RecorCam HC-808A Trail Camera User Manual

1. Introduction

Welcome to the RecorCam HC-808A Trail Camera User Manual. This guide provides comprehensive instructions for the setup, operation, and maintenance of your new trail camera. Please read this manual thoroughly before using the device to ensure proper functionality and to maximize its lifespan.

The RecorCam HC-808A is designed for wildlife monitoring, hunting, farm surveillance, and home security, offering high-quality images and videos with advanced features like rapid trigger speed and night vision capabilities.

2. Product Overview

2.1 Key Features

• High Resolution: Captures 24MP still images and 1080P Full HD videos with audio.
• Fast Trigger Speed: Ultra-fast 0.3-second trigger speed with 3 PIR motion sensors.
• Wide Angle Detection: 1200 wide-angle lens and 82ft (25m) detection range.
• Advanced Night Vision: 850nm low-glow infrared LEDs for clear night recordings up to 65ft (20m) without disturbing wildlife.
• Durable Design: IP66 waterproof rating ensures reliable operation in various weather conditions.
• Multi-functional Modes: Supports video delay, target recording time, time lapse, continuous recording, audio recording, and password protection.
• Display: Built-in 2.0-inch LCD screen for easy setup and playback.

2.2 Package Contents

Please verify that all items listed below are included in your package:

• RecorCam HC-808A Trail Camera x1
• USB Cable x1
• Wall Mounting Bracket x1
• Fasten Strap x1
• Screw Package x1
• User Manual x1
• 8GB SD Card x1 (may vary by package)

3. Setup

3.1 Battery Installation

1. Open the camera's casing by unlatching the side clips.
2. Locate the battery compartment.
3. Insert 8 AA batteries (not included) according to the polarity indicators (+/-) inside the compartment.
4. Close the battery compartment cover securely.

3.2 SD Card Installation

1. Ensure the camera is powered off.
2. Locate the SD card slot, usually next to the battery compartment.
3. Insert a Micro SD card (up to 32GB, Class 10 recommended) into the slot with the gold contacts facing down until it clicks into place.
4. To remove, gently push the card until it springs out.

3.3 Mounting the Camera

The camera can be mounted using the provided strap or the wall mounting bracket.

Using the Fasten Strap:

1. Thread the strap through the slots on the back of the camera.
2. Secure the camera to a tree or pole at the desired height and angle.
3. Ensure the camera is stable and pointed towards the area you wish to monitor.

Using the Wall Mounting Bracket:

1. Choose a suitable mounting surface.
2. Use the provided screws to attach the bracket to the surface.
3. Attach the camera to the bracket and adjust the angle as needed.

4. Operating the Camera

4.1 Powering On/Off

• To power on, slide the mode switch from OFF to TEST or ON.
• In TEST mode, you can access the menu and adjust settings.
• In ON mode, the camera will begin monitoring based on your settings.
• To power off, slide the mode switch to OFF.

4.2 Mode Selection and Menu Navigation

The camera features a 2.0-inch LCD screen for easy navigation and setting adjustments.

• In TEST mode, press the MENU button to enter the settings menu.
• Use the UP/DOWN arrows to navigate through options and LEFT/RIGHT arrows to change values.
• Press OK to confirm selections.

4.3 Recording Settings

Adjust the following settings in the menu to customize your recording preferences:

• Mode: Select Photo, Video, or Photo+Video.
• Photo Resolution: Choose from 24MP, 20MP, 16MP, 12MP, or 8MP for still images.
• Video Resolution: Set to 1080P for high-definition video recording.
• PIR Sensitivity: Adjust the sensitivity of the motion sensors (Low, Medium, High) based on the environment.
• Trigger Interval: Set the delay between consecutive triggers.
• Time Lapse: Enable time lapse mode for capturing events over extended periods.
• Timer Recording: Schedule specific times for the camera to be active.
• Burst Images: Configure the number of photos taken per trigger in photo mode.

4.4 Viewing Files

You can view captured photos and videos directly on the camera's LCD screen or by connecting the camera to a computer.

On Camera Playback:

• In TEST mode, press the PLAY button to enter playback mode.
• Use the UP/DOWN arrows to browse through files.
• Press OK to play videos or view photos.

Connecting to a Computer:

1. Connect the camera to your computer using the provided USB cable.
2. The camera will appear as a removable disk.
3. Open the disk to access the DCIM folder, where your photos and videos are stored.

5. Maintenance

5.1 Cleaning the Camera

• Use a soft, dry cloth to clean the camera body.
• For the lens and PIR sensors, use a lens cleaning cloth and solution to avoid scratches.
• Do not use abrasive cleaners or solvents.

5.2 Battery and SD Card Management

• Replace batteries when the low battery indicator appears or when performance degrades.
• Regularly format the SD card through the camera's menu to ensure optimal performance and prevent data corruption. Back up important files before formatting.

5.3 Water Resistance (IP66)

The RecorCam HC-808A is rated IP66 waterproof, protecting it from dust and powerful water jets. While it is designed for outdoor use in various weather conditions, avoid submerging the camera in water.

6. Troubleshooting

7. Specifications

8. Warranty and Support

RecorCam products are manufactured to high-quality standards. For any questions, technical support, or warranty claims, please contact RecorCam customer service through the retailer where you purchased the product or visit the official RecorCam website for contact information.

Please retain your proof of purchase for warranty purposes.
