Introduction
This instruction manual provides detailed guidance for assembling the Revell 85-4499 Fast & Furious Brian's Ford SVT Lightning Model Car Kit. This 1:25 scale plastic model kit allows enthusiasts to recreate Brian O'Conner's iconic Ford F-150 SVT Lightning from "The Fast and the Furious" movie. The kit is designed for individuals aged 12 and up, offering a rewarding building experience.
The Ford F-150 SVT Lightning is known for its special handling suspension and high-performance 4.6 V-8 engine. This model kit captures these details, featuring a custom body "aero" package, a supercharged V-8 engine, and a detailed chassis.
Safety Information
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm (Proposition 65 Warning). This product is for external use only. Keep out of reach of small children. Adult supervision is recommended during assembly due to small parts and the use of sharp tools and adhesives.
Kit Contents and Required Tools
The Revell 85-4499 kit contains 118 plastic parts molded in white, transparent red, and clear, along with soft black tires.
Note: Paint and glue are not included in this kit and must be purchased separately.
Recommended Tools (Not Included):
- Hobby knife or sprue cutters for removing parts from sprues.
- Plastic model cement or glue.
- Various paint colors (refer to packaging for recommended colors).
- Small paint brushes.
- Tweezers for handling small parts.
- Sandpaper or sanding sticks for smoothing edges.
Assembly Instructions
Follow these steps carefully for successful assembly. Refer to the included diagram sheets for part identification and placement.
Step 1: Preparation
- Carefully unpack all parts and compare them against the parts list in the kit to ensure all components are present and undamaged.
- Familiarize yourself with the instruction diagrams before beginning assembly.
- Prepare your workspace: ensure it is clean, well-lit, and well-ventilated.
Step 2: Chassis and Engine Assembly
- Begin by assembling the detailed chassis components.
- Construct the supercharged V-8 engine according to the diagrams. Pay attention to small details and ensure proper alignment.
- Attach the engine assembly to the chassis.
Step 3: Interior Assembly
- Assemble the interior components, such as the dashboard, seats, and steering wheel.
- Paint interior parts before assembly if desired, allowing adequate drying time.
- Secure the completed interior into the chassis.
Step 4: Body and Exterior Details
- Assemble the main body sections, ensuring a flush fit.
- Attach exterior details such as mirrors, bumpers, and the custom "aero" package components.
- Apply paint to the body and exterior parts as per your preference, allowing sufficient drying time between coats.
Step 5: Wheels and Final Assembly
- Mount the soft black tires onto the wheel rims.
- Attach the wheel assemblies to the chassis.
- Carefully join the completed body to the chassis assembly.
- Apply any decals provided in the kit, following the decal placement guide.
This image displays the packaging for the Revell 85-4499 model kit, featuring the Brian's Ford SVT Lightning.
Display and Care
Displaying Your Model:
Once assembled, your Revell Brian's Ford SVT Lightning model is ready for display. Choose a stable, flat surface away from direct sunlight, extreme temperatures, and high humidity to preserve the model's finish and structural integrity.
Cleaning and Maintenance:
- To clean the model, gently dust it with a soft, dry brush or a microfiber cloth.
- Avoid using harsh chemicals, abrasive cleaners, or excessive moisture, as these can damage the paint and plastic.
- Handle the model by its base or main body to prevent damage to delicate parts.
Troubleshooting Common Assembly Issues
- Parts Not Fitting: Ensure you are using the correct parts as indicated in the diagrams. Sometimes, a small amount of sanding or trimming with a hobby knife may be required for a perfect fit. Do not force parts together.
- Glue Issues: Use plastic model cement sparingly. Too much glue can melt the plastic or leave unsightly marks. Allow sufficient drying time for each glued section before proceeding. If parts detach, reapply a small amount of glue and hold firmly until set.
- Paint Application: For best results, apply paint in thin, even coats. Allow each coat to dry completely before applying the next. If paint appears uneven or clumpy, it may be too thick or applied in humid conditions.
- Decal Application: Ensure the surface is clean and smooth before applying decals. Use water to slide decals into position and a soft cloth or cotton swab to gently press out air bubbles and excess water.
Specifications
- Model Name: Fast & Furious Brian's Ford SVT Lightning Model Car Kit
- Model Number: 85-4499
- Brand: Revell
- Scale: 1:25
- Skill Level: 4 (Recommended for experienced modelers)
- Number of Pieces: 118
- Assembled Dimensions: Approximately 8.75" (L) x 3.625" (W) x 2.6875" (H)
- Material: Plastic (Molded in white, transparent red, and clear)
- Tires: Soft black
- Engine: Supercharged V-8
- Age Recommendation: 12 years and up
- UPC: 031445044991
Warranty and Support
Warranty Information:
This product is sold without a manufacturer's warranty. Please inspect all parts upon receipt. If you encounter any issues with missing or defective parts, please contact the retailer where the kit was purchased.
Customer Support:
For general inquiries or additional information regarding Revell products, please visit the official Revell website or contact their customer service department.
