sockets into six 3-prong AC outlets, providing ample power for multiple devices.
- Space-Saving Design: Its low-profile, compact design allows it to sit flush against the wall, minimizing clutter and blending seamlessly with your decor.
- Centralized Charging: Ideal for creating a dedicated charging station for portable devices such as cell phones, tablets, and smartwatches.
- Safety Certified: ETL-listed, ensuring compliance with safety standards. Constructed with high-temperature resistant and flame-retardant materials for enhanced safety.
Image 3.1: The extender helps keep desk cables neat and tidy.
4. Package Contents
Each package contains the following items:
- 2 x EXTRASTAR 6-Outlet Extenders
5. Setup
Setting up your EXTRASTAR 6-Outlet Extender is a simple process.
- Identify a Suitable Outlet: Locate a standard duplex or decorator 3-prong wall outlet. This extender is not compatible with USB-only or GFCI outlets.
- Plug In the Extender: Align the two sets of prongs on the back of the extender with the corresponding slots in your wall outlet. Gently push the extender firmly into the wall outlet until it is flush with the wall.
- Verify Connection: Ensure the extender is securely seated and does not wobble.
Image 5.1: Rear view of the extender, showing the prongs for wall insertion.
Image 5.2: Suitable and unsuitable outlet types for the extender.
Video 5.1: An overview of the EXTRASTAR 6-Outlet Extender, demonstrating its features and compact design.
6. Operation
Once the extender is securely plugged into a wall outlet, it is ready for use.
- Connect Devices: Plug your electronic devices into any of the six available 3-prong AC outlets on the extender.
- Power On: Ensure your devices are properly connected and then power them on as usual.
- Monitor Load: Be mindful of the total power consumption of all connected devices. Do not exceed the maximum rating of 1875W.
Image 6.1: The extender in use, providing power to a tablet.
Image 6.2: The extender is compatible with a wide range of devices.
7. Maintenance
To ensure the longevity and safe operation of your EXTRASTAR 6-Outlet Extender, follow these maintenance guidelines:
- Cleaning: Disconnect the extender from the wall outlet before cleaning. Use a dry, soft cloth to wipe the surface. Do not use liquid cleaners or sprays.
- Inspection: Periodically inspect the extender for any signs of damage, such as cracks, frayed wires, or loose prongs. If damage is found, discontinue use immediately.
- Storage: When not in use, store the extender in a cool, dry place away from direct sunlight and moisture.
8. Troubleshooting
If you encounter issues with your EXTRASTAR 6-Outlet Extender, refer to the following common troubleshooting steps:
- No Power to Devices:
- Ensure the extender is fully and securely plugged into the wall outlet.
- Check if the wall outlet itself is functioning by plugging in another device directly.
- Verify that the total wattage of connected devices does not exceed 1875W. Unplug some devices if overloaded.
- Check your home's circuit breaker for tripped circuits.
- Loose Fit in Wall Outlet:
- If the extender feels loose, try it in a different wall outlet. If the issue persists, the extender may be damaged or the wall outlet may be worn. Discontinue use if the fit is not secure.
If these steps do not resolve the issue, please contact EXTRASTAR customer service for further assistance.
9. Specifications
| Specification | Detail |
|---|---|
| Brand | EXTRASTAR |
| Model Number | FL-JC23 |
| Number of Outlets | 6 AC outlets |
| Number of Wires | 3 (Grounded) |
| Plug Format | Type B |
| Amperage | 15 Amps |
| Voltage | 125 Volts |
| Max Wattage | 1875 Watts |
| Material | Plastic |
| Color | White |
| Certification | ETL Listed |
| Product Dimensions | 3.8 x 1 x 3.2 inches (95mm x 25mm x 80mm) |
| Item Weight | 6.9 ounces |
Image 9.1: Product dimensions of the 6-Outlet Extender.
10. Warranty and Support
EXTRASTAR is committed to providing high-quality products and customer satisfaction. Your purchase includes two EXTRASTAR 6-Outlet Extenders.
For warranty details or any questions regarding your product, please do not hesitate to contact EXTRASTAR customer service. Our team is ready to assist you with any inquiries or support needs.
Contact Information: Please refer to the product packaging or the official EXTRASTAR website for the most current customer service contact details.
