Ledvion Universal LED Dimmer (Model LV10010) Instruction Manual

1. Introduction

1.1 Product Overview

The Ledvion Universal LED Dimmer (Model LV10010) is designed for seamless dimming of various LED and halogen lamps. This integrated, phase-switched (trailing edge) dimmer operates within a 220-240V range and supports LED loads from 3W to 250W and halogen loads from 3W to 300W. Its universal design ensures compatibility with a wide range of standard cover frames.

Image 1: Ledvion Universal LED Dimmer module with included cover plate.

1.2 Key Features

• Universal Compatibility: Dims LED lamps from 3W to 250W and halogen lamps from 3W to 300W.
• Trailing Edge Technology: Features built-in electronics to prevent buzzing noise and flickering, ensuring quiet operation.
• Wide Frame Compatibility: Designed to fit almost all standard cover frames from brands such as GIRA, Berker, Peha, Jung, and Busch Jager. Includes an adapter for specific Busch Jaeger models requiring a 4mm to 6mm rotary shaft expansion.
• High Quality & Certified: Complies with various quality standards, including Intertek, CE, RoHS, and REACH.
• 2-Year Warranty: Backed by a 2-year manufacturer's warranty.

Image 2: The dimmer supports a wide range of LED and Halogen lamp wattages.

Image 3: The dimmer's trailing edge technology ensures silent and flicker-free performance.

2. Safety Information

WARNING: Risk of electric shock. Installation should only be performed by a qualified electrician or in accordance with local electrical codes. Always disconnect power at the circuit breaker before installation, maintenance, or troubleshooting.

• Do not exceed the specified maximum load (250W for LED, 300W for Halogen).
• Ensure the operating voltage (220-240V) matches your electrical system.
• Do not use with non-dimmable lamps.
• Keep out of reach of children.

3. Package Contents

Verify that all items are present in your package:

• 1x Ledvion Universal LED Dimmer Module (LV10010)
• 1x Cover Plate (white, classic look)
• 1x Rotary Knob
• 1x Adapter (for 4mm to 6mm shaft expansion)

4. Specifications

Image 4: Physical dimensions of the dimmer module.

5. Installation

5.1 Preparation

1. Disconnect Power: Before starting any electrical work, turn off the main power supply to the circuit at your fuse box or circuit breaker. Verify that the power is off using a voltage tester.
2. Remove Existing Switch: Carefully remove the existing light switch from the wall box. Disconnect the wires, noting their connections.
3. Check Wall Box: Ensure your flush-mounted wall box has two retaining screws for secure mounting, as this dimmer does not use a clamping mechanism. A deeper wall box is advantageous but not strictly necessary.

5.2 Wiring Connection

The Ledvion dimmer supports both one-way and two-way switching configurations. Connect the wires to the screw terminals as shown in the diagrams below. Ensure all connections are tight and secure.

Image 5: Wiring diagrams for one-way and two-way connections.

• L: Live wire (Input)
• L1: Switched Live wire (Output to lamp)
• L2: For two-way switching (connect to the other switch's L2 terminal)
• N: Neutral wire (Required for two-way switching, if applicable)

5.3 Mounting the Dimmer

1. Carefully place the wired dimmer module into the wall box. Ensure wires are not pinched.
2. Secure the dimmer module to the wall box using the provided screws.
3. If necessary, attach the 4mm to 6mm adapter to the dimmer shaft before placing the rotary knob.
4. Attach the cover plate and then the rotary knob.

Image 6: Installation of the dimmer module into a wall box.

6. Setup and Configuration

6.1 Adjusting Minimum Dimming Level

After installation, it is recommended to set the minimum dimming level to prevent flickering or premature lamp failure at very low light settings. This is done via a small adjustment screw labeled 'MIN' on the dimmer module.

1. Restore power to the circuit.
2. Turn on the light and dim it to its lowest setting.
3. Using a small screwdriver, carefully turn the 'MIN' adjustment screw (usually located near the terminals) until the lamp dims smoothly without flickering and remains stable at its lowest desired light output.
4. Test the full dimming range to ensure satisfactory operation.

7. Operation

7.1 Power On/Off

Press the rotary knob to turn the connected lights on or off.

7.2 Dimming Function

Rotate the knob clockwise to increase the light intensity and counter-clockwise to decrease it.

8. Compatibility

8.1 Compatible Cover Frames

The universal design of the Ledvion dimmer makes it compatible with most standard cover frames from leading brands, including:

• GIRA
• Berker
• Peha
• Jung
• Busch Jager
• Kopp
• Merten by Schneider

Image 7: Examples of suitable dimmer covers from various brands.

8.2 Incompatible Lamps

NOTE: This dimmer is not compatible with the following lamp types or systems:

• Philips Hue
• WarmGlow
• DimTone

9. Maintenance

The Ledvion Universal LED Dimmer requires minimal maintenance.

• Ensure power is off before cleaning.
• Wipe the surface of the dimmer and cover plate with a soft, dry cloth.
• Do not use abrasive cleaners, solvents, or harsh chemicals, as these may damage the finish.

10. Troubleshooting

If you encounter issues with your Ledvion dimmer, refer to the following common problems and solutions:

11. Warranty and Support

11.1 Warranty Information

The Ledvion Universal LED Dimmer (Model LV10010) comes with a 2-year warranty from the date of purchase, covering defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims.

Image 8: The Ledvion dimmer includes a 2-year warranty.

11.2 Further Support

For additional information, detailed documentation, or to contact customer support, please scan the QR code below or visit the Ledvion website.

Image 9: Scan this QR code for access to additional documentation and support.
