1. Introduction to IPL Technology
The DEESS GP586 IPL (Intense Pulsed Light) Hair Removal Device is designed for long-term hair reduction. IPL technology works by emitting broad-spectrum light that targets the melanin in hair follicles. This light energy is converted into heat, which damages the hair follicle and inhibits future hair growth. Regular use leads to a significant reduction in hair density and thickness, resulting in smoother skin.
This device is intended for home use and offers a convenient method for managing unwanted hair.
Image 1.1: Illustration of IPL technology targeting hair follicles beneath the skin surface to inhibit regrowth.
2. Important Safety Information
Read all instructions and safety warnings before using the device. Failure to follow these instructions may result in injury or device damage.
2.1 General Warnings
- Always wear the provided protective eyewear during operation to shield your eyes from the intense light flashes.
- Do not use the device on irritated, sunburned, or broken skin.
- Avoid direct exposure to the light window.
- Keep the device dry. Do not use it in wet environments or near water.
- Ensure the device is clean before each use.
2.2 Contraindications (Do Not Use If)
Consult a medical professional before use if you have any concerns. Do not use this device if you are:
- Under 18 years of age.
- Pregnant or breastfeeding.
- Diagnosed with diabetes, high blood pressure, or heart conditions.
- Have a history of skin cancer or pre-cancerous lesions.
- Have very dark skin tones, as IPL may not be suitable and could cause skin damage.
- Have very light hair (white, grey, or red), as IPL is less effective on these hair colors due to insufficient melanin.
3. Product Overview and Components
The DEESS GP586 IPL device is designed for user-friendly operation. It features a durable design with a wired power system for consistent performance.
3.1 Package Contents
Your package should contain the following items:
- 1 x DEESS GP586 IPL Main Unit (with HR lamp head for hair removal)
- 1 x Power Adapter
- 1 x User Manual (English and German)
- 1 x Pair of Protective Glasses
3.2 Device Features
- Unlimited Flashes: The device offers unlimited flashes for long-term use, eliminating the need for replacement cartridges within a 2-year period from the purchase date.
- Automatic Flash Mode: Ideal for treating larger body areas such as legs and arms, providing continuous flashes when in contact with the skin.
- Manual Flash Mode: Suitable for precise treatment of smaller or sensitive areas like the underarms and bikini line.
- Multi-functional Lamp Heads (Optional): In addition to the standard HR (Hair Removal) lamp head, SR (Skin Rejuvenation) and AC (Anti-Acne) lamp heads are available for purchase separately to expand the device's functionality.
4. Setup
Before your first treatment, ensure you prepare your skin and the device correctly.
4.1 Skin Preparation
- Shave the area to be treated. IPL is most effective when the hair is short, allowing the light energy to reach the follicle directly.
- Clean and dry your skin thoroughly. Ensure there are no lotions, creams, deodorants, or makeup on the treatment area.
4.2 Device Connection
- Connect the power adapter to the device.
- Plug the power adapter into a suitable electrical outlet. The device is wired and requires continuous power during use.
- Put on the protective glasses before turning on the device.
Image 4.1: The DEESS GP586 device connected to its power source, ensuring stable operation.
5. Operating Instructions
Follow these steps for safe and effective hair removal treatments.
5.1 Powering On and Energy Level Selection
- Press and hold the power button for 2-3 seconds to turn on the device.
- Once powered on, briefly press the power button to cycle through the 5 energy levels (1-5). Start with level 1 for sensitive skin or your first treatment, and gradually increase as your skin tolerates it. Higher levels generally yield faster results.
Image 5.1: Energy level selection on the DEESS GP586, ranging from level 1 for sensitive skin to level 5 for faster results.
5.2 Treatment Modes: Automatic and Manual
The device offers two modes for different body areas:
- Automatic Flash Mode: For large areas like legs and arms, place the light window firmly against the skin. The device will automatically emit flashes as you glide it over the skin.
- Manual Flash Mode: For smaller or sensitive areas such as underarms, bikini line, or face, place the light window firmly against the skin and press the flash button manually for each pulse.
Image 5.2: Demonstrating Automatic Flash Mode for large areas and Manual Flash Mode for smaller, precise areas.
5.3 Application Technique
- Ensure the light window is in full contact with your skin. The device will not flash if contact is not complete.
- Move the device slowly and evenly over the treatment area. Overlap flashes slightly to ensure full coverage, but avoid flashing the same spot multiple times in one session.
- A slight warm sensation or a mild prickling feeling is normal during treatment. If you experience pain or discomfort, reduce the energy level.
5.4 Treatment Schedule and Expected Results
Consistent use according to the recommended schedule is crucial for optimal results. Individual results may vary based on skin type, hair thickness, and adherence to the treatment plan.
| Phase | Frequency | Expected Outcome |
|---|---|---|
| Weeks 1-4 | 2-3 times per week | Hair growth begins to slow, and some hair may start to fall out. |
| Weeks 5-8 | 2 times per week | Hair growth is noticeably reduced. |
| Weeks 9-12 | 1 time per week | Hair becomes finer, lighter, and growth is significantly diminished. |
| After 12 Weeks | Once a month (as needed) | Maintain smooth, hair-free skin. |
Image 5.3: Visual representation of the recommended treatment schedule and expected hair reduction progress.
6. Maintenance
Proper care and maintenance will ensure the longevity and optimal performance of your device.
6.1 Cleaning the Device
- Always unplug the device from the power outlet before cleaning.
- Use a soft, dry cloth to wipe the light window and the device body.
- Do not use abrasive cleaners, alcohol, or harsh chemicals, as these can damage the device.
- Ensure no water or liquids enter the device.
6.2 Storage
- Store the device in a cool, dry place, away from direct sunlight and moisture.
- Keep the device out of reach of children.
7. Troubleshooting
If you encounter any issues with your DEESS GP586 device, refer to the following common troubleshooting tips.
| Problem | Possible Cause | Solution |
|---|---|---|
| Device does not turn on. | Not properly connected to power. | Ensure the power adapter is securely connected to both the device and the electrical outlet. |
| Device does not flash. | Light window not in full contact with skin. | Press the light window firmly against the skin. The device has a safety sensor that prevents flashing without proper skin contact. |
| No noticeable hair reduction after several weeks. | Inconsistent use, incorrect energy level, or unsuitable hair/skin type. | Review the treatment schedule and ensure consistent application. Increase the energy level if comfortable. Confirm your hair and skin type are suitable for IPL treatment (dark hair, light skin). Patience is key, as results take time. |
| Skin irritation or discomfort. | Energy level too high, or skin not properly prepared. | Reduce the energy level. Ensure skin is clean, dry, and freshly shaved before treatment. Avoid treating irritated skin. |
8. Specifications
Detailed technical specifications for the DEESS GP586 IPL Hair Removal Device.
- Model Number: 589 DE
- Manufacturer: GSD
- Dimensions: 24.8 x 20.6 x 9.6 cm (approx. 9.76 x 8.11 x 3.78 inches)
- Weight: 1.03 kg (approx. 2.27 lbs)
- Wavelength: 510-1100 nm
- Pulse Duration: 2-3 milliseconds
- Energy Levels: 5 adjustable levels
- Flash Lifespan: Unlimited flashes (within 2 years from purchase date)
- Power Source: Wired (AC adapter)
9. Warranty and Support
The DEESS GP586 IPL Hair Removal Device comes with a commitment to quality and performance.
9.1 Warranty Information
The device is designed for long-term use, offering unlimited flashes within a 2-year period from the date of purchase. This ensures that you can continue your hair removal treatments without concerns about flash cartridge replacements during this period.
9.2 Customer Support
For any questions, concerns, or technical assistance regarding your DEESS GP586 IPL device, please refer to the contact information provided with your purchase documentation or visit the official DEESS website for customer support details.
