1. Introduction
This manual provides essential information for the safe and efficient operation of your Aufun 8KW 12V Diesel Air Heater. Please read it thoroughly before installation and use. This heater is designed to provide warmth for various vehicles, including trucks, vans, RVs, and boats, and can also assist in defrosting windows.
Image 1.1: The Aufun Diesel Air Heater is suitable for a wide range of vehicles, providing versatile heating solutions.
2. Safety Information
Always prioritize safety when installing and operating the diesel air heater. Failure to follow safety instructions can result in property damage, injury, or death.
- Ensure proper ventilation during operation to prevent carbon monoxide buildup.
- Install the exhaust pipe securely and ensure it directs exhaust gases safely away from the vehicle's interior and any occupied spaces.
- Do not operate the heater in enclosed, unventilated areas.
- Keep flammable materials away from the heater and its exhaust system.
- Regularly inspect fuel lines and electrical connections for leaks or damage.
- Ensure the heater is securely mounted to prevent movement during vehicle operation.
- Only use diesel fuel. Do not use gasoline or other volatile fuels.
- Disconnect power before performing any maintenance or repairs.
3. Package Contents
Verify that all components are present and undamaged upon unpacking. The package typically includes:
- 1x Diesel Air Heater Unit
- 1x LCD Switch
- 1x Remote Control
- 1x Muffler
- 1x Exhaust Pipe
- 1x Air Filter
- 1x Air Outlet Pipe
- 1x Induction Pipe
- Mounting Accessories (clamps, screws, brackets)
- 1x User Manual (this document)
Image 3.1: Main unit and all included accessories for the Aufun 8KW 12V Diesel Air Heater.
Image 3.2: Visual representation of the accessory list, including the rotary vent, exhaust pipe, muffler, air filter, air outlet pipe, remote control, induction pipe, and installation kit.
4. Specifications
| Rated Power | 8 KW |
| Rated Voltage | 12 V |
| Fuel Type | Diesel |
| Tank Capacity | 5 L |
| Fuel Consumption | 0.18-0.48 L/h |
| Product Dimensions | 42 x 41 x 15.5 cm (approx. 16.5 x 16.1 x 6.1 inches) |
| Operating Temperature | -40 °C to +50 °C (-40 °F to +122 °F) |
| Remote Control Effective Distance | 10-20 meters (33-66 feet) |
| Overheat Protection | 240 °C (464 °F) |
| Model Number | HAG4190E |
| Item Weight | 9 Kilograms (approx. 19.8 lbs) |
Image 4.1: Side view of the heater showing approximate dimensions: 15.7 inches (40cm) length, 9.8 inches (25cm) width, and 12.2 inches (31cm) height.
5. Setup and Installation
Proper installation is critical for the safe and effective operation of your heater. It is recommended that installation be performed by a qualified professional if you are unsure about any steps. This section provides general guidelines; refer to the detailed installation diagram (if provided separately) for specific mounting points and connections.
- Choose a Location: Select a stable, flat surface for mounting the heater, ensuring adequate clearance for air intake and exhaust. The location should be protected from direct water exposure.
- Mount the Heater: Secure the main unit using the provided brackets and screws. Ensure it is firmly attached to prevent vibration and movement.
- Connect Exhaust System: Attach the exhaust pipe to the heater's exhaust port and route it safely outside the vehicle. Use the muffler to reduce noise. Ensure no exhaust gases can re-enter the vehicle.
- Connect Air Intake and Outlet: Attach the air filter to the air intake pipe and connect it to the heater. Connect the air outlet pipe to direct warm air into the desired space.
- Fuel Connection: Connect the fuel line from the heater to the diesel tank. Ensure all connections are tight and leak-free. The integrated fuel tank should be filled with diesel fuel, ensuring it is not overfilled and the cap is securely fastened.
- Electrical Connection: Connect the heater to a 12V power source. Ensure correct polarity and secure connections. It is advisable to connect through a fuse for circuit protection.
- Initial Start-up: After installation, perform a test run. Monitor for any unusual noises, smells, or leaks.
Image 5.1: The heater features an LCD display for monitoring and a remote control for convenient operation, even from a distance.
6. Operating Instructions
The Aufun diesel air heater can be operated via its integrated LCD control panel or the provided remote control.
6.1. LCD Control Panel
- Power On/Off: Press and hold the power button (usually marked with a power symbol) to turn the heater on or off.
- Temperature Adjustment: Use the up/down arrows to set the desired temperature. The LCD will display the current and target temperatures.
- Mode Selection: Some models may have different operating modes (e.g., fan only, heating). Refer to the specific icons on your LCD for mode selection.
- Monitoring: The LCD displays various parameters such as current temperature, fan speed, and fuel level.
6.2. Remote Control
The remote control allows for convenient operation from a distance (up to 10-20 meters).
- Power: Use the designated power button to turn the heater on or off.
- Temperature/Power Adjustment: Buttons are typically available to increase or decrease the heating power or target temperature.
- Lock/Unlock: Some remotes may have a lock function to prevent accidental changes.
Important: Ensure the fuel tank has sufficient diesel before operation. The heater features ceramic glow plugs for rapid ignition and complete combustion, ensuring efficient heating and low emissions.
Image 6.1: Illustrates the benefit of the heater, showing a cold, snowy car interior before use (-5°C/23°F) and a warm, defrosted interior after use (20°C/68°F), enabling safe driving.
Image 6.2: The heater operating quietly, providing warmth to a sleeping person in a truck cabin, highlighting its low noise level and comfort.
7. Maintenance
Regular maintenance ensures the longevity and efficient operation of your diesel air heater.
- Fuel Filter: Periodically check and clean or replace the fuel filter to prevent blockages.
- Air Filter: Inspect and clean the air filter regularly to ensure proper airflow and prevent dust accumulation.
- Exhaust System: Check the exhaust pipe and muffler for any blockages, corrosion, or damage. Ensure all connections are secure.
- Electrical Connections: Verify that all electrical connections are tight and free from corrosion.
- General Cleaning: Keep the exterior of the heater clean and free from debris.
- Fuel Tank: Ensure the fuel tank is clean and free of contaminants.
8. Troubleshooting
If you encounter issues with your heater, refer to the following common troubleshooting steps:
- Heater Not Starting:
- Check 12V power supply and connections.
- Ensure sufficient fuel in the tank.
- Verify the fuel line is not blocked or kinked.
- Check for error codes on the LCD display and consult the full manual for their meaning.
- Low Heat Output:
- Inspect air intake and outlet for obstructions.
- Clean or replace the air filter.
- Ensure the heater is set to the correct temperature or power level.
- Excessive Smoke:
- Check fuel quality.
- Inspect exhaust system for blockages.
- This may indicate incomplete combustion; professional inspection may be required.
- Unusual Noises:
- Check for loose components or mounting.
- Ensure fan is not obstructed.
For persistent issues or complex repairs, contact customer support or a qualified technician.
9. Warranty and Support
For warranty information, technical support, or to purchase replacement parts, please refer to the contact details provided with your purchase documentation or visit the official Aufun website. Keep your purchase receipt as proof of purchase for warranty claims.
