1. Product Overview
The RAEFLOW Waterless Urinal with Hose (Model P7816) is designed to provide a convenient and sustainable solution for liquid waste management in various settings. This innovative urinal eliminates the need for water flushing, contributing to significant water conservation. Its robust, UV-resistant construction ensures durability for both indoor and outdoor applications, making it ideal for locations without traditional plumbing access.
Image: The RAEFLOW Waterless Urinal, gray in color, shown with its product packaging. The urinal features a sleek design and is accompanied by a flexible hose for urine diversion. The packaging highlights its waterless nature and UV resistance.
2. Product Components
Upon unboxing your RAEFLOW Waterless Urinal, please verify that all the following components are included:
- Waterless Urinal Unit: The main gray plastic urinal body.
- Urine Hose: One (1) 1.5-meter (approximately 4.9 feet) flexible hose for directing urine.
- Mounting Screws: A set of screws for secure installation.
Image: A detailed view of the RAEFLOW Waterless Urinal, illustrating its dimensions (Height 15.7 in, Width 11.8 in, Depth 7.8 in). The image also clearly shows the included 1.5-meter hose and the mounting screws, providing a comprehensive visual of all components.
3. Safety Information
Please read and understand all safety instructions before installation and use. Failure to follow these guidelines may result in injury or product damage.
- Always wear appropriate personal protective equipment (PPE), such as gloves and eye protection, during installation.
- Ensure the mounting surface is stable and capable of supporting the urinal's weight, especially when in use.
- Keep the urinal and its components out of reach of children and pets.
- Do not use harsh chemicals or abrasive cleaners on the urinal, as this may damage the material.
- Ensure proper ventilation if installing in an enclosed space.
- Dispose of urine responsibly according to local regulations.
4. Setup and Installation
The RAEFLOW Waterless Urinal is designed for straightforward installation on various surfaces such as walls, poles, or fences. Follow these steps for optimal setup:
- Choose Location: Select a suitable location that is stable, provides adequate privacy, and allows for proper urine diversion. Consider both indoor (e.g., garage, workshop) and outdoor (e.g., garden, outhouse, camping site) environments.
- Mark Mounting Points: Hold the urinal against the desired mounting surface and use a pencil to mark the positions for the two mounting screws at the top of the unit.
- Drill Pilot Holes: Depending on your mounting surface (wood, brick, etc.), drill appropriate pilot holes at the marked points. Ensure the drill bit size is suitable for the provided screws.
- Secure Urinal: Align the urinal with the pilot holes and use the provided screws to firmly attach the unit to the surface. Note: Some users have reported issues with the included screws stripping. If you encounter resistance, consider using high-quality wood screws or appropriate anchors from your own toolbox for a more secure installation.
- Attach Urine Hose: Connect the 1.5-meter urine hose to the outlet at the bottom of the urinal. Ensure a snug fit to prevent leaks.
- Direct Urine: Route the hose to direct urine to a suitable collection container, a designated compost area, or directly into the ground away from water sources and sensitive areas. Ensure the hose has a continuous downward slope to facilitate drainage.
Image: The RAEFLOW Waterless Urinal demonstrating its versatility, installed both outdoors on a tree trunk and indoors on a wooden wall. This illustrates its suitability for various environments.
Image: A top-down perspective showing the installation process of the urinal. Two screws are visible, along with a screwdriver, indicating the points where the urinal is secured to a surface.
Image: The RAEFLOW Waterless Urinal mounted on a brick wall, with its hose extending downwards towards a grassy area, demonstrating a typical outdoor installation for urine diversion.
5. Operating Instructions
Using the RAEFLOW Waterless Urinal is simple and efficient:
- Position yourself comfortably in front of the urinal.
- Urinate directly into the urinal basin.
- The urine will flow through the internal drain and into the attached hose.
- Ensure the hose remains unobstructed to allow for continuous flow to your chosen diversion point or collection container.
- No flushing is required, as the design facilitates gravity-fed drainage.
Image: A collage of images depicting diverse environments suitable for the RAEFLOW Waterless Urinal, including a camping site, a garage, a backyard, and a construction site, highlighting its adaptability.
6. Maintenance and Cleaning
The RAEFLOW Waterless Urinal requires minimal maintenance due to its design. Regular cleaning will ensure hygiene and longevity:
- Regular Cleaning: Wipe down the interior and exterior surfaces of the urinal with a damp cloth and mild soap or a non-abrasive bathroom cleaner.
- Odor Control: While the waterless design helps minimize odors, you may use urinal cakes or natural odor absorbers if desired, especially in enclosed spaces.
- Hose Inspection: Periodically check the urine hose for any blockages or damage. Ensure it remains clear for proper drainage.
- UV Resistance: The urinal is constructed from UV-resistant material, making it suitable for prolonged outdoor exposure without significant degradation.
Image: The RAEFLOW Waterless Urinal mounted on a brick wall, illustrating its low maintenance aspect. The image shows the hose effectively diverting liquid waste away from the unit, emphasizing its self-composing function.
7. Troubleshooting
Refer to the following common issues and their solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Slow drainage or pooling urine | Hose kinked or obstructed; insufficient slope for drainage. | Check the hose for kinks or blockages and clear any debris. Ensure the hose has a continuous downward slope from the urinal to the discharge point. |
| Unpleasant odor | Infrequent cleaning; lack of ventilation; urine residue buildup. | Clean the urinal regularly with mild soap and water. Ensure adequate ventilation. Consider using urinal cakes or natural odor neutralizers. |
| Urinal feels loose after installation | Screws not fully secured; mounting surface not strong enough; screws stripped. | Re-tighten screws. If screws are stripped, replace them with higher quality screws or use appropriate wall anchors for your mounting surface. Ensure the mounting surface is robust. |
8. Specifications
| Feature | Detail |
|---|---|
| Brand | RAEFLOW |
| Model Number | P7816 |
| Color | Gray |
| Product Dimensions (L x W x H) | 7.8 x 11.8 x 15.7 inches |
| Item Weight | 2.26 pounds |
| Hose Diameter | 32 mm |
| Hose Length | 1.5 meters (approx. 4.9 feet) |
| UV Resistance | Yes |
| Included Components | Urinal unit, urine hose, mounting screws |
9. Warranty and Support
For any questions, concerns, or support regarding your RAEFLOW Waterless Urinal, please contact the manufacturer directly. While specific warranty details are not provided in this manual, RAEFLOW is committed to customer satisfaction.
Please refer to your purchase documentation or the RAEFLOW official website for the most current warranty information and customer service contact details.
