SHINE WELL Leg Compression Massager with Heat (Model RM) - Instruction Manual

Introduction

The SHINE WELL Leg Compression Massager with Heat (Model RM) is designed to provide targeted compression and heat therapy to your legs and feet. This device features multiple massage modes and intensity levels to help alleviate muscle soreness, reduce swelling, and promote circulation. Please read this manual thoroughly before initial use to ensure safe and effective operation.

Safety Information

• Do not use this device on injured or inflamed skin.
• Avoid use during pregnancy. Consult a physician before use if you have any medical conditions.
• Keep the device away from water and do not use it in humid environments.
• Always follow the instructions provided in this manual.
• Unplug the power adapter from the socket before cleaning or maintenance.
• Do not walk around while using the massager to prevent falls.

Package Contents

Verify that all items are present in the package:

• 2 x Leg Compression Wraps (Left and Right)
• 1 x Handheld Controller
• 1 x Power Adapter
• 2 x Extension Pieces
• 1 x Storage Bag
• 1 x User Manual

Product Overview

The SHINE WELL Leg Compression Massager consists of two leg wraps, a handheld controller, and a power adapter. The leg wraps are designed to cover the foot and calf areas, providing comprehensive massage. The controller allows for easy selection of massage modes, intensity levels, and heat settings.

Image: SHINE WELL Leg Compression Massager with Heat, displaying the leg wraps and handheld controller.

Image: Close-up of the handheld controller, detailing buttons for Mode, Intensity, Heat, and Power.

Setup

1. Prepare the Leg Wraps: Unfold the leg wraps. Each wrap is labeled 'L' for left and 'R' for right. Ensure the air tubes are not tangled.
2. Adjust Size (if needed): If the leg wraps are too tight, attach the provided extension pieces using the Velcro fasteners. The maximum calf size with extensions can reach 28.5 inches.
3. Wear the Wraps: Sit comfortably. Place your feet into the foot sections of the wraps. Secure the wraps around your calves and feet using the Velcro fasteners. Ensure they are snug but not overly tight, allowing for air inflation.
4. Connect the Controller: Connect the air tubes from both leg wraps to the corresponding ports on the handheld controller. Ensure the 'UP' indicator on the connector aligns with the controller's port.
5. Connect Power: Plug the power adapter into a wall outlet and then into the designated port on the handheld controller.

Image: Leg wraps with extension pieces, illustrating how to adjust for larger calf sizes.

Operating Instructions

1. Power On: Press the Power button on the handheld controller to turn on the device. The indicator lights will illuminate.
2. Select Massage Mode: Press the Mode button to cycle through the 3 available massage modes: Sequence, Circulation, and Whole. The corresponding indicator light will show the selected mode.
3. Adjust Intensity: Press the Intensity button to choose from 3 air pressure intensities: Min, Mid, and Max. The indicator light will show the current intensity.
4. Activate Heat Function: Press the Heat button to activate or deactivate the heating function. There are 2 heating levels (Min/Max). The heat can be turned on or off at any time during the massage.
5. Automatic Shut-off: The device is equipped with a 20-minute automatic shut-off function to prevent overuse. It is recommended to use the massager no more than 5 times a day, with each session lasting 20 minutes.

Maintenance

• Cleaning: Unplug the device before cleaning. The inner lining of the leg wraps is removable and can be washed. Wipe the exterior of the wraps and the controller with a soft, damp cloth. Do not use abrasive cleaners or immerse the device in water.
• Storage: Store the massager in a cool, dry place away from direct sunlight. Use the provided storage bag to keep the components organized and protected from dust.

Troubleshooting

Specifications

Warranty and Support

For warranty information or product support, please refer to the contact details provided in your product packaging or visit the official SHINE WELL website. Keep your purchase receipt for warranty claims.
