Aquor House Hydrant V2+ User Manual

1. Product Overview

The Aquor House Hydrant V2+ is an innovative frost-free outdoor faucet designed for quick and easy water access. It features a concealed, flush-mount design that enhances exterior aesthetics while providing reliable, leak-free, and burst-proof performance. Constructed with high-quality, corrosion-resistant materials, this hydrant offers superior freeze protection compared to traditional hose bibs.

Figure 1: Aquor House Hydrant V2+ with its quick-connect hose connector.

Key Features:

• Elevated Outdoor Faucets: Connect garden hoses, sprinklers, and hose accessories instantly with a simple push and twist for a leak-free, quick-connecting swap of your spigot. The concealed frost-free sillcock offers a sleek, out-of-sight design.
• Burst-Proof & Stress-Free: Hydrants installed in insulated walls have 7x better sub-zero freeze protection than brass. Automatically drains and seals to winterize outdoor faucet so you never need to use a foam cover on your wall hydrant again.
• Professional Grade Details: Upgrade your outdoor water faucet to a longer-lasting solution with 100% lead-free, corrosion-resistant 316L stainless steel and crush-proof, military-grade polymer—all for a durable, more functional outdoor spigot.
• Limited Lifetime Warranty: Our products are backed by a limited lifetime warranty, offering decades of maintenance-free use. The unique valve design of the frost-free outdoor faucet is plumbing code approved for backflow prevention.
• What's Included: House hydrant, debris cover for head, straight hose connector, 1/2 inch NPT straight inlet, four mounting screws. A straightforward installation guide is also included for the outside faucet.

2. Setup and Installation

Proper installation is crucial for the optimal performance and longevity of your Aquor House Hydrant. Refer to the official Installation Manual (PDF) for detailed instructions.

Figure 2: Diagram illustrating the 10-inch stem length and 11.5-inch install depth for the VBHP010 model. An optional elbow inlet can shorten the install depth by 0.5 inches.

Installation Steps Overview:

1. Select Location: Choose an exterior wall location that allows for proper internal plumbing connections and drainage.
2. Measure Wall Thickness: Determine the appropriate hydrant length based on your wall's thickness to ensure the internal valve is within the heated space. The VBHP010 model has a 10-inch stem length and 11.5-inch installed depth.
3. Drill Hole: Use the provided mounting template to accurately drill a 1.5-inch hole through the exterior wall.
4. Mount Hydrant: Secure the hydrant to the exterior wall using the four mounting screws.
5. Connect Plumbing: From the interior, connect the hydrant to your water supply using appropriate plumbing fittings (e.g., 1/2 inch NPT straight inlet). Ensure all connections are watertight.
6. Test for Leaks: Slowly turn on the water supply and check for any leaks at the connections.

3. Operating Instructions

The Aquor House Hydrant V2+ is designed for effortless water access with its quick-connect system.

Figure 3: The Aquor House Hydrant simplifies various outdoor watering tasks.

To Use the Hydrant:

1. Attach Connector: Ensure your garden hose has the Aquor quick-connect hose connector attached.
2. Open Cover: Lift the debris cover on the hydrant face.
3. Insert and Twist: Align the grooves on the hose connector with the nibs on the hydrant. Push the connector firmly into the hydrant and twist it a quarter turn to engage the water flow.
4. Water Flow: Water will begin to flow instantly.

To Disconnect:

1. Twist and Pull: Twist the hose connector a quarter turn in the opposite direction and pull it out of the hydrant.
2. Automatic Drainage: The hydrant will automatically drain any remaining water from the internal pipe, ensuring frost-free operation.
3. Close Cover: Close the debris cover to protect the hydrant opening.

4. Maintenance

The Aquor House Hydrant V2+ is designed for minimal maintenance due to its robust construction and frost-free features.

• Winterization: The hydrant automatically drains and seals, providing superior freeze protection. No need for foam covers or manual shut-off valves for winterization in most climates.
• Cleaning: Periodically wipe down the exterior faceplate with a soft, damp cloth to remove dirt and debris. Avoid abrasive cleaners.
• Debris Cover: Ensure the debris cover is always closed when the hydrant is not in use to prevent foreign objects from entering the valve.

Figure 4: The hydrant's design ensures automatic winterization and professional-grade durability.

5. Troubleshooting

If you encounter any issues with your Aquor House Hydrant, consider the following common troubleshooting steps:

• No Water Flow:
  • Ensure the hose connector is fully inserted and twisted a quarter turn.
  • Check if the main water supply to the hydrant is turned on.
  • Verify that the hose itself is not kinked or blocked.
• Leaks at Connection:
  • Ensure the hose connector is properly seated and twisted.
  • Check the O-rings on the hose connector for wear or damage. Replace if necessary.
  • Confirm that the internal plumbing connections are secure and free of leaks.
• Water Not Draining:
  • Ensure the hose connector is fully removed after use. The automatic drainage mechanism activates upon disconnection.
  • Check for any obstructions in the drainage port on the hydrant face.

For persistent issues, please contact Aquor customer support.

6. Specifications

7. Warranty and Support

Aquor stands behind the quality of its products.

• Limited Lifetime Warranty: The Aquor House Hydrant V2+ is backed by a limited lifetime warranty, ensuring decades of maintenance-free use.

Customer Support:

For assistance with product selection, installation, or product support, please contact Aquor Water Systems:

• Phone: (800) 458-1749
• Hours: Monday - Friday, 9 AM - 4 PM PST

Additional resources, including the full installation manual, can be found on the Aquor Store on Amazon.
