Introduction
This manual provides comprehensive instructions for the safe installation, operation, and maintenance of your Meyda Tiffany 109567 Two-Light Wall Sconce Hardware. Please read all instructions carefully before beginning installation and retain this manual for future reference. This product is designed for indoor use only.
Safety Information
WARNING: Risk of electric shock. Disconnect power at the circuit breaker or fuse box before installation or servicing. Consult a qualified electrician if you are unsure about the installation process.
- Ensure all electrical connections comply with local codes and ordinances, as well as the National Electric Code (NEC).
- Do not install this fixture in wet or damp locations.
- Use only the specified bulb type and wattage to avoid overheating.
- Handle glass components with care to prevent breakage.
- Keep flammable materials away from the light fixture.
Package Contents
Verify that all components are present and undamaged before proceeding with installation.
- Wall Sconce Hardware (Main Fixture)
- Mounting Plate
- Mounting Screws and Wire Nuts
- Glass Shades (if applicable, though description says "Hardware")
- Instruction Manual
Image: The Meyda Tiffany 109567 Two-Light Wall Sconce Hardware in Brushed Nickel finish. This image shows the complete fixture, including the metal frame and glass components.
Setup and Installation
- Turn Off Power: Locate the circuit breaker or fuse box controlling the power to the desired installation location. Turn off the power completely.
- Prepare Mounting Surface: Ensure the wall surface is clean, dry, and structurally sound to support the fixture's weight.
- Attach Mounting Plate: Secure the mounting plate to the electrical junction box using the provided screws. Ensure it is firmly attached.
- Make Electrical Connections:
- Connect the ground wire (usually bare copper or green) from the fixture to the ground wire from the junction box.
- Connect the hot wire (usually black) from the fixture to the hot wire from the junction box.
- Connect the neutral wire (usually white) from the fixture to the neutral wire from the junction box.
- Secure all connections with wire nuts and ensure no bare wire is exposed.
- Mount the Fixture: Carefully align the fixture with the mounting plate and secure it using the provided screws.
- Install Bulbs: Insert two A15 type bulbs (not included) into the sockets. Do not exceed the maximum wattage specified on the fixture.
- Restore Power: Turn the power back on at the circuit breaker or fuse box. Test the fixture.
Operating Instructions
This wall sconce is designed for simple operation. Once installed and powered, it functions as a standard light fixture controlled by your wall switch. It requires two A15 type bulbs. The fixture does not include a built-in switch or dimmer; control is external via the household electrical system.
Maintenance
Cleaning
To clean the fixture, ensure the power is off and the fixture is cool. Wipe with a soft, dry cloth. Do not use abrasive cleaners, solvents, or polishes as they may damage the finish or glass. For stubborn spots, a slightly damp cloth may be used, followed by immediate drying.
Bulb Replacement
Before replacing bulbs, turn off the power at the circuit breaker and allow the bulbs to cool. Unscrew the old bulbs and replace them with new A15 type bulbs. Ensure the replacement bulbs do not exceed the maximum wattage rating of the fixture. The fixture is designed for two bulbs.
Troubleshooting
| Problem | Possible Cause | Solution |
|---|---|---|
| Fixture does not light up. |
|
|
| Bulbs burn out quickly. |
|
|
| Fixture flickers. |
|
|
Specifications
- Model Name: 109567
- Brand: Meyda
- Item Weight: 4 pounds
- Package Dimensions: 14 x 14 x 10 inches
- Finish Type: Brushed Nickel
- Material: Glass, Metal
- Style: Tiffany
- Light Fixture Form: Sconce
- Power Source: Corded Electric
- Number of Light Sources: 2
- Bulb Type: A15 (not included)
- Mounting Type: Wall Mount
- Included Components: Light Fixture
- UPC: 705696108121
Warranty Information
This Meyda Tiffany product is covered by a 1-year manufacturer's warranty from the date of purchase. This warranty covers defects in materials and workmanship under normal use. It does not cover damage resulting from improper installation, accident, misuse, abuse, or unauthorized modifications. Please retain your proof of purchase for warranty claims.
Customer Support
For technical assistance, missing parts, or warranty inquiries, please contact Meyda customer service. Refer to the official Meyda website or your purchase documentation for the most current contact information.
Note: Always provide your product model number (109567) when contacting support to ensure efficient service.
