Famidoc Upper Arm Blood Pressure Monitor FDBP-A4 User Manual

Introduction

This manual provides instructions for the proper use and maintenance of your Famidoc Upper Arm Blood Pressure Monitor, Model FDBP-A4. Please read this manual thoroughly before use to ensure accurate readings and safe operation. This device is designed for home use to measure systolic and diastolic blood pressure and pulse rate.

Important Safety Information

• Consult your physician before using this device for any medical condition.
• This device is not intended to be a substitute for professional medical advice, diagnosis, or treatment.
• Do not use this device on infants, children, or individuals who cannot express consent.
• Avoid using the monitor in a moving vehicle or on an airplane.
• Do not use the device in conjunction with high-frequency surgical equipment.
• Keep the device out of reach of children and pets.
• Statements regarding dietary supplements have not been evaluated by the FDA and are not intended to diagnose, treat, cure, or prevent any disease or health condition.

Product Overview

The Famidoc Upper Arm Blood Pressure Monitor (Model FDBP-A4) is an automatic digital device designed for convenient and accurate blood pressure measurement. It features a large LED display, two-user mode with 120 memory sets, irregular heartbeat detection, and silent inflation/deflation technology.

Image: Contents of the Famidoc Blood Pressure Monitor package, including the main unit, cuff, and user manual.

Setup

1. Install Batteries

Open the battery compartment cover located on the back of the main unit. Insert four AAA batteries, ensuring correct polarity (+/-). Close the battery cover securely. The device can also be powered via a 5V/1A USB cable (not included).

Image: The back of the monitor with the battery compartment open, showing four AAA batteries. The image also indicates a USB power option.

2. Set Date and Time

Press the SET button to enter the date setting mode. Use the MEM button to adjust the month, then press SET to confirm. Repeat this process for the day and year. Follow a similar procedure to set the time (hour and minute).

3. Choose Measurement Unit

After setting the time, the device will enter the unit selection mode (kPa/mmHg). Press the MEM button to switch between kPa and mmHg. Press SET to confirm your selection.

4. Select User Mode

Long press the START/STOP button for 3 seconds until the user symbol (man or woman) flashes. Then press the SET button to switch between User 1 and User 2. This allows two individuals to store their readings separately.

Operating Instructions

1. Proper Cuff Placement

Ensure you are seated comfortably with your arm resting on a flat surface. Wrap the cuff around your left upper arm, approximately 2-3 cm above the elbow. The air tube should run down the center of your arm. Ensure the cuff is snug but not too tight; you should be able to fit two fingers between the cuff and your arm. Keep your palm facing upwards.

Image: Visual guide for correct cuff placement on the upper arm, indicating the 2-3 cm distance from the elbow and the position of the air tube.

2. Taking a Measurement

Once the cuff is correctly placed, press the START/STOP button. The cuff will automatically inflate and then slowly deflate. Remain still and silent during the measurement. The systolic pressure, diastolic pressure, and pulse rate will be displayed on the screen once the measurement is complete.

Image: The large LED display of the monitor showing blood pressure readings (SYS, DIA) and pulse.

3. Interpreting Results

The monitor features a color-coded indicator on the left side of the display to help interpret your blood pressure readings according to WHO guidelines:

• Green: Optimal/Normal Blood Pressure
• Yellow: High Normal Value / Mild Hypertension
• Red: Moderate / Severe Hypertension

An irregular heartbeat indicator (IHB) will also appear if an irregular heartbeat is detected during measurement. Consult your doctor if you frequently receive high readings or IHB alerts.

Image: The monitor's display showing the color-coded blood pressure classification on the left side.

4. Memory Function

The device stores up to 120 readings for each of the two users. To view past readings, press the MEM button. Each press will cycle through the stored measurements, displaying the most recent first.

Maintenance

• Clean the monitor and cuff with a soft, dry cloth. Do not use abrasive cleaners or immerse the device in water.
• Store the device in a cool, dry place, away from direct sunlight and extreme temperatures.
• Remove batteries if the device will not be used for an extended period.
• Do not attempt to disassemble or repair the device yourself. Contact customer support for assistance.

Troubleshooting

Specifications

• Model Name: Upper Arm Blood Pressure Monitor
• Item Model Number: FDBP-A4
• Measurement Method: Oscillometric method
• Measurement Range: Pressure: 0-299 mmHg, Pulse: 40-199 beats/min
• Accuracy: Pressure: ±3 mmHg, Pulse: ±5% of reading
• Cuff Size: 8.7-16.5 inches (22-42 cm)
• Power Source: 4x AAA batteries (included) or DC 5V/1A USB (adapter not included)
• Display Type: Digital LED
• Memory: 2 users, 120 sets of memory per user
• Operating Conditions: 5°C-40°C, 15%-90% RH (non-condensing)
• Storage Conditions: -20°C-55°C, 15%-90% RH (non-condensing)
• Manufacturer: FAMIDOC TECHNOLOGY CO., LTD.

Warranty and Support

For warranty information or technical support, please contact Famidoc customer service. Refer to the contact details provided in the product packaging or visit the official Famidoc website. Keep your purchase receipt as proof of purchase.
