LEMBERI APFP-2F
LEMBERI 72-inch Electric Fireplace User Manual (Model APFP-2F)
Brand: LEMBERI | Model: APFP-2F
Introduction
This manual provides detailed instructions for the safe operation, installation, and maintenance of your LEMBERI 72-inch Electric Fireplace. Please read all instructions carefully before use and retain this manual for future reference.
Safety Information
Your LEMBERI Electric Fireplace is ETL Certificate Approved, ensuring it meets recognized safety standards. It is equipped with an auto-heat kill safety feature to prevent overheating. Always ensure proper ventilation and follow all local electrical codes during installation.
- Do not block air vents.
- Keep flammable materials away from the heater.
- Ensure the power cord is not pinched or damaged.
- Unplug the fireplace before cleaning or maintenance.
Product Features
- Adjustable Flame: 12 flame colors, 5 flame speed modes, and 5 flame brightness levels.
- Adjustable Flame Bed: 12 flame bed colors.
- Heating Modes: 750 Watts and 1500 Watts, with a fan-only option for flame display without heat.
- Control: Touch screen control panel and remote control.
- Timer: Programmable timer function.
- Installation: Recessed, semi-recessed, or wall-mounted options.
- Slim Design: Only 3.2 inches thick, 20% thinner than comparable models.
- Unique Three-Hole Design: Provides stronger airflow, even heat distribution, and faster heating.
Setup and Installation
The LEMBERI 72-inch Electric Fireplace offers versatile installation options to suit your space. It can be recessed into a wall, semi-recessed, or wall-mounted.
Dimensions and Recess Requirements
For recessed installation, ensure the wall opening matches the specified dimensions. The slim 3.2-inch depth allows for a sleek, integrated look. For wall-mounted installation, securely fasten the unit to wall studs using appropriate hardware.
The fireplace can be plugged into a standard electrical outlet or hardwired by a qualified electrician, depending on your installation preference and local codes.
Operating Instructions
Your LEMBERI Electric Fireplace can be operated using the integrated touch screen control panel or the included remote control.
Control Panel and Remote Functions
- Power ON/OFF: Press the power button on the remote or touch panel to turn the unit on or off.
- Heater Settings: Select between 750 Watts and 1500 Watts for heating. The fireplace can also display flames without activating the heater.
- Flame Color: Cycle through 12 different flame colors to match your ambiance.
- Flame Bed Color: Choose from 12 different colors for the crystal flame bed.
- Flame Speed: Adjust the flame movement speed with 5 available settings.
- Flame Brightness: Control the intensity of the flames with 5 brightness levels.
- Timer: Set the operational timer from 1 to 8 hours.
Maintenance
To ensure the longevity and optimal performance of your LEMBERI Electric Fireplace, regular maintenance is recommended.
- Cleaning: Ensure the unit is unplugged and cool before cleaning. Use a soft, damp cloth to wipe down the exterior. Do not use abrasive cleaners or sprays.
- Air Vents: Periodically check and clean the air intake and exhaust vents to prevent dust buildup, which can impede airflow and heating efficiency.
- Internal Components: For any internal maintenance, it is recommended to contact qualified service personnel.
Troubleshooting
If you encounter issues with your LEMBERI Electric Fireplace, refer to the following common troubleshooting steps:
| Problem | Possible Cause | Solution |
|---|---|---|
| No power/Unit does not turn on. | Power cord unplugged, circuit breaker tripped, or power switch off. | Check power connection, reset circuit breaker, ensure main power switch is on. |
| No heat output. | Heater function not activated, or thermostat setting too low. | Activate heater mode (750W/1500W) and increase thermostat setting. Ensure fan vents are clear. |
| Flames not visible or flickering incorrectly. | Flame effect motor issue or LED light malfunction. | Check flame brightness and speed settings. If issue persists, contact customer support. |
| Unusual noise from the unit. | Internal components rubbing (e.g., flame effect fins). | Ensure the unit is installed correctly and no internal components are obstructed. Refer to the video for potential fin adjustment. |
Addressing Unusual Noises
Some users have reported unusual noises, often caused by the internal fins of the flame effect mechanism rubbing against the back panel. The manufacturer suggests ensuring these fins are vertical and straight. If they are bent, carefully adjust them to prevent contact.
Specifications
| Feature | Detail |
|---|---|
| Brand | LEMBERI |
| Model Name | APFP-2F |
| Power Source | Electric |
| Product Dimensions | 72"W x 18.11"H x 3.25"D (Based on diagram, note: product data listed 1"D x 1"W x 1"H) |
| Material | Alloy Steel |
| Finish Type | Polished |
| Installation Type | Wall Mount (also Recessed/Semi-Recessed) |
| Heat Output | 5120 BTU per Hour (Note: original data listed unusual unit, simplified to BTU/hr) |
| Special Feature | Adjustable Flame, Dimmer, Flame Effect, Multicolor Flame, Timer |
| Color | Black |
| Room Type | Living Room |
| Ventilation Type | Vent Free |
| Heating Coverage | Up to 400 sq ft (Estimated for 1500W heater, note: original data listed 5 sq ft which is likely incorrect) |
| Included Components | Remote Control |
| Item Weight | Approx. 50-70 lbs (Estimated for 72-inch unit, note: original data listed 1 Pound) |
| Burner type | Quartz |
| Size | 72 inch |
Warranty and Support
The LEMBERI Electric Fireplace comes with a Limited Warranty. For specific warranty terms, conditions, and to register your product, please refer to the documentation included with your purchase or visit the official LEMBERI website. For technical support or service inquiries, please contact LEMBERI customer service.
