C+UE Hospital Grade Blood Pressure Monitor - Instruction Manual

Introduction

Thank you for choosing the C+UE Hospital Grade Blood Pressure Monitor. This device is designed for accurate and convenient blood pressure measurement on the arm. It features an all-in-one design, making it portable and easy to use for both professional and personal monitoring. Please read this manual thoroughly before use to ensure proper operation and to maintain the accuracy and longevity of your device.

This product is listed on the Australian Register of Therapeutic Goods (ARTG) with registration number 394831, ensuring it meets strict regulatory standards for medical devices.

ARTG Australian Register of Therapeutic Goods No. 394831

Safety Information

Always consult your healthcare professional for interpretation of blood pressure readings. Self-diagnosis and treatment based on measurement results can be dangerous. This device is intended for non-invasive measurement and monitoring of arterial blood pressure in adults. Do not use this device on infants, children, or individuals who cannot express their consent.

• Do not use the device in environments with strong electromagnetic fields.
• Keep the device dry and away from direct sunlight.
• Do not disassemble or attempt to repair the device yourself. Contact qualified service personnel.
• Ensure correct battery polarity when inserting batteries.
• Remove batteries if the device will not be used for an extended period.

Package Contents

Upon opening the package, please verify that all items listed below are present and in good condition:

• C+UE Hospital Grade Blood Pressure Monitor (Model: CUE-U81M)
• Integrated Arm Cuff
• Instruction Manual
• Storage Case
• 4 x AAA Batteries (may be included separately or pre-installed)

The C+UE Blood Pressure Monitor and its packaging, including the instruction manual.

Setup

1. Battery Installation

The C+UE Blood Pressure Monitor requires 4 AAA batteries for operation. Ensure batteries are inserted with correct polarity as indicated inside the battery compartment.

Ensure 4 AAA batteries are correctly inserted into the device.

2. Cuff Placement

Proper cuff placement is crucial for accurate readings. The integrated arm cuff should be placed directly on your upper arm, above the elbow. Ensure the red arrow or indicator on the cuff is aligned with your brachial artery (typically on the inside of your elbow).

Correct placement of the integrated arm cuff on the upper arm.

3. Optimal Measurement Position

For the most accurate blood pressure readings, sit comfortably with your back supported and feet flat on the floor. Rest your arm on a table or flat surface so that the cuff is at the same level as your heart. Avoid talking or moving during the measurement process.

Demonstration of proper body and arm positioning for accurate blood pressure measurement.

Operating Instructions

Device Overview

Key components and display indicators of the C+UE Blood Pressure Monitor.

• SYS mmHg: Systolic Blood Pressure reading.
• DIA mmHg: Diastolic Blood Pressure reading.
• PUL /min: Pulse Rate (beats per minute).
• M: Memory indicator, showing current memory group (User 1 or 2).
• MEM Button: Accesses stored measurement records.
• SET Button: Used for setting date, time, and user profiles.
• S/T Button: Starts a measurement or turns the device off/terminates a measurement.

1. Taking a Measurement

With the cuff correctly positioned and your arm at heart level, press the S/T button. The cuff will automatically inflate, and the measurement will begin. Remain still and quiet during this process. Once complete, your systolic, diastolic, and pulse readings will be displayed on the large LCD screen.

The large LCD screen displays your measurement results clearly.

2. Memory Function

The monitor features a 99-group memory function, allowing you to track your readings over time. Press the MEM button to review past measurements. The device supports two user profiles, enabling separate tracking for two individuals.

3. Setting Date and Time

To set the date and time, press and hold the SET button until the display flashes. Use the MEM button to adjust values and the SET button to confirm and move to the next setting. This ensures accurate time-stamping of your measurements.

Official Product Videos

For a visual guide on using your C+UE Blood Pressure Monitor, please watch the official instructional videos below:

Maintenance

• Cleaning: Wipe the device and cuff with a soft, dry cloth. If necessary, use a slightly damp cloth with mild soap, then wipe dry. Do not use abrasive cleaners or immerse the device in water.
• Storage: Store the monitor in its provided case in a cool, dry place, away from direct sunlight and extreme temperatures.
• Battery Replacement: Replace all 4 AAA batteries when the low battery indicator appears on the display.

Troubleshooting

Specifications

• Model Number: CUE-U81M
• Product Dimensions: 190 x 120 x 65 cm
• Item Weight: 700 Grams
• Power Source: Battery Powered (4 AAA batteries required)
• Display Type: LCD
• Measurement Method: Oscillometric
• Memory: 99 groups (for 2 users)
• Measurement Location: Arm
• Manufacturer: C+UE/Urion
• ARTG Registration: 394831

Warranty and Support

C+UE is committed to providing high-quality medical products. For warranty information, technical support, or service inquiries, please refer to the contact details provided in your product packaging or visit the official C+UE website. You can also scan the QR code below for direct access to product information and support.

Scan for more product information
