Introduction
This manual provides essential instructions for the safe and effective operation, assembly, and maintenance of your CRAFTSMAN 113.198210 Electronic Radial Arm Saw. Please read all instructions carefully before operating the saw.
Figure 1: Manual Cover - CRAFTSMAN 10-inch Electronic Radial Saw
Safety Instructions
CAUTION: READ ALL INSTRUCTIONS CAREFULLY.
WARNING: TO AVOID INJURY FROM UNEXPECTED STARTING OR ELECTRICAL SHOCK, DO NOT PLUG THE POWER CORD INTO A SOURCE OF POWER. THIS CORD MUST REMAIN UNPLUGGED WHENEVER YOU ARE WORKING ON THE SAW.
Always ensure the saw is unplugged before performing any assembly, maintenance, or adjustments. Wear appropriate safety gear, including eye protection, hearing protection, and gloves, when operating or working on the saw.
Unpacking and Preassembly
The CRAFTSMAN 113.198210 Radial Saw is shipped complete in one box. Carefully unpack all components and verify against the parts list below. Ensure all packing materials are removed before proceeding with assembly.
Figure 2: Unpacking and Preassembly Diagram
Preassembly Parts List
| Item No. | Description | Qty. |
|---|---|---|
| A | Basic Saw Assembly | 1 |
| B | Rear Table | 1 |
| C | Cable Spacer | 1 |
| D | Rip Fence | 1 |
| E | Front Table | 1 |
| F | Owners Manual | 1 |
| G | Loose Parts Bag | 1 |
| H | Channel, Table Mounting | 2 |
| I | Handwheel Assembly | 1 |
| J | Trim Cap, R.H. | 1 |
| K | Trim Ledge | 1 |
| L | Trim Cap, L.H. | 1 |
| M | 23" Cabinet with 1 Door | 1 |
| N | Arbor Wrench | 1 |
| P | Shaft Wrench | 1 |
| Q | Caster | 2 |
Setup and Assembly
Detailed instructions for the complete setup and assembly of the CRAFTSMAN 113.198210 Electronic Radial Arm Saw are provided in the full manual. This includes mounting the saw to its cabinet, attaching tables, and securing all components. Proper assembly is crucial for safe and accurate operation.
Operating Instructions
The CRAFTSMAN 113.198210 Electronic Radial Arm Saw is designed for various cutting operations. The complete manual details how to set up the saw for different tasks, including:
- Basic crosscutting and ripping
- Beveling operations
- Molding operations
- Making precise adjustments for cut depth, angle, and length
Always ensure the workpiece is securely clamped and the blade guard is in place before starting any cutting operation.
Maintenance
Regular maintenance is essential to ensure the longevity and safe operation of your radial arm saw. The full manual provides detailed information on:
- Lubrication schedules and points
- Cleaning procedures for the saw and its components
- Inspection of electrical cords, blades, and moving parts
- Adjustments to maintain accuracy and performance
Always disconnect power before performing any maintenance or cleaning.
Parts List for Guard Assembly
This section provides a detailed parts list for the guard assembly of the CRAFTSMAN 10-inch Electronic Radial Saw, Model No. 113.198210. Refer to the diagram and table below for identification and ordering of replacement parts.
Figure 3: Guard Assembly Exploded View
Figure 6 - Guard Assembly Parts List
| Key No. | Part No. | Description | Key No. | Part No. | Description |
|---|---|---|---|---|---|
| 1 | 816264 | Guard | 10 | STD581050 | *Ring, Retaining |
| 2 | 120399 | *Nut, Square 5/16-18 | 11 | 63270 | Spreader |
| 3 | 63258 | Elbow, Dust | 12 | 816341 | Bearing (Includes Key #10) |
| 4 | 63241 | Bar, Anti-Kickback | 13 | 60035 | Grip |
| 5 | 815816 | Guide, Anti-Kickback | 14 | 816070 | Screw, Guard Clamp |
| 6 | STD551010 | Washer, 13/64 x 5/8 x 1/32 | 15 | 166785-3 | Screw, Wing 5/16-18 x 2-3/4 |
| 7 | STD601103 | *Screw, Pan Hd. | 16 | 63538 | Clamp, Guard |
| 8 | STD541231 | Type "1" 10-32 x 3/8 | 17 | STD510009 | *Screw, Pan Hd. 8-32 x 1/2 |
| 9 | 815815 | *Nut, Hex Jam 5/16-18 | 18 | STD551208 | *Lockwasher, External No. 8 |
| Pawl | 19 | STD541008 | *Nut, Hex 8-32 |
*Standard Hardware Item may be Purchased Locally.
Always order by Part Number - Not by Key Number.
Specifications
Detailed technical specifications for the CRAFTSMAN 113.198210 Electronic Radial Arm Saw, such as motor horsepower, blade diameter, and cutting capacities, are not available in this excerpt. Please refer to the complete manual for comprehensive product specifications.
Troubleshooting
Troubleshooting guides and common issue resolutions for the CRAFTSMAN 113.198210 Electronic Radial Arm Saw are not included in this manual excerpt. For assistance with operational problems or malfunctions, consult the complete operator's manual or contact CRAFTSMAN customer support.
Warranty and Support
Information regarding the product warranty and customer support contacts for the CRAFTSMAN 113.198210 Electronic Radial Arm Saw is not provided in this manual excerpt. Please refer to the original product documentation or the CRAFTSMAN official website for warranty details and support options.
