AMZASA AS9012-4BK Farmhouse Lantern Chandelier Instruction Manual

Model: AS9012-4BK

1. Safety Information

Please read and understand this entire manual before attempting to assemble, install, or operate this product. Failure to do so may result in electric shock, fire, or other injuries that can be hazardous or even fatal.

  • WARNING: Risk of electric shock. Turn off power at the main circuit breaker or fuse box before starting installation or performing any maintenance.
  • All electrical connections must be in accordance with local codes and the National Electric Code (NEC). If you are unfamiliar with proper electrical wiring connections, consult a qualified electrician.
  • This fixture is designed for indoor use only. Do not expose to water or moisture.
  • Ensure the mounting surface is capable of supporting the weight of the fixture.
  • Use only the specified bulb type and wattage. Refer to the Specifications section for details.
  • This product is UL Listed, ensuring it meets specific safety standards.

2. Package Contents

Carefully unpack the fixture and check that all parts are included. If any parts are missing or damaged, contact customer service before proceeding.

  • Light Fixture (1)
  • Mounting Hardware (screws, wire nuts, etc. - specific components may vary)
  • Instruction Manual (1)
Detailed view of chandelier components including canopy, chain, frame, and bulb sockets.
Image 1: Detailed view of the chandelier's components, showing the ceiling canopy, adjustable chain, main frame, and four E12 bulb sockets.

3. Specifications

BrandAMZASA
Model NameAS9012-4BK
ColorBlack
MaterialIron
StyleFarmhouse, Industrial, Rustic
Fixture Dimensions (H x W)17.5" x 11.8"
Adjustable Chain LengthMax 48.4"
Total Max Height65.9"
Item Weight7 Pounds
Number of Light Sources4
Bulb BaseE12
Maximum Compatible Wattage40 Watts per bulb (160 Watts total)
Voltage110 Volts
Installation TypePendant Light (Hanging)
Indoor/Outdoor UsageIndoor
CertificationUL Listed
Diagram showing the dimensions of the AMZASA AS9012-4BK chandelier, including a width of 11.8 inches, a fixture height of 17.5 inches, and an adjustable chain length up to 48.4 inches.
Image 2: Dimensional diagram of the chandelier, illustrating its width, fixture height, and the maximum adjustable chain length.

4. Installation Instructions

Before You Begin:

  • Turn off electrical power at the main fuse box or circuit breaker.
  • Consult a qualified electrician if you are not experienced with electrical wiring.
  • Ensure you have all necessary tools (screwdriver, wire strippers, electrical tape, etc.).

4.1. Assembly

  1. Carefully remove the fixture from its packaging.
  2. Attach the main frame components if they are not pre-assembled.
  3. Connect the adjustable chain to the fixture and the canopy. Adjust the chain length to your desired hanging height. The chain can be adjusted up to 48.4 inches.
  4. Insert four E12 base bulbs (not included) into the sockets. Do not exceed 40 watts per bulb.
The AMZASA AS9012-4BK Farmhouse Lantern Chandelier with four E12 bulbs installed, ready for mounting.
Image 3: The assembled chandelier with bulbs, showcasing its design before final installation.

4.2. Mounting

  1. Secure the mounting bracket to the junction box in the ceiling using the provided screws.
  2. Connect the fixture's wires to the house wiring:
    • Connect the black wire from the fixture to the black (hot) wire from the junction box.
    • Connect the white wire from the fixture to the white (neutral) wire from the junction box.
    • Connect the bare copper or green ground wire from the fixture to the ground wire from the junction box.
    • Secure all connections with wire nuts and electrical tape.
  3. Carefully tuck all wires into the junction box.
  4. Attach the canopy to the mounting bracket, securing it with the provided hardware.
  5. This fixture is suitable for installation on sloped, flat, or vaulted ceilings.
Close-up view of the four E12 candle-style bulbs within the black lantern chandelier frame.
Image 4: A close-up of the four E12 bulb sockets, highlighting the candle-style bulbs.

5. Operation

Once installed, restore power at the circuit breaker. The chandelier is operated via a standard wall switch (not included). The fixture is designed for E12 LED bulbs, which provide a warm light ambiance.

Comparison image showing the AMZASA AS9012-4BK chandelier both illuminated (ON) and unilluminated (OFF), demonstrating its appearance in both states.
Image 5: Visual representation of the chandelier in both its 'ON' (illuminated) and 'OFF' (unilluminated) states.

6. Maintenance

6.1. Cleaning

  • Always turn off power to the fixture before cleaning.
  • Wipe the fixture with a soft, dry cloth.
  • Do not use abrasive cleaners, solvents, or polishes as they may damage the finish.

6.2. Bulb Replacement

  • Ensure the power is off and the bulbs have cooled before attempting to replace them.
  • Unscrew the old E12 bulb and screw in a new E12 bulb.
  • Do not exceed the maximum wattage of 40 watts per bulb.

7. Troubleshooting

ProblemPossible CauseSolution
Fixture does not light
  • Power is off
  • Faulty bulb
  • Incorrect wiring
  • Loose connection
  • Check circuit breaker/fuse.
  • Replace bulb.
  • Verify wiring connections (consult electrician if unsure).
  • Ensure all connections are secure.
Flickering light
  • Loose bulb
  • Loose wiring connection
  • Incompatible dimmer switch (if applicable)
  • Tighten bulb.
  • Check wiring connections.
  • Ensure dimmer switch is compatible with LED bulbs.

8. Warranty & Support

This AMZASA product comes with a 3-year product warranty from the date of purchase.

If you have any questions, require assistance, or encounter issues with your fixture, please contact AMZASA customer service. Our online service is available 24 hours.

For support, please visit the AMZASA Store on Amazon or refer to your purchase documentation for direct contact information.
