LEXiBOOK RL977MI

LEXiBOOK Miraculous Projector Alarm Clock RL977MI User Manual

Model: RL977MI

1. Introduction

This manual provides comprehensive instructions for the setup, operation, and maintenance of your LEXiBOOK Miraculous Projector Alarm Clock, model RL977MI. Please read this manual thoroughly before using the device to ensure proper function and safety.

LEXiBOOK Miraculous Projector Alarm Clock, front view showing the LCD screen displaying 13:45, control buttons, and a Ladybug character. A blue projection of Ladybug is visible above the clock.

Figure 1: Front view of the LEXiBOOK Miraculous Projector Alarm Clock, model RL977MI. The clock features a digital LCD display, control buttons for time and alarm settings, and a projector that casts an image of Ladybug.

2. Safety Information

Important Safety Instructions:

This product is recommended for ages 3 years and up.
Do not expose the device to water or excessive moisture.
Do not attempt to disassemble or modify the device.
Use only the specified battery type (3 LR03/AAA batteries). Ensure correct polarity during installation.
Remove batteries if the device will not be used for an extended period.
Keep batteries out of reach of small children.

3. Package Contents

The package should contain the following items:

1 x LEXiBOOK Miraculous Projector Alarm Clock (Model RL977MI)
1 x Instruction Manual

Note: 3 LR03/AAA batteries are required for operation and are not included in the package.

Product packaging for the LEXiBOOK Miraculous Projector Alarm Clock, showing the clock and its features on the box.

Figure 2: The retail packaging for the LEXiBOOK Miraculous Projector Alarm Clock, illustrating the product and its key functions.

4. Components and Controls

Familiarize yourself with the main components and control buttons of your alarm clock:

LCD Screen: Displays time, alarm status, and other indicators.
Projector Lens: Located at the top, projects the image onto the ceiling.
Time Button: Used to enter time setting mode.
Alarm Button: Used to enter alarm setting mode.
Light Button (Night Light/Projector): Activates and cycles through night light colors and projection.
Hour Button: Adjusts the hour during setting modes.
Minute Button: Adjusts the minute during setting modes.
On/Off Button: Powers the device or specific functions.
Battery Compartment: Located at the bottom or back of the unit.

5. Setup

5.1. Battery Installation

Locate the battery compartment cover on the bottom or back of the alarm clock.
Using a small screwdriver (not included), unscrew the cover and remove it.
Insert 3 new LR03/AAA batteries, ensuring the correct polarity (+/-) as indicated inside the compartment.
Replace the battery compartment cover and secure it with the screw.

The clock will power on automatically once batteries are correctly installed.

6. Operating Instructions

6.1. Setting the Current Time

Press and hold the Time button until the hour display starts flashing.
Press the Hour button repeatedly to adjust the hour.
Press the Time button again to confirm the hour and move to minute setting. The minute display will flash.
Press the Minute button repeatedly to adjust the minute.
Press the Time button one last time to confirm the minute and exit time setting mode.

6.2. Setting the Alarm

Press and hold the Alarm button until the alarm hour display starts flashing.
Press the Hour button repeatedly to adjust the alarm hour.
Press the Alarm button again to confirm the alarm hour and move to alarm minute setting. The alarm minute display will flash.
Press the Minute button repeatedly to adjust the alarm minute.
Press the Alarm button one last time to confirm the alarm minute and exit alarm setting mode.
To activate or deactivate the alarm, briefly press the Alarm button. An alarm icon will appear or disappear on the LCD screen.

A child stretching and smiling in bed, with the LEXiBOOK Miraculous Projector Alarm Clock on a bedside table, suggesting a pleasant wake-up experience.

Figure 3: The alarm clock is designed to provide a gentle wake-up experience, as depicted by a child waking up comfortably.

6.3. Snooze Function

When the alarm sounds, press any button (except the On/Off button) to activate the snooze function. The alarm will temporarily stop and sound again after a few minutes (typically 5-10 minutes, refer to product specifics if available). To turn off the alarm completely, press the On/Off button.

6.4. Using the Night Light and Projector

The alarm clock features a night light and a projector that displays a Ladybug image on the ceiling in three different colors.

Press the Light button once to turn on the night light and projector. It will cycle through blue, red, and orange projection colors.
Press the Light button repeatedly to change the projection color (blue, red, orange).
To activate the automatic timer for the night light/projector, press and hold the Light button. The timer can be set for 5, 10, or 30 minutes. Release the button when the desired timer duration is displayed or indicated.
To turn off the night light and projector, press the Light button until it switches off, or wait for the timer to expire.

The LEXiBOOK Miraculous Projector Alarm Clock displaying a blue Ladybug projection on the ceiling.

Figure 4: The projector displaying a blue Ladybug image on the ceiling, creating a soothing ambiance.

The LEXiBOOK Miraculous Projector Alarm Clock displaying a red Ladybug projection on the ceiling.

Figure 5: The projector displaying a red Ladybug image on the ceiling, offering an alternative color option.

The LEXiBOOK Miraculous Projector Alarm Clock on a wooden surface at night, with a clear blue Ladybug projection on the ceiling against a starry background.

Figure 6: The alarm clock positioned on a nightstand, showcasing the clear projection of Ladybug onto the ceiling in a darkened room.

7. Care and Maintenance

Clean the device with a soft, dry cloth. Do not use abrasive cleaners or solvents.
Keep the projector lens clean to ensure clear image projection.
Avoid dropping the device or exposing it to strong impacts.
Store the alarm clock in a cool, dry place when not in use for extended periods.

8. Troubleshooting

Problem	Possible Cause	Solution
Device does not turn on.	Batteries are not installed or are depleted. Incorrect battery polarity.	Ensure batteries are correctly installed with proper polarity. Replace with new LR03/AAA batteries.
Display is dim or flickering.	Low battery power.	Replace all batteries with new ones.
Projector image is blurry.	Projector lens is dirty. Distance to projection surface is too far or too close.	Clean the projector lens with a soft, dry cloth. Adjust the distance of the clock from the ceiling.
Alarm does not sound.	Alarm is not activated. Alarm volume is too low (if adjustable, though this model does not specify).	Ensure the alarm icon is visible on the LCD screen. Re-set the alarm.

9. Specifications

Brand: LEXiBOOK
Model: RL977MI
Display Type: Digital LCD with blue backlight
Special Features: Alarm, Projection Clock, Snooze, Night Light with Timer
Projection Colors: 3 colors (Blue, Red, Orange)
Night Light Timer: 5, 10, 30 minutes
Power Source: 3 x LR03/AAA batteries (not included)
Product Dimensions: Approximately 4.65"W x 3.58"H (11.8 cm x 9.1 cm)
Item Weight: 115 Grams (approx. 4.1 ounces)
Material: ABS Plastic
Recommended Age: 3 years and up

10. Warranty and Support

For warranty information or technical support, please refer to the documentation provided with your purchase or contact LEXiBOOK customer service directly. Contact details can typically be found on the manufacturer's official website or on the product packaging.

Manufacturer: Lexibook
