FERCAISH 855AP-1A-C 24V PCB Relay User Manual

1. Product Overview

The FERCAISH 855AP-1A-C 24VDC is a fully-sealed PCB relay designed for various electronic applications, including the resolution of the F01 error code commonly found in certain dryer models. This relay serves as a direct replacement for the 855AP-1A-C and can also substitute for G8P-1A4P-ACD relays on PC boards and circuit boards.

Figure 1: Two views of the FERCAISH 855AP-1A-C 24V PCB Relay. The relay is black, rectangular, with four metal pins extending from one side for PCB mounting. Markings on the relay include "855AP-1A-C", "30A 240VAC", and "24V=DC".

2. Key Features

• Direct Replacement: Specifically designed to replace the 855AP-1A-C 24VDC relay and can serve as a substitute for G8P-1A4P-ACD.
• F01 Error Solution: Effective in resolving the F01 error code in compatible dryer outlets.
• Fully Sealed Design: Ensures durability and protection for the internal components.
• High Quality Construction: Features a stable and durable design with a high-quality coil and shell.
• Versatile Application: Suitable for use in various electronic equipment, communication systems, and industrial control.
• Easy Integration: Designed for straightforward installation and replacement on printed circuit boards.

Figure 2: Quality Assurance details of the relay, illustrating its robust construction with a focus on stability, durability, and the quality of its internal coil and external shell.

3. Product Specifications

Figure 3: Detailed dimensions of the 855AP-1A-C relay, including length, width, height, and pin spacing, provided in both millimeters and inches.

Figure 4: Close-up view of the PCB relay, clearly displaying its model number (855AP-1A-C), coil voltage (DC 24V), and contact capacity (30A 240VAC).

4. Installation Guide

Replacing a PCB relay requires basic soldering skills. If you are new to soldering, it is highly recommended to practice on a non-essential or damaged circuit board before attempting to replace the relay on your primary device's controller board.

Installation Steps:

1. Preparation: Ensure the device is powered off and disconnected from any power source. Identify the old relay on the circuit board that needs replacement.
2. Desoldering: Carefully use a soldering iron and desoldering wick or pump to remove the old relay from the circuit board. Ensure all solder points are clean.
3. New Relay Placement: Position the new FERCAISH 855AP-1A-C relay onto the circuit board, aligning its pins with the corresponding holes.
4. Soldering: Solder the pins of the new relay securely to the circuit board. Ensure strong, clean solder joints.
5. Insulation and Placement: After soldering, ensure the bottom of the circuit board is electrically insulated. Place the board in a stable position within the dryer or device. For dryer applications, ensure the board is not positioned where it could be dislodged or interfere with moving parts like the drum.
6. Testing: Once installed, carefully reassemble the device and perform necessary tests to confirm the relay is functioning correctly.

Figure 5: The 855AP-1A-C relay shown mounted on a green circuit board, demonstrating its integration into an electronic system. Various views of the relay itself are also presented.

5. Operating Principle

The FERCAISH 855AP-1A-C is a general power relay that operates by using an electromagnetic coil to open or close electrical contacts. When the specified DC 24V coil voltage is applied, an electromagnetic field is generated, which actuates the internal mechanism to switch the 30A 250VAC contacts. This allows the relay to automatically adjust, protect, and change circuits, thereby safeguarding connected electrical equipment from overcurrents or other electrical anomalies.

Its primary function is to act as an electrical switch that can be controlled by a separate low-power signal (the coil voltage) to switch a high-power circuit (the contact capacity), providing isolation and control within electronic systems.

6. Maintenance

The FERCAISH 855AP-1A-C PCB relay is a fully-sealed component designed for long-term reliability and requires no routine maintenance. Its sealed construction protects internal components from dust, moisture, and other environmental factors. In the event of a malfunction, the relay is designed for replacement rather than repair.

7. Troubleshooting: F01 Error Code

The FERCAISH 855AP-1A-C relay is frequently used to address the F01 error code in certain dryer models. This error typically indicates an issue with the dryer's control board, often related to a faulty relay responsible for power management or heating element control.

Troubleshooting Steps for F01 Error:

1. Identify the Faulty Relay: On the dryer's control board, locate the relay that corresponds to the F01 error. This is often the power relay or a relay controlling the heating circuit.
2. Verify Compatibility: Ensure the replacement relay (FERCAISH 855AP-1A-C) matches the specifications of the original faulty relay, particularly coil voltage (DC 24V) and contact capacity (30A 250VAC).
3. Replacement Procedure: Follow the detailed "Installation Guide" in Section 4 to carefully desolder the old relay and solder the new FERCAISH 855AP-1A-C relay onto the circuit board.
4. Test Functionality: After replacement, reassemble the dryer and test its operation. If the F01 error persists, further diagnosis of the control board or other dryer components may be necessary.

Note: Always ensure the dryer is unplugged and de-energized before attempting any repairs. If you are unsure about performing this repair, consult a qualified technician.

8. Applications

The FERCAISH 855AP-1A-C PCB relay is a versatile component suitable for a wide range of applications due to its robust design and electrical specifications. Common applications include:

• Household Appliances: Such as dryers (for F01 error resolution), washing machines, and other home electronics requiring power switching.
• Industrial Control Systems: Used in automation, machinery, and process control for switching high-power loads.
• Electronic Equipment: General purpose use in various electronic circuits for signal isolation and power control.
• Communication Systems: Integration into telecommunication devices and network equipment.
• Automotive Field: Applicable in certain automotive electrical systems where a 24VDC coil and 30A switching capacity are required.
• Security Systems: Can be found in electronic security doors and access control systems.

Figure 6: Examples of the diverse applications where the FERCAISH 855AP-1A-C relay can be utilized, ranging from household appliances to industrial and automotive sectors.

9. Warranty and Support

Specific warranty information for the FERCAISH 855AP-1A-C PCB Relay is not provided in this manual. For details regarding product warranty or technical support, please refer to the product packaging or contact the manufacturer, FERCAISH, directly through their official channels.
