Introduction
This manual provides detailed instructions for the safe installation, operation, and maintenance of your Warehouse of Tiffany Quara 26 Inch Modern Glam Crystal Fandelier. Please read all instructions carefully before beginning installation and retain this manual for future reference. This fandelier combines a ceiling fan with a crystal light fixture, designed for indoor use in medium-sized rooms.
Safety Information
WARNING: To reduce the risk of electric shock, fire, or personal injury, always turn off the main power supply at the circuit breaker or fuse box before installation or maintenance.
- All electrical connections must be in accordance with local codes, ordinances, or national electrical codes. If you are unfamiliar with electrical wiring, consult a qualified electrician.
- Ensure the installation site can support the weight of the fandelier.
- Do not operate the fan with damaged blades. Replace any damaged blades immediately.
- Keep hands, clothing, and other objects clear of the fan blades when the fan is in operation.
- This product is for indoor use only and is not water resistant.
Package Contents
Carefully unpack all components and ensure all items are present before discarding packaging materials. If any parts are missing or damaged, contact customer support.
- Fandelier Unit (Motor housing, downrod, canopy)
- Three (3) PC Blades
- Crystal Embellishments
- Light Kit (with 6 E27 bulb bases)
- Remote Control
- Mounting Hardware
Setup and Installation
Professional installation is recommended for electrical components. Ensure power is OFF at the circuit breaker before proceeding.
1. Mounting the Fandelier
This fandelier supports both flush mount and downrod mount installations. Select the appropriate method for your ceiling height and preference. Ensure the junction box is securely fastened to the building structure and can support the fandelier's weight.
Image: Close-up view of the fandelier's polished chrome canopy and downrod, showing the connection point to the ceiling. This component houses the wiring and supports the main unit.
2. Electrical Wiring
Connect the fandelier's electrical wires to your household wiring according to the provided wiring diagram (not included in this document, refer to product packaging for specific diagrams). Ensure all connections are secure and insulated with wire connectors. The fandelier requires a corded electric power source.
3. Attaching Blades and Light Kit
Securely attach the three (3) PC blades to the motor housing. Install six (6) E27 base bulbs (not included) into the light kit sockets. The maximum wattage per bulb is 25 watts.
Image: Detailed view of the fandelier's internal structure, highlighting the six E27 bulb sockets and the metal framework that supports the crystal elements.
4. Installing Crystal Embellishments
Carefully attach the crystal embellishments to the fandelier frame. Refer to the product diagram for the correct placement and orientation of each crystal piece.
Image: Close-up shot showcasing the intricate arrangement and reflective quality of the crystal embellishments on the fandelier's outer drum. Each crystal piece is precisely cut to refract light.
Once all components are installed, restore power at the circuit breaker.
Operating Instructions
Your fandelier is controlled by a remote control. Ensure the remote has working batteries installed.
Remote Control Functions:
- Power Button: Turns the fandelier (fan and lights) on or off.
- Fan Speed Buttons: Adjusts the fan speed (typically low, medium, high).
- Light On/Off Button: Controls the light fixture independently of the fan.
Point the remote control directly at the fandelier for optimal response. The fan features three (3) PC blades for efficient airflow.
Image: The Warehouse of Tiffany Quara 26 Inch Modern Glam Crystal Fandelier, showcasing its polished chrome finish, crystal drum, and integrated fan blades. This image provides an overall view of the product.
Maintenance
Regular maintenance ensures optimal performance and longevity of your fandelier.
Cleaning:
- Metal Finish: Wipe with a soft, dry cloth. Do not use abrasive cleaners or polishes, as they may damage the polished chrome finish.
- Crystal Embellishments: Gently dust with a soft cloth or use a mild glass cleaner on a cloth, then wipe dry. Avoid spraying cleaner directly onto the crystals or electrical components.
- Fan Blades: Wipe the PC blades with a soft, damp cloth to remove dust.
Bulb Replacement:
Ensure power is OFF at the circuit breaker before replacing bulbs. Allow bulbs to cool completely before handling. Replace with E27 base bulbs, not exceeding 25 watts per bulb.
Troubleshooting
If you encounter issues with your fandelier, refer to the following common problems and solutions:
| Problem | Possible Cause | Solution |
|---|---|---|
| Fandelier does not turn on. | No power supply; loose wiring; remote control battery dead. | Check circuit breaker. Ensure all wiring connections are secure. Replace remote control batteries. |
| Fan operates, but lights do not. | Bulbs are loose or burnt out; light kit wiring issue. | Tighten or replace bulbs. Check light kit wiring connections. |
| Fan makes excessive noise. | Loose mounting screws; unbalanced blades. | Ensure all mounting screws are tight. Check for any obstructions. Balance blades if necessary (balancing kit not included). |
| Remote control not responding. | Dead batteries; remote out of range; interference. | Replace remote batteries. Ensure you are within range and pointing at the fandelier. Remove any potential sources of interference. |
Specifications
Refer to the following table for detailed product specifications:
| Feature | Specification |
|---|---|
| Brand | Warehouse of Tiffany |
| Model Number | DW01W54CR |
| Color | Chrome Polish |
| Material | Metal, Crystal, Polycarbonate (Blades) |
| Style | Glam |
| Power Source | Corded Electric |
| Installation Type | Flush Mount, Downrod Mount |
| Special Feature | Remote Control |
| Control Method | Remote |
| Finish Type | Polished |
| Number of Light Sources | 6 |
| Wattage (Lights) | 25 watts (per bulb, E27 base) |
| Electricity Use (Fan) | 28 Watts (excludes lights) |
| Airflow | 2,626 Cubic Feet Per Minute |
| Airflow Efficiency | 48 Cubic Feet Per Minute Per Watt |
| Assembly Required | Yes |
| Certification | ETL |
Dimensions:
Image: Technical drawing illustrating the key dimensions of the fandelier, including overall height (22.4 inches), body height (10.7 inches), width (26 inches), downrod length (9.8 inches), and canopy dimensions (5.9 x 2.4 inches).
Energy Information:
Image: Energy Information label detailing the fandelier's performance at high speed, including airflow (2,626 Cubic Feet Per Minute), electricity use (28 Watts, excluding lights), and airflow efficiency (48 Cubic Feet Per Minute Per Watt).
Image: Energy Guide label providing an estimated yearly energy cost of $14, based on 28 watts of energy use. It also shows the airflow of 2626 CFM and airflow efficiency of 48 CFM/Watt.
Warranty and Support
This product is sold without a manufacturer's warranty. For any questions regarding installation, operation, or troubleshooting that are not covered in this manual, please contact the retailer or manufacturer directly for assistance.
