STHOUYN BBYZX18

STHOUYN Comfy Floor Chair with 2 USB Charging Ports

Model: BBYZX18

User Manual

1. Safety Instructions

  • Weight Capacity: Do not exceed a weight capacity of 300 lbs (136 kg) to ensure stability and longevity of the product.
  • Stable Surface: Always place the chair on a stable, level surface.
  • Adjustable Mechanisms: Keep fingers away from adjustable mechanisms while changing positions to prevent injury.
  • Children: Supervise children when they are using the chair.
  • Cleaning: Follow maintenance instructions for cleaning to avoid damage to materials.
  • Damage: Do not use the chair if any part is damaged or broken. Contact customer support for replacement parts.

2. Package Contents

Ensure all components are present before assembly:

  • Floor Chair Unit (1)
  • Removable Armrests (2)
  • USB Charging Cable (1)
  • Assembly Screws (Long)
  • L-Wrench (1)
  • User Manual (1)

3. Setup

The STHOUYN Comfy Floor Chair requires minimal assembly. Follow these steps:

  1. Unpack Components: Carefully remove all parts from the packaging.
  2. Attach Armrests: Align the armrests with the designated holes on the sides of the chair. Use the provided long screws and L-wrench to secure them. Ensure they are tightened firmly. The armrests are removable and can be positioned on either side as preferred.
  3. Position Floor Protector: A protective bag is included to cover the metal base of the chair. This prevents scratches on your floor. Place the chair on the floor protector.
  4. Connect USB Cable: Plug the USB charging cable into the designated ports on the armrest and connect the other end to a power source (e.g., wall adapter, power bank).
Image showing the STHOUYN floor chair with USB ports and dimensions.

Image: STHOUYN floor chair with USB ports and dimensions. The image highlights the two USB charging ports on the armrest and provides detailed measurements of the chair in various configurations.

4. Operation

4.1 Adjusting the Backrest

The chair features a 5-position adjustable backrest, ranging from 90° to 180° (flat). To adjust:

  1. Push the backrest forward until you hear a click, releasing the locking mechanism.
  2. Slowly recline the backrest to your desired angle. You will hear clicks as it locks into each position.
  3. To flatten the chair completely, push the backrest all the way forward until it releases, then lay it flat.
Image showing the 5-angle adjustment backrest of the STHOUYN floor chair.

Image: The 5-angle adjustment backrest of the STHOUYN floor chair. This visual guide demonstrates how to unlock, set the level, and lock the backrest into various positions for activities like watching TV, reading, gaming, or sleeping.

4.2 Using USB Charging Ports

The chair is equipped with two USB charging ports for convenience:

  • Connect your devices (e.g., smartphone, tablet) to the USB ports using their respective charging cables.
  • Ensure the chair's main power cable is connected to a wall outlet or power bank.
  • The ports provide standard charging speeds.
Image showing the two USB charging ports on the armrest of the STHOUYN floor chair.

Image: Close-up of the two USB charging ports on the armrest of the STHOUYN floor chair. A smartphone is shown connected and charging, illustrating the convenience of the integrated charging feature.

4.3 Swivel Function

The chair features a 360-degree swivel base:

  • Simply rotate the chair in any direction while seated.
  • The swivel base is designed for smooth and easy movement.

Video: This video demonstrates the STHOUYN Convertible Sleeper Chair Bed with USB. It shows the chair's 360-degree swivel function and its ability to convert into different positions, including a floor chair, chaise lounge, and flat sleeping surface. The integrated USB charging ports are also highlighted.

4.4 Folding and Storage

For compact storage, the chair can be folded:

  1. Ensure the backrest is in the fully upright position.
  2. Push the backrest forward until it folds completely over the seat.
  3. The chair will then be in a compact, folded state for easy storage in cabinets or small spaces.
Image showing the STHOUYN floor chair folded for compact storage.

Image: The STHOUYN floor chair folded for compact storage. This image illustrates how the chair can be easily collapsed to save space, making it convenient for storage in smaller living areas.

5. Maintenance

5.1 Cleaning

To maintain the chair's appearance and longevity:

  • Spot Cleaning: For minor spills, wipe clean with a damp cloth and mild detergent.
  • Removable Cover: The fabric cover is attached with Velcro and can be easily disassembled for cleaning. Refer to the care label for specific washing instructions.
  • Avoid Harsh Chemicals: Do not use abrasive cleaners or harsh chemicals, as these may damage the fabric.

5.2 General Care

  • Regularly check all screws and connections to ensure they are tight.
  • Avoid prolonged exposure to direct sunlight to prevent fading of the fabric.
  • Keep sharp objects away from the chair to prevent tears or punctures.

6. Troubleshooting

ProblemPossible CauseSolution
Backrest does not adjust or lock.Mechanism is stuck or not fully disengaged.Push the backrest fully forward until it clicks, then recline slowly. Ensure no obstructions are present.
USB ports not charging.Power cable not connected or faulty device cable.Ensure the chair's power cable is securely plugged in. Test with a different device cable or power source.
Chair feels unstable or wobbly.Loose assembly screws.Check and tighten all assembly screws, especially those on the armrests and base. Ensure the chair is on a level surface.
Swivel function is stiff.Debris in the swivel mechanism or lack of lubrication.Clean any visible debris from the swivel base. Apply a silicone-based lubricant if necessary (avoid oil-based lubricants).

7. Specifications

  • Brand: STHOUYN
  • Model Name: floor chair
  • Model Number: BBYZX18
  • Color: Navy Blue
  • Material: Metal & Fabric (Linen surface, Sponge fill)
  • Product Dimensions (Folded): 22.4"D x 26"W x 26.77"H
  • Product Dimensions (Flat): 26.0"W x 71.3"L
  • Item Weight: 23.3 pounds
  • Weight Capacity: 300 lbs
  • Reclining Positions: 5 (90° to 180°)
  • Special Features: Adjustable, Durable, Foldable, Removable Armrests, 2 USB Charging Ports, 360° Swivel Base
  • Room Type: Bedroom, Living Room, Dormitory, Tatami Room, Company Lounge

8. Warranty and Support

For warranty information, please refer to the product's original purchase documentation or contact STHOUYN customer service. If you encounter any issues or have questions regarding your STHOUYN Comfy Floor Chair, please reach out to our support team for assistance.

Customer Service: [Insert Customer Service Contact Information Here, e.g., email, phone number, website]
