HUNICOM H-628 Rechargeable Walkie-Talkie User Manual

1. Introduction

Thank you for choosing the HUNICOM H-628 Rechargeable Walkie-Talkie. This device is designed for reliable two-way communication, offering features such as long-range PMR, a built-in flashlight, VOX functionality, and a durable 1200 mAh battery. Please read this manual carefully to ensure proper operation and to maximize your user experience.

2. Safety Information

  • Do not operate the radio in explosive atmospheres (e.g., flammable gases, dust particles, metallic powders).
  • Do not modify or disassemble the radio. Repairs should only be performed by authorized personnel.
  • Use only HUNICOM approved batteries and chargers. Improper use may cause fire, explosion, or injury.
  • Avoid exposing the radio to direct sunlight for extended periods or to extreme temperatures.
  • Keep the radio away from medical devices such as pacemakers, as it may interfere with their operation.
  • Do not immerse the radio in water, despite its water-resistant design.

3. Package Contents

Please check the package for the following items:

  • HUNICOM H-628 Walkie-Talkie Unit(s)
  • 1200 mAh Lithium-ion Battery Pack(s)
  • Charging Cable (USB)
  • Belt Clip(s)
  • User Manual (This document)

4. Product Features

  • PMR Two-Way Communication: Reliable communication over distances up to 5 KM (unobstructed).
  • 16 Channels: Multiple channels for clear communication.
  • 1200 mAh Rechargeable Battery: Provides extended operating time.
  • Built-in Flashlight: For illumination in low-light conditions.
  • VOX Function: Voice-activated transmission for hands-free operation.
  • LCD Display: Clear display of channel, battery status, and other settings.
  • Water-resistant Design: Suitable for outdoor use in various weather conditions.
Two HUNICOM H-628 walkie-talkies in a night setting, demonstrating the built-in flashlight and LCD display. One unit shows the front with the screen and buttons, the other shows the back with the battery compartment. A person is visible in the background, illuminated by a flashlight.

Image: HUNICOM H-628 walkie-talkies demonstrating the 1200mAh rechargeable battery, LCD display, and flashlight for night use.

An illustration showing communication range capabilities of the HUNICOM H-628 walkie-talkie in different environments: up to 5 KM without obstacles, 3 KM in open areas with trees, and 1 KM inside a house. Silhouettes of hikers are visible in the background.

Image: Illustration of the HUNICOM H-628's communication range: 5 KM without obstacles, 3 KM in open areas, and 1 KM indoors.

A collage of three images depicting various outdoor and recreational activities where the HUNICOM H-628 walkie-talkie can be used: hiking in mountains, cycling in a group, and a soccer match.

Image: Examples of outdoor activities, adventure, and sports entertainment where the HUNICOM H-628 walkie-talkie can be utilized.

5. Product Overview (Controls)

Detailed close-up views of the HUNICOM H-628 walkie-talkie, showing the front panel with MENU, LAMP, and MON buttons, the Push-To-Talk (PTT) button on the side, and the speaker/microphone (SP/MIC) port.

Image: Detailed views of the HUNICOM H-628 walkie-talkie controls, including MENU, LAMP, MON, PTT, and SP/MIC.

  • Antenna: For transmitting and receiving signals.
  • Rotary Knob (Top): Power ON/OFF and Volume adjustment.
  • LCD Display: Shows channel, battery level, and other indicators.
  • MENU Button: Accesses and navigates the radio's settings menu.
  • Up/Down Buttons (Arrows): Used for channel selection and menu navigation.
  • LAMP Button: Activates the built-in flashlight.
  • MON (Monitor) Button: Temporarily disables squelch to listen to weak signals.
  • PTT (Push-To-Talk) Button: Press and hold to transmit, release to receive.
  • SP/MIC (Speaker/Microphone): Integrated speaker and microphone for audio.
  • Charging Port: For connecting the USB charging cable.

6. Setup

6.1 Battery Installation

  1. Ensure the walkie-talkie is powered off.
  2. Locate the battery compartment cover on the back of the unit.
  3. Slide the cover down or unclip it to open.
  4. Insert the 1200 mAh Lithium-ion battery pack, ensuring the contacts align correctly.
  5. Replace the battery compartment cover and secure it.

6.2 Charging the Battery

  1. Connect the USB charging cable to the charging port on the walkie-talkie.
  2. Connect the other end of the USB cable to a compatible USB power adapter (not included) or a computer USB port.
  3. The battery indicator on the LCD will show charging status.
  4. Once fully charged, disconnect the charging cable.

6.3 Power On/Off and Volume Adjustment

Front and back view of the HUNICOM H-628 walkie-talkie, highlighting the top rotary knob. An arrow indicates turning the knob to power on/off and adjust volume.

Image: HUNICOM H-628 walkie-talkie showing the rotary knob for power and volume control.

  1. To power on the radio, rotate the top rotary knob clockwise until you hear a click. The LCD will light up.
  2. Continue rotating the knob clockwise to increase the volume. Rotate counter-clockwise to decrease the volume.
  3. To power off, rotate the knob counter-clockwise until you hear a click and the LCD turns off.

7. Operating Instructions

7.1 Channel Selection

  1. With the radio powered on, press the MENU button once. The channel number on the LCD will flash.
  2. Use the Up or Down arrow buttons to select your desired channel (1-16).
  3. Press the MENU button again to confirm the selection and exit the channel setting mode.

7.2 Transmitting and Receiving (PTT)

  1. Ensure your radio is on the same channel as the other party.
  2. To transmit, press and hold the PTT button located on the side of the radio. Speak clearly into the microphone.
  3. Release the PTT button to stop transmitting and listen for a response.

7.3 VOX Function (Voice-Activated Transmission)

The VOX function allows you to transmit without pressing the PTT button, by simply speaking into the microphone.

  1. Press the MENU button repeatedly until the VOX setting appears on the LCD.
  2. Use the Up or Down arrow buttons to select the VOX sensitivity level (e.g., 1-3, with 3 being most sensitive) or to turn VOX off.
  3. Press MENU to confirm and exit.

7.4 Flashlight Operation

To use the built-in flashlight:

  • Press the LAMP button once to turn the flashlight on.
  • Press the LAMP button again to turn the flashlight off.

7.5 Monitor Function

The Monitor function allows you to listen to weak signals or to check for activity on a channel without the squelch filtering them out.

  • Press and hold the MON button to temporarily disable the squelch.
  • Release the MON button to re-enable squelch.

8. Maintenance

8.1 Cleaning

  • Wipe the radio surface with a soft, damp cloth. Do not use harsh chemicals or abrasive cleaners.
  • Ensure the charging port is free of dust and debris.

8.2 Battery Care

  • Charge the battery fully before first use.
  • Do not overcharge or deep discharge the battery.
  • If storing the radio for an extended period, remove the battery and store it in a cool, dry place.

8.3 Storage

  • Store the radio in a dry, dust-free environment.
  • Avoid extreme temperatures and direct sunlight.

9. Troubleshooting

  • No Power: Check if the battery is installed correctly and fully charged. Ensure the rotary knob is turned to the ON position.
  • Cannot Transmit or Receive: Verify that both radios are on the same channel. Check battery level. Ensure the PTT button is pressed fully when transmitting.
  • Poor Audio Quality/Static: Move closer to the other radio. Check for obstructions. Ensure the antenna is securely attached. Adjust volume.
  • Short Range: Obstacles like buildings, hills, and dense foliage can significantly reduce range. Move to a more open area.
  • VOX Not Working: Check VOX sensitivity settings in the menu. Ensure the microphone is not obstructed.

10. Specifications

  • Brand: HUNICOM
  • Model Number: H-628
  • Color: Orange
  • Number of Channels: 16
  • Maximum Range: Up to 5 Kilometers (unobstructed)
  • Battery Type: Lithium-ion
  • Battery Capacity: 1200 mAh
  • Rechargeable: Yes
  • Voltage: 1.5 Volts (Internal operating voltage, battery voltage may differ)
  • Water Resistance: Water-resistant (not submersible)
  • Approximate Weight: 90 Grams (per unit, without battery)
  • Compatible Devices: UHF two-way radios with compatible frequency range
  • Manufacturer: Shenzhen JIZHIDA Technology Co., Ltd.

11. Warranty and Support

HUNICOM products are designed for reliability and performance. For warranty information, technical support, or service inquiries, please refer to the contact information provided with your purchase or visit the official HUNICOM website. Please retain your proof of purchase for warranty claims.
