1. Product Overview
This document provides detailed instructions for the Aichiyu Flip Remote Key Fob, model HLO 1K0 959 753 P. This key fob is designed as a replacement or spare for compatible Volkswagen vehicles. It features four buttons for various functions and operates at a frequency of 315Mhz with an ID48 chip.
Image 1.1: The Aichiyu Flip Remote Key Fob, displaying its closed form and the internal circuit board when opened. This image illustrates the complete unit, including the remote buttons and the electronic components.
2. Compatibility
This remote key fob is compatible with specific Volkswagen models and years. It is crucial to verify that the FCC ID and Part Number match your original remote key fob to ensure proper functionality.
2.1 Key Specifications for Compatibility:
- FCC ID: NBG92596263
- Part Number: HLO 1K0 959 753 P / 1K0959753P
- Frequency: 315 Mhz
- Chip Type: ID48
- Buttons: 4 (Lock, Trunk, Unlock, Panic)
2.2 Compatible Vehicle Models:
- Volkswagen CC: 2009-2011
- Volkswagen Eos: 2007-2011
- Volkswagen Golf: 2006-2011
- Volkswagen Jetta: 2005-2011
- Volkswagen GTI: 2006-2011
- Volkswagen Rabbit: 2006-2009
- Volkswagen R32: 2008
- Volkswagen Tiguan: 2010
Important: Always compare the FCC ID and Part Number on your original remote with the specifications provided before purchase to ensure compatibility.
Image 2.1: The Aichiyu key fob displayed alongside a list of compatible Volkswagen vehicle models and their respective years. This visual aid helps users confirm if their vehicle is supported.
Image 2.2: A detailed view of the key fob's specifications, including FCC ID: NBG92596263 and Part Number: HLO 1K0 959 753 P. This image emphasizes the critical identifiers for compatibility verification.
3. Setup and Programming
This remote key fob requires professional programming and key cutting. Self-programming is not available for this device. Attempting to program it yourself may result in damage or improper function.
3.1 Programming Requirements:
- Professional Programming: The key fob must be programmed by a qualified automotive locksmith or a dealership using specialized diagnostic equipment.
- Key Blade Cutting: The included uncut emergency key blade must be cut to match your vehicle's ignition by a professional locksmith.
The key fob comes complete with a battery, chip, remote board, and an uncut emergency key, ready for professional setup.
Image 3.1: An exploded view of the key fob, revealing its internal components: the circuit board, the CR2032 battery, and the separate uncut key blade. This illustrates what is included for professional assembly and programming.
4. Operating Instructions
The Aichiyu Flip Remote Key Fob features four distinct buttons for controlling your vehicle's locking and security functions.
4.1 Button Functions:
- Lock Button: Press once to lock all vehicle doors.
- Unlock Button: Press once to unlock the driver's door, or twice to unlock all vehicle doors (may vary by vehicle configuration).
- Trunk Release Button: Press and hold to open the vehicle's trunk or tailgate.
- Panic Button: Located on the side, press to activate the vehicle's alarm system. Press again to deactivate.
Image 4.1: The Aichiyu key fob with clear labels pointing to each of its four buttons: Lock, Trunk Release, Unlock, and the side-mounted Panic Alarm button. This image visually explains the function of each control.
5. Maintenance
Proper care and maintenance will extend the lifespan of your remote key fob.
5.1 Battery Replacement:
The key fob uses one CR2032 battery, which is included. When the remote's range decreases or it stops responding, the battery may need replacement. Consult a professional or refer to your vehicle's owner's manual for specific instructions on how to safely open the fob and replace the battery without damaging internal components.
5.2 General Care:
- Material: The key fob is constructed from Acrylonitrile Butadiene Styrene (ABS), known for its durability.
- Cleaning: Wipe with a soft, dry cloth. Avoid harsh chemicals or abrasive materials.
- Protection: While designed to be scratch-resistant and durable, avoid dropping the key fob or exposing it to extreme temperatures or moisture.
Image 5.1: A composite image showcasing the key fob's quality attributes, including its high-quality construction, smooth surface finish, and resistance to scratches, ensuring original functionality over time.
6. Troubleshooting
If you encounter issues with your Aichiyu Flip Remote Key Fob, consider the following:
- Remote Not Responding:
- Check the battery. A weak or dead CR2032 battery is a common cause.
- Ensure the key fob was correctly programmed by a professional locksmith or dealer. Incorrect programming is a frequent issue.
- Vehicle Not Starting (after key cutting/programming):
- The immobilizer chip (ID48) may not have been correctly programmed to your vehicle. This requires specialized diagnostic tools available to professionals.
- Revisit the locksmith or dealer who performed the programming to diagnose the issue.
- Intermittent Functionality:
- Environmental interference can sometimes affect remote signals.
- Verify the key fob's FCC ID and Part Number still match your vehicle's requirements.
Note: Since self-programming is not supported, most troubleshooting steps will involve consulting a qualified automotive locksmith or dealership.
7. Specifications
| Feature | Detail |
|---|---|
| Brand | Aichiyu |
| Model Name | Flip Remote Key Fob Replacement |
| Model Number | HLO 1K0 959 753 P / 1K0959753P |
| FCC ID | NBG92596263 |
| Frequency | 315 MHz |
| Chip Type | ID48 |
| Number of Buttons | 4 (Unlock, Trunk, Lock, Panic) |
| Battery Type | CR2032 (included) |
| Material | Acrylonitrile Butadiene Styrene (ABS) |
| Item Weight | 1.76 ounces (0.05 Kilograms) |
| Package Dimensions | 4.41 x 2.87 x 0.59 inches |
8. Warranty and Support
For information regarding warranty coverage, technical support, or any product-related inquiries, please contact Aichiyu customer service directly. Details can typically be found on the product packaging or the manufacturer's official website.
