GESIPOR Bathroom LED Mirror

Introduction

Thank you for choosing the GESIPOR Bathroom LED Mirror. This smart mirror is designed to enhance your bathroom experience with its advanced features, including adjustable lighting, anti-fog capabilities, integrated wireless speaker, and convenient time and temperature display. This manual provides essential information for the proper setup, operation, and maintenance of your new mirror.

Figure 1: GESIPOR Bathroom LED Mirror with Wireless Speaker and Wall Switch.

Safety Information

Please read all safety instructions carefully before installation and use. Keep this manual for future reference.

• Ensure the power supply is disconnected before any installation or maintenance.
• Installation should be performed by a qualified electrician in accordance with local electrical codes.
• The mirror is made of tempered glass for safety. While durable, avoid strong impacts.
• Do not attempt to disassemble or modify the mirror.
• Keep the mirror away from excessive moisture or direct water spray, except for the intended anti-fog function.

Figure 2: The mirror features an explosion-proof tempered glass design for enhanced safety, minimizing risk of injury if broken.

Setup and Installation

For detailed installation instructions, please refer to the dedicated Installation Manual (PDF) provided with your product or available online. Professional installation is recommended.

Key Components:

• 5MM PVC Panel: Provides a sturdy backing for the mirror.
• Aluminum Alloy Frame: Ensures structural integrity and durability.
• 1.2M Cable & US Plug: For power connection. The mirror can be hardwired or plugged in.
• UL Certified Components: Includes 48-inch (1.2m) length power cord, 110V IP67 waterproof defogger, and 110V-270V LED power driver.

Figure 3: Rear view of the mirror highlighting the 5mm PVC panel, aluminum alloy frame, and power connection details.

Operating Instructions

1. Power and Lighting Control

The mirror features touch-sensitive controls integrated into the mirror surface. A short press on the light icon will turn the LED lights on or off. Long press to adjust brightness.

• Dimmable Lighting: Long press the touch sensor to seamlessly adjust the brightness from 5% to 100%.
• Color Temperature Adjustment: Short press the light icon to cycle through three color temperatures:
  • White Light (6000K)
  • Natural Light (4000K)
  • Warm Light (3000K)
• Memory Function: The mirror remembers your last brightness and color temperature settings when turned off and restores them upon reactivation.

Figure 4: Integrated touch controls for light, anti-fog, Bluetooth, and time/date settings.

Figure 5: Adjusting between white (6000K) and warm (3000K) light settings.

2. Anti-Fog Function

Activate the anti-fog function with a single press of the defog button on the mirror's touch panel. This feature clears condensation, ensuring a clear reflection even in steamy environments.

Figure 6: The anti-fog function ensures a clear mirror surface in humid conditions.

3. Wireless Speaker (Bluetooth)

Enjoy music or take calls directly through your mirror's integrated wireless speaker.

• Pairing: Activate Bluetooth on your phone/device and search for "XN19". Select to connect.
• Music Playback: Once connected, audio from your device will play through the mirror's speakers.
• Call Answering: Touch the phone icon on the mirror to answer incoming calls.

Figure 7: The mirror's wireless speaker allows for audio streaming and call handling.

4. Time and Temperature Display

The mirror displays the current time and temperature, eliminating the need for additional devices in your bathroom. Use the '+' and '-' buttons to adjust the time and date, then press 'set' to confirm changes.

Figure 8: Digital display for time, date, and temperature, with adjustment controls.

Maintenance

To ensure the longevity and optimal performance of your GESIPOR LED Mirror, follow these maintenance guidelines:

• Cleaning: Use a soft, damp cloth and a mild glass cleaner to wipe the mirror surface. Avoid abrasive cleaners or harsh chemicals that could damage the mirror or its components.
• Frame Care: Wipe the aluminum alloy frame with a soft, dry cloth.
• Electrical Components: Ensure the mirror is unplugged or power is off before cleaning any electrical parts. Do not spray water directly onto the electrical components.

Troubleshooting

If you encounter any issues with your mirror, please refer to the following common troubleshooting tips:

If the problem persists, please contact GESIPOR customer support for assistance.

Specifications

Warranty and Support

GESIPOR is committed to providing high-quality products and satisfactory after-sales service. For any warranty claims, technical support, or inquiries, please contact GESIPOR customer service through the retailer where you purchased the product or visit the official GESIPOR brand store online.

Your feedback is valuable and helps us continuously improve our products and services.
